Siemens 6SL3210-1KE23-2UF1 SINAMICS G120C RATED POWER
"*" indicates required fields
Siemens 6SL3210‑1KE23‑2UF1 SINAMICS G120C Compact Frequency Inverter
Product Overview
The Siemens 6SL3210‑1KE23‑2UF1 is a compact‑size SINAMICS G120C variable frequency drive (VFD) designed for three‑phase AC motor speed control in general industrial applications. With a rated power of 15 kW, this integrated drive combines power unit, control unit and safety functions in one compact housing. It features high efficiency, simple commissioning, robust industrial performance and built‑in safety torque off function. Widely applied in fans, pumps, conveyors, packaging machinery, textile equipment and other standard machinery, it provides stable motor speed regulation and energy‑saving operation.
Main Functions
- Stepless Motor Speed Regulation
Realizes smooth speed control of three‑phase asynchronous motors for flexible production and process adjustment.
- Energy‑saving Operation
Optimizes motor running parameters to reduce power consumption for fan and pump loads under variable working conditions.
- Built‑in Safety Function
Integrated Safe Torque Off (STO) safety function to cut off motor torque reliably for machine safety requirements.
- Rich I/O Interfaces
Equipped with digital inputs, digital outputs and analog I/O for connecting sensors, switches and external control signals.
- Multiple Communication Options
Supports standard industrial communication protocols to connect with PLCs, HMIs and upper‑level control systems.
- Complete Protection & Diagnosis
Monitors over‑current, over‑voltage, under‑voltage, over‑temperature and motor overload, with fault code display for troubleshooting.
- Simple Parameter Setting
Supports basic commissioning via BOP‑2 operator panel or TIA Portal software for fast on‑site setup.
Technical Characteristics
- Compact integrated design, saving cabinet installation space.
- High‑performance vector control ensures stable low‑speed torque output.
- Industrial‑grade EMC design with strong anti‑interference capability for factory environments.
- Wide voltage adaptability and high overload capacity for heavy‑duty starting conditions.
- Fan‑cooled structure with long‑life cooling system for continuous long‑time operation.
- DIN‑rail mounting compatible, easy for installation and wiring in control cabinets.
Technical Specifications
表格
| Item | Specification |
|---|---|
| Model Number | 6SL3210‑1KE23‑2UF1 |
| Series | SINAMICS G120C Compact Inverter |
| Rated Power | 15 kW |
| Input Power | 3‑phase 380‑480 V AC, 50/60 Hz |
| Rated Output Current | 32 A |
| Control Mode | V/F control, vector control |
| Safety Function | Built‑in Safe Torque Off (STO) |
| I/O Configuration | Digital inputs ×6, digital outputs ×2, analog input ×1, analog output ×1 |
| Protection Class | IP20 |
| Operating Temperature | ‑10 °C to +50 °C |
| Storage Temperature | ‑40 °C to +70 °C |
| Overload Capacity | 150% rated current for 60 s |
| Mounting Type | DIN‑rail mounting |
Product Dimensions and Weight
Overall Dimensions (Width × Height × Depth)
- Inverter Size: 160 mm × 260 mm × 190 mm
Weight
- Net Weight: Approximately 4.1 kg
- Gross Weight (with standard packaging): Approximately 4.6 kg
