New Original Schneider ATV12HU15M2 Altivar 12 Variable Speed Drive
"*" indicates required fields
New Original Schneider ATV12HU15M2 Altivar 12 Variable Speed Drive
Product Overview
ATV12HU15M2 is a compact entry-level variable frequency drive (VFD) belonging to Schneider Electric Altivar 12 series, specially designed for speed regulation control of small asynchronous three-phase motors in simple industrial equipment and commercial machinery施耐德电气. This unit accepts single-phase 200~240V AC input, delivers rated output power of 1.5kW (2HP), equipped with built-in heat sink and integrated EMC filter. Adopting sensorless flux vector control technology, it provides stable motor torque output, flexible speed adjustment and comprehensive motor protection functions. With ultra-compact cabinet-friendly structure, intuitive front panel operation knob, embedded Modbus RS485 communication interface and multiple preset application macros, it features easy commissioning, low noise operation and outstanding anti-interference capability. Certified with CE, UL and RoHS standards, it is widely applied in small conveyors, packaging machines, mixers, textile ironing equipment, fans, pumps and general automated small-scale production machinery.
Main Technical Specifications
| Parameter Item | Detailed Specification |
|---|---|
| Model Code | ATV12HU15M2 |
| Series | Altivar 12 Compact General-purpose VFD |
| Rated Output Power | 1.5 kW / 2 HP |
| Input Power Supply | Single-phase AC 200 ~ 240 V (50/60 Hz), tolerance -15% ~ +10% |
| Output Rating | Three-phase AC 200 ~ 240 V |
| Rated Output Current | 7.5 A |
| Input Line Current | 14.9 A (240V) / 17.8 A (200V) |
| Output Frequency Range | 0.5 Hz ~ 400 Hz |
| Switching Frequency | 2 kHz ~ 16 kHz adjustable |
| Control Mode | U/F characteristic control, Sensorless flux vector control |
| Peak Overload Torque | 150% rated torque for 60 seconds |
| Braking Capacity | Up to 70% nominal torque without external braking resistor |
| Built-in Standard Ports | 4 digital inputs, 1 analog input, 2 digital outputs, 1 relay fault output, 1 analog output |
| Communication Interface | RS485 Modbus protocol (2-wire) |
| EMC Filter | Integrated built-in EMC filter |
| Protection Grade | IP20 (indoor control cabinet installation only) |
| Operating Ambient Temperature | -10 ℃ ~ +50 ℃ (derating required above 40℃) |
| Storage Temperature | -20 ℃ ~ +70 ℃ |
| Acoustic Noise Level | ≤ 45 dB |
| Certifications | CE, UL, cUL, RoHS |
Overall Dimensions & Net Weight
| Dimension & Weight Parameter | Exact Data |
|---|---|
| Overall Width | 105 mm |
| Overall Height | 143 mm |
| Overall Depth | 156.2 mm |
| Mounting Method | Vertical panel DIN rail mounting |
| Single Unit Net Weight | 1.4 kg |
| Packaged Gross Weight | Approximately 1.7 kg |
| Cooling Mode | Built-in axial fan + integrated aluminum heat sink |
Primary Main Functions
- Stepless Motor Speed Regulation: Continuously adjust rotating speed of asynchronous motors to match different production process requirements, replacing fixed-speed operation to realize flexible process control.
- Energy Saving Operation: Optimize motor operating efficiency under variable load conditions, effectively reduce power consumption for fan, pump and conveying equipment.
- Soft Start & Soft Stop: Avoid large impulse current and mechanical shock during motor startup and shutdown, extend service life of motors, belts and mechanical transmission components.
- Complete Multi-dimensional Protection: Integrate overvoltage, undervoltage, overcurrent, overload, overheating, short-circuit and motor stall protection to prevent equipment damage from abnormal working conditions.
- Modbus Network Communication: Realize data interaction with PLC, HMI and upper monitoring systems via RS485 bus, supporting remote speed setting, running status reading and fault diagnosis.
- Multiple Application Preset Macros: Built-in dedicated parameter groups for fans, pumps, conveyors and mixing equipment, one-click quick setup to shorten on-site debugging time.
- Fault Record Storage: Automatically record the latest 4 groups of fault codes and running parameters for convenient maintenance troubleshooting.
- Flexible Signal Configuration: Freely define functions of digital/analog input and output terminals to adapt to diverse on-site wiring and control logic demands.
Key Technical Features
- Ultra-compact slim body design occupies minimal cabinet space, perfectly suited for small electrical control cabinets with limited internal layout area.
- Intuitive front panel rotary knob + digital display enables parameter modification and speed monitoring without extra programming tools.
- Integrated EMC filter effectively suppresses electromagnetic radiation and conducted interference, ensuring stable operation near inverters and servo equipment.
- Sensorless vector control delivers high starting torque at low speed, guaranteeing stable operation for heavy-load startup scenarios.
- Adjustable switching frequency reduces motor electromagnetic noise, adapting to quiet workshop environmental requirements.
- Robust plastic housing and internal reinforced circuit structure possess excellent vibration resistance for continuous 24-hour cyclic production operation.
- Wide input voltage tolerance adapts to unstable industrial power grid fluctuation without shutdown or malfunction.
- Plug-and-play design simplifies installation and wiring, lowering overall engineering time and maintenance difficulty for OEM machinery manufacturers.
List of 10 Similar Functional Schneider Altivar Series Variable Speed Drives
- ATV12HU075M2: 0.75kW single-phase input compact VFD, low-power small equipment dedicated model
- ATV12HU22M2: 2.2kW single-phase input upgraded power version of ATV12HU15M2
- ATV12HU15M3: 1.5kW three-phase 200V input variant for three-phase industrial power supply environments
- ATV310HU15N4: 1.5kW three-phase 380V general-purpose economical VFD for fans and pumps
- ATV320U15N4: High-performance compact VFD with advanced communication and safety functions
- ATV12HU40M2: 4kW maximum power model of Altivar 12 single-phase series
- ATV12HU15M2S: Without built-in EMC filter economical version for non-interference sensitive occasions
- ATV340U15N4: IoT-enabled heavy-duty VFD with extended safety and process control functions
- ATV11HU15M2: Previous generation economical VFD with compatible installation dimensions
- ATV212HU15N4: HVAC dedicated variable frequency drive optimized for air conditioning and ventilation systems
