New Original SICK 1059632 GL6G-P4211 Retroreflective Photoelectric Sensor
Product Overview
The GL6G-P4211 (Order No. 1059632) is a miniature retroreflective photoelectric sensor belonging to SICK premium G6 compact series, manufactured in Hungary for general industrial automation object detection tasks. Adopting dual-lens optical structure integrated with polarizing filter and PinPoint red LED light source, this sensor achieves stable detection up to maximum 6 meters when paired with standard PL80A reflector, and it is specially optimized for reliable detection of transparent materials such as plastic bottles, glass sheets and transparent packaging filmsSICK. Equipped with PNP digital switching output, 270° sensitivity adjustment potentiometer and selectable light-on/dark-on switching logic, the tiny rectangular body features IP67 dustproof and waterproof enclosure, built-in comprehensive circuit protection and high anti-interference ASIC chip. With ultra-small installation footprint, robust mechanical structure and long service life, it complies with CE, UL and RoHS standards, widely deployed in packaging machinery, logistics conveyor lines, food processing equipment, automated assembly jigs and electronics production lines for counting, position triggering and object presence monitoring.
Main Technical Specifications
| Parameter Item | Detailed Specification |
|---|---|
| Full Model | GL6G-P4211 |
| Order Code | 1059632 |
| Detection Principle | Retroreflective type, dual lens system with polarization filter |
| Rated Sensing Range | 0.07 m ~ 5 m (standard working); Max. 6 m (with PL80A reflector) |
| Light Source | PinPoint visible red LED, wavelength 650 nm |
| Light Spot Diameter | Ø 8 mm at 350 mm distance |
| Power Supply | DC 10 V ~ 30 V, allowable ripple ±10% |
| No-load Current Consumption | 30 mA |
| Switching Output | PNP open collector, max. output current 100 mA |
| Switching Mode | Light-on / Dark-on selectable via side toggle switch |
| Response Time | ＜ 625 μs |
| Max Switching Frequency | 1,000 Hz |
| Adjustment Mode | 270° rotary potentiometer for sensing distance fine tuning |
| Special Function | Transparent object detection capability |
| Built-in Protection | Reverse polarity protection, output short-circuit & overload protection |
| Protection Class | IP67 |
| Operating Ambient Temperature | -25 ℃ ~ +55 ℃ |
| Storage Temperature | -40 ℃ ~ +70 ℃ |
| Service Life of LED | 100,000 hours under 25 ℃ ambient |
| Connection Interface | M8 4-pin male plug connector |
| Certifications | CE, UL, RoHS |
Overall Dimensions & Net Weight
| Dimension & Weight Parameter | Exact Data |
|---|---|
| Overall Outline Size | Width 12 mm × Height 31.5 mm × Depth 21 mm |
| Mounting Design | Built-in M3 metal threaded inserts for bracket fixing |
| Single Unit Net Weight | 20 g |
| Packaged Gross Weight | Approximately 28 g |
| Housing Material | ABS/PC blended engineering plastic |
| Front Optical Window | PMMA transparent anti-scratch plastic |
Primary Main Functions
- General Solid & Transparent Object Detection: Reliably identify opaque workpieces, cartons, as well as transparent glass, PET bottles and plastic films that ordinary retroreflective sensors fail to detect steadily.
- High-speed Counting & Position Triggering: 1kHz high switching frequency supports high-speed conveyor workpiece counting, limit position stop and mechanical jog triggering for automated assembly equipment.
- Flexible Switching Logic Selection: Freely switch between light-activated and dark-activated output modes to match diverse PLC input logic requirements on site.
- Sensing Distance Calibration: Large rotary potentiometer enables easy sensitivity adjustment to adapt to different detection distances and environmental dust conditions.
- Abnormal Circuit Self-protection: Multiple protective circuits prevent damage caused by reverse power wiring, output short circuit and overload current faults.
- Clear Working Status Indication: Bright built-in LED indicators display power supply status, light receiving condition and output switching state for rapid debugging and troubleshooting.
- Harsh Environment Adaptation: IP67 sealed casing resists workshop dust, water splashes and slight oil mist erosion in humid production workshops.
- Stable Long-term Continuous Operation: Exclusive SICK ASIC chip effectively suppresses mutual interference between multiple adjacent sensors and electromagnetic disturbance from inverters and servo drives.
Key Technical Features
- Ultra-compact 12mm slim miniature housing occupies minimal installation space, ideal for dense layout inside narrow mechanical fixtures and compact equipment frames.
- PinPoint focused red LED generates tiny round light spot, ensuring precise alignment and reducing false triggering caused by uneven object surfaces.
- Polarizing filter eliminates interference from shiny reflective surfaces such as metal plates, greatly improving detection stability for glossy workpieces.
- Embedded metal threaded mounting holes enhance structural rigidity, resisting loosening faults triggered by long-term equipment vibration.
- Wide DC input voltage range tolerates industrial power grid voltage fluctuation without signal loss or abnormal reset.
- M8 standard plug-and-play connector simplifies wiring and equipment replacement, shortening maintenance downtime.
- Extremely long MTTFD value guarantees decades of stable operation under cyclic industrial working conditions.
- Unified G6 series mechanical dimensions realize full interchangeability among different sensing principle models for convenient equipment upgrading.
List of 10 Similar Functional SICK G6 Series Photoelectric Sensors
- GL6G-N4211: NPN output version of GL6G-P4211 for NPN-type PLC control systems
- GL6-P1212: 2m fixed cable outgoing type without M8 connector, economical wired connection model
- GTB6-P4241: Background suppression diffuse reflection sensor for short-range irregular object detection
- GTE6-P4211: Standard diffuse reflective photoelectric switch for general short-distance object sensing
- GL6G-P4215: Extended 8m long-distance retroreflective sensor for large-span conveyor application
- GL6G-P1211: Basic retroreflective model without transparent object detection function
- GSE6-P4211: Through-beam opposed photoelectric sensor for ultra-reliable long-distance detection
- GL6G-P4211-HT: High-temperature resistant variant suitable for baking and thermal processing workshops
- GL6G-P4212: Dual-indicator enhanced version with extra fault diagnosis LED lamp
- WT2S-P130: Micro ultra-miniature series retroreflective sensor for ultra-narrow installation space
