New Original Parker 801-12 BLU 801 Series Push-Lok Blue Thermal Rubber Hose
1. Product Overview
801-12 BLU is an original Parker low-pressure multipurpose rubber hose within the 801 Push-Lok series. The marking -12 refers to 3/4 inch nominal inner diameter, and BLU stands for blue outer cover for circuit visual identification. It is constructed with single high-tensile fiber braid reinforcement, synthetic rubber inner tube and MSHA-certified abrasion-resistant outer jacket.
This hose is engineered to match Parker 82 Series and HY Series Push-Lok push-on fittings. Assembly only requires push-fit connection without crimping equipment, supporting fast on-site hose fabrication. It transmits compressed air, low-pressure petroleum hydraulic oil, lubricants, cooling water, water-glycol coolant and thermal circulation media. Widely applied in machine tools, automated assembly lines, packaging machinery, general pneumatic systems and industrial thermal management loops. The blue outer cover helps distinguish different fluid pipelines to avoid misconnection during equipment assembly and maintenance.
2. Main Functions
- Multi-medium Low-pressure Fluid Transmission Conveys compressed air, cooling liquid, lubricating oil and low-pressure hydraulic fluid steadily within defined pressure and temperature operating boundaries.
- Push-Lok Quick Assembly Compatibility Direct push-fit connection with dedicated push-on fittings, greatly simplifying field modification, maintenance and hose replacement work.
- Color-coded Pipeline Classification Blue outer surface enables intuitive separation of different fluid circuits, convenient for equipment inspection and troubleshooting.
- Balanced Flexibility for Compact Installation Optimized structural design achieves a reasonable minimum bend radius, suitable for layout inside limited machine frames and equipment enclosures.
- Vacuum conveying capability Supports vacuum service up to 711 mm Hg, applicable to negative pressure suction and vacuum transport circuits.
- Wide ambient temperature adaptability Maintains stable performance for various working media under fluctuating industrial temperatures.
- Durable wear-resistant outer cover MSHA-approved rubber outer layer resists mechanical friction, dust and mild oil mist for extended service life.
3. Technical Characteristics
| Technical Parameter | Detailed Specification |
|---|---|
| Full Model | 801-12 BLU |
| Product Series | 801 Series Push-Lok Multipurpose Rubber Hose |
| Nominal Inner Diameter | 3/4 inch (19.0 mm) |
| Outer Diameter | 27.7 mm |
| Reinforcement | Single high-tensile fiber braid |
| Inner Tube Material | Synthetic NBR rubber |
| Cover Material | MSHA accepted synthetic rubber, Blue |
| Maximum Working Pressure | 250 psi (1.7 MPa) |
| Burst Pressure | 1000 psi, 4:1 safety design factor |
| Minimum Bend Radius | 200 mm |
| Vacuum Rating | Max. 711 mm Hg (28 inch-Hg) |
| Compatible Fittings | Parker 82 Series, HY Series Push-Lok fittings |
| Temperature Range – Oil | -40 ℃ ~ +125 ℃ |
| Temperature Range – Water | Max. +85 ℃ |
| Temperature Range – Air | Max. +70 ℃ |
| Unit Weight | 0.48 kg per meter |
| Supply Form | Standard reel packaging or custom cut lengths |
| Compliance Standards | MSHA, RoHS |
Core Technical Advantages
- Push-Lok push-in connection removes reliance on crimping tools, ideal for field maintenance and spare part replacement;
- Single fiber braid structure balances flexibility and pressure resistance for low-pressure industrial fluid circuits;
- Multiple color options support standardized pipeline marking for automation equipment;
- Broad medium compatibility covers pneumatic, cooling and thermal management applications;
- Mature rubber formulation guarantees stable long-term operation in general factory workshop environments.
4. Product Dimensions and Weight
Section Dimensions (Unit: Millimeter)
| Dimension Item | Exact Size |
|---|---|
| Nominal Inner Diameter | 19.0 |
| Outer Diameter | 27.7 |
| Minimum Bend Radius | 200 |
Weight Reference
表格
| Weight Category | Specific Value |
|---|---|
| Unit Weight | 0.48 kg per meter |
| Packaged Weight | Depends on customized cutting length |
5. 10 Parker Similar Push-Lok Multipurpose Rubber Hoses
All models belong to Parker Push-Lok low-pressure hose system compatible with push-on fittings; variations include inner diameter, cover color and upgraded specifications:
- 801-4 BLU 1/4″ Blue Push-Lok Multipurpose Rubber Hose
- 801-6 BLU 3/8″ Blue 801 Series Push-Lok Hose
- 801-8 BLU 1/2″ Blue Push-Lok Thermal Rubber Hose
- 801-10 BLU 5/8″ Blue Push-Lok Multipurpose Hose
- 801-12 BLK 3/4″ Black 801 Series Push-Lok Hose
- 801-12 RED 3/4″ Red Color-Coded Push-Lok Hose
- 801-12 GRN 3/4″ Green Push-Lok Rubber Hose
- 801PLUS-12-BLU Enhanced Push-Lok Multipurpose Hose
- 801TM-12-BLU Thermal Management Special Push-Lok Hose
- 804-12 BLU High Temperature Resistant Push-Lok Rubber Hose
