New Original SHIMADEN SR1-8P-1C Panel Mount PID Temperature Controller (SSR Drive Output)
Product Overview
SR1-8P-1C is a compact DIN 48×48 digital PID temperature controller manufactured by SHIMADEN (Japan), belonging to the classic SR1 economical series of industrial process regulators. This panel-mounted instrument is designed for precise temperature closed-loop control across heating furnaces, ovens, packaging machinery, plastic molding equipment, food processing devices and general heating/cooling automation systems. The model features SSR voltage drive output to directly trigger solid state relays for heater power regulation, integrated auto-tuning Expert PID algorithm, universal multi-sensor input and one set of configurable alarm output. Its front panel complies with IP66 dustproof and splash-proof standard after cabinet embedding, equipped with high-brightness dual digital displays for real-time measured value and set value reading. Powered by universal AC wide-range voltage, the unit delivers stable overshoot-suppressed temperature control, simple parameter configuration and reliable long-term continuous operation, certified with CE and RoHS industrial safety standards worldwide.
Main Technical Specifications
| Parameter Item | Detailed Specification |
|---|---|
| Full Model | SR1-8P-1C |
| Overall Series | SHIMADEN SR1 Compact PID Controller Series |
| Standard Panel Size | DIN 48 mm × 48 mm Square |
| Main Control Output | P-Type SSR Drive Output: 12 V DC ±1.5 V, Max 30 mA |
| Proportional Cycle | Adjustable 1 ~ 120 seconds |
| Universal Sensor Input | Thermocouple (K, J, E, T, R, S, B, N); Pt100 RTD; DC mV / DC Voltage signals |
| Display Resolution | 0.1℃ / 1℃ selectable; Display range: -1999 ~ 9999 digits |
| Control Algorithm | Expert SF PID with Auto-Tuning, Overshoot Suppression Function |
| Auxiliary Output | 1 set relay alarm output (SPDT contact, 240 VAC / 1 A resistive load) |
| Rated Power Supply | AC 100 ~ 240 V (50/60 Hz), ±10% tolerance |
| Power Consumption | Less than 6 VA |
| Front Protection Grade | IP66 / NEMA 4X (after embedded panel installation) |
| Operating Ambient Temp | 0 ℃ ~ +50 ℃ |
| Storage Temperature | -20 ℃ ~ +70 ℃ |
| Ambient Humidity | 10% ~ 90% RH (non-condensing) |
| Insulation Withstand Voltage | 2000 V AC between input and power terminals |
| Certifications | CE, RoHS |
Overall Dimensions & Net Weight
| Dimension & Weight Parameter | Exact Data |
|---|---|
| Body Outer Dimensions | Width 48 mm × Height 48 mm × Depth 111 mm |
| Cabinet Panel Cutout Size | 45 mm × 45 mm |
| Applicable Panel Thickness | 1.2 mm ~ 3.2 mm |
| Single Unit Net Weight | 150 g |
| Packaged Gross Weight | Approximately 180 g |
| Mounting Method | One-touch embedded panel snap installation |
Primary Main Functions
- Precise Closed-loop PID Temperature Regulation: Automatically calculate proportional, integral and derivative parameters via auto-tuning function, effectively eliminate temperature fluctuation and overheating overshoot to maintain constant set temperature.
- SSR Driving Control: The 12 V DC voltage output directly drives external solid state relays, realizing contactless silent heater switching with long service life compared to mechanical relay output.
- Multi-mode Alarm Function: Supports high temperature alarm, low temperature alarm, deviation alarm and sensor break alarm to trigger warning signals for abnormal working conditions.
- Universal Signal Compatibility: Freely switch input types between thermocouples, thermal resistors and voltage signals to adapt to diverse temperature sensing scenarios without replacing controllers.
- Multi-group Preset Temperature Values: Store multiple target temperature setpoints for quick switching during different production processes, shortening product changeover time.
- Sensor Fault Diagnosis: Automatically detect open-circuit or short-circuit of temperature probes, stop heating output and display error codes to avoid equipment overheating damage.
- Simple On-site Calibration: Zero and span correction function corrects measurement deviation caused by long-term use or sensor aging.
- Dust & Moisture Resistant Operation: Sealed front panel prevents workshop oil mist, water splashes and dust intrusion, suitable for humid and dusty production environments.
Key Technical Features
- Ultra-compact 48×48 mini square design occupies minimal cabinet space, ideal for small control panels and multi-channel dense layout occasions.
- Exclusive SF anti-overshoot PID algorithm optimizes heating curve performance, perfectly suited for precision thermal processing requiring strict temperature stability.
- Contactless SSR drive output has no mechanical abrasion, supporting high-frequency long-cycle switching without contact sticking failure.
- Large bright digital dual display ensures clear reading under strong light and dim workshop lighting conditions.
- Wide universal AC power input adapts to unstable industrial grid voltage fluctuation without abnormal reset or display flicker.
- One-touch snap-in mounting structure simplifies installation and disassembly without extra fixing brackets.
- Simplified parameter menu reduces operation difficulty for on-site maintenance technicians.
- Reinforced internal circuit layout provides excellent anti-electromagnetic interference capability near inverters and solenoid valves.
List of 10 Similar Functional SHIMADEN Temperature Controllers
- SR1-8Y-1C: Same 48×48 size, mechanical relay contact output version for low-frequency switching applications
- SR1-8I-1C: 4–20 mA current analog output PID controller for external actuator continuous regulation
- SR1-8V-1C: 0–10 V DC voltage output model for proportional electric heater control
- SR3-8P-1C: 96×96 large panel SSR drive PID controller for high-power heating equipment
- SR4-8P-1C: 96×48 horizontal rectangular SSR output temperature controller for narrow cabinet layout
- SRS11A-8P: New generation upgraded SRS1 series compact PID controller with enhanced anti-interference and communication option
- SR71-8P: Previous generation 48×48 SSR drive temperature controller with compatible installation dimensions
- SR1-8P-2C: Dual alarm output upgraded model for dual-limit safety temperature monitoring
- FP93-8P: Programmable ramp temperature controller with multi-step temperature curve program function
- SR91-8P: High-precision industrial grade PID regulator with optional RS485 Modbus communication interface
