Siemens 6ES7 231‑4HD32‑0XB0 SIMATIC S7‑1200 SM 1231 Analog Input Module
Product Overview
The Siemens 6ES7 231‑4HD32‑0XB0 is an SM 1231 high‑precision analog input expansion module for the SIMATIC S7‑1200 PLC series. It is designed to acquire standard voltage and current analog signals from industrial field sensors and transmitters, converting continuous physical signals into digital data for S7‑1200 CPU processing. This module expands the analog signal acquisition capacity of the control system, featuring high‑resolution conversion, channel‑level diagnostics, and strong anti‑interference performance. It is widely used in temperature, pressure, flow, liquid‑level and weight measurement applications in machinery manufacturing, water treatment, HVAC and small‑to‑medium process automation systems.
Main Functions
- Multi‑range Analog Signal Collection
Supports standard voltage and current input signals to connect various industrial sensors and measuring transmitters.
- High‑precision A/D Conversion
Provides accurate analog‑to‑digital conversion to ensure reliable measurement results for industrial closed‑loop control.
- Channel‑level Fault Diagnosis
Monitors open‑circuit, short‑circuit, over‑range and under‑range conditions for each channel, and transmits diagnostic information to the CPU in real time.
- Independent Channel Configuration
Allows separate parameter setting of signal type, measurement range and filter time for each channel via TIA Portal software.
- Galvanic Isolation Protection
Isolates field‑side circuits from the PLC internal bus to prevent damage caused by ground potential differences and electromagnetic noise.
- Modular System Expansion
Plugs directly into the S7‑1200 backplane bus, enabling flexible expansion of analog input points without extra wiring.
Technical Characteristics
- Compact modular design suitable for standard DIN‑rail mounting inside electrical control cabinets.
- High‑resolution conversion for stable acquisition of weak industrial analog signals.
- Industrial‑grade electromagnetic compatibility for reliable operation in harsh factory environments.
- Low power consumption, supporting long‑term continuous 24‑hour operation.
- Full compatibility with all S7‑1200 CPU models and Totally Integrated Automation Portal software.
- Rugged mechanical structure with vibration and shock resistance for on‑site industrial use.
Technical Specifications
表格
| Item | Specification |
|---|---|
| Model Number | 6ES7 231‑4HD32‑0XB0 |
| Module Type | SM 1231, 4‑channel analog input module |
| Supported Input Signals | Voltage, Current |
| Resolution | 13‑bit + sign |
| Galvanic Isolation | Yes, between field side and backplane bus |
| Diagnostics | Open‑circuit, short‑circuit, over‑range, under‑range per channel |
| Protection Class | IP20 |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Compatible System | SIMATIC S7‑1200 PLC series |
| Programming Software | TIA Portal |
| Mounting Type | Standard DIN‑rail mounting |
Product Dimensions and Weight
Overall Dimensions (Width × Height × Depth)
- Module Size: 45 mm × 100 mm × 75 mm
Weight
- Net Weight: Approximately 0.14 kg
- Gross Weight (with standard packaging): Approximately 0.19 kg
