New Original Schneider A9N15656 Fuse Switch Disconnector
1. Product Overview
The A9N15656 is an original Schneider Electric modular fuse switch disconnector belonging to the Acti9 (A9) low-voltage terminal distribution product line. It integrates three core functions: manual circuit isolation, short-circuit protection via replaceable cartridge fuse, and load breaking control. Designed for DIN rail mounting inside distribution boxes, control cabinets and power distribution panels, this unit is widely applied in residential power distribution, commercial building auxiliary circuits, small industrial control loops, photovoltaic branch circuits and instrumentation power supply loops.
This model adopts standardized modular design consistent with the full Acti9 series, realizing compact centralized circuit protection and visible breaking point isolation compliance with international safety regulations. It is factory-new original genuine product with complete structural integrity, intact internal fuse holder assembly and qualified mechanical and electrical performance.
2. Main Functions
- Visible Isolation Function
Clear mechanical on/off indication window on front panel; when switched to OFF position, a reliable air isolation gap is formed inside, satisfying safety isolation requirements for circuit maintenance, preventing accidental electric shock during wiring or overhaul work.
- Short-Circuit & Overcurrent Protection
Equipped with dedicated internal fuse cavity for matching standard cylindrical cartridge fuses. When short-circuit or severe overcurrent occurs, the fuse melts rapidly to cut off fault current, protecting upstream cables, terminal loads and front-end distribution components from burnout damage.
- Manual Load Switching Control
Manually operated toggle handle realizes safe closing and opening of rated load current, used for regular circuit startup, shutdown and branch power cut-off management.
- Modular Expansion Compatibility
Reserved assembly interface for matching Acti9 series auxiliary contacts, shunt release, under-voltage release and other electrical accessories to realize remote tripping, switching status signal feedback and automatic protection linkage.
3. Technical Features
Core Electrical Specifications
表格
| Item | Technical Parameter |
|---|---|
| Brand & Model | Schneider Electric A9N15656 |
| Product Series | Acti9 Modular Low-Voltage Series |
| Pole Configuration | 1-Pole (1P) |
| Rated Operational Voltage | 230 V AC 50/60 Hz |
| Max Accommodated Fuse Rating | Up to 63 A standard cylindrical fuse |
| Standard Compliance | IEC 60947-3, IEC 60269, GB 14048.3 |
| Mechanical Endurance | 20,000 times on-off operation |
| Electrical Endurance | 10,000 times rated current breaking |
| Ambient Operating Temperature | -35 °C ~ +70 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Protection Class | IP20 (indoor installation) |
| Mounting Standard | 35 mm standard DIN top-hat rail |
Structural & Design Advantages
- Dual-purpose Wiring Terminals
Tunnel-type screw terminals support solid copper wire, stranded wire and busbar connection, with firm crimping, anti-loosening structure and strong anti-vibration performance.
- Flame-Retardant Housing Material
High-temperature resistant thermoplastic shell with flame retardant rating V0, anti-arc ablation, anti-aging and long service life under continuous operating temperature.
- Integrated Fuse Holder Structure
Tool-assisted fuse replacement design, convenient for on-site maintenance and fuse specification adjustment according to actual load current demand.
- Anti-misoperation Handle Lock Structure
Optional padlockable handle design to lock switch in OFF state, avoiding unauthorized closing during maintenance operation.
- Inter-series Uniform Modular Pitch
Consistent installation width with Acti9 MCB, RCD and other components, neat arrangement inside distribution box, high space utilization.
4. Product Dimension & Net Weight
Overall Dimension Table
表格
| Dimension Type | Value (Unit: mm) | Description |
|---|---|---|
| Module Width | 18 | 1 standard modular unit (9 mm × 2) |
| Total Height | 85 | Overall vertical height of installed body |
| Installation Depth | 69 | Depth protruding inside distribution box after DIN rail mounting |
| Total Overall Size | 18 (W) × 85 (H) × 69 (D) | Complete outline dimension |
Weight Parameter
- Single unit net weight: approximately 115 grams
- Gross weight with individual packaging: approximately 140 grams
5. Typical Application Scenarios
- Branch circuit protection in residential and commercial power distribution boxes
- Control loop protection for small motors, solenoid valves and contactor control circuits
- DC/AC auxiliary power protection for PLC, sensors and field instruments
- String branch protection for small off-grid photovoltaic power supply systems
- Isolation and overcurrent protection for lighting, socket sub-circuits
