1. Product Overview
VP5006BJ111HXR is an original IMI Norgren 3/2-way proportional pressure control valve belonging to the VP50 series. It adopts air piloted glandless spool technology with built-in closed-loop pressure sensor feedback, delivering continuously adjustable pneumatic output pressure corresponding to analog control signals. The model supports 0–10 V voltage command signal and provides real-time pressure feedback output.
Designed for filtered dry compressed air, this unit features G1/4 threaded ports and standard M12×1 5-pin electrical connector. It is widely applied in tension control, pressing machinery, packaging equipment, textile production lines, automated testing stations and robotic clamping systems, where precise, dynamic pneumatic pressure regulation is required. The suffix HXR represents special customized specification variant. It supports manifold or direct surface mounting and achieves fast response with excellent linearity and low hysteresis, suitable for continuous duty industrial automation environments.
2. Main Functions
- Continuous Closed-Loop Proportional Pressure Regulation Converts analog control signal into stable proportional pneumatic output pressure. Internal pressure sensor forms closed-loop control to eliminate pressure fluctuation caused by load variation and supply pressure drift.
- 3/2-Way Pneumatic Function Integrates supply, output and exhaust ports. It can build up, maintain or release air pressure dynamically to adapt to variable tension and clamping force demands.
- Analog Signal Input & Feedback Output Accepts 0–10 V setpoint signal from PLC or motion controller, and outputs corresponding analog feedback signal for real-time pressure monitoring on host control systems.
- Fast Dynamic Response Performance Short pressure adjustment cycle enables rapid pressure rise and decay, meeting high-speed continuous operation requirements of automated machinery.
- Adjustable Control Parameters Gain and response characteristics can be optimized to balance stability and dynamic performance for different load volumes.
- High Flow Capacity with Low Air Consumption Supports large airflow output while maintaining low steady-state air consumption, improving system energy efficiency.
- Rugged Environmental Adaptability IP65 protection rating prevents dust, splash water and workshop oil mist intrusion, supporting stable operation under typical factory conditions.
3. Technical Characteristics
| Technical Parameter | Detailed Specification |
|---|---|
| Full Model | VP5006BJ111HXR |
| Product Series | VP50 Series 3/2 Proportional Pressure Control Valve |
| Pneumatic Function | 3/2-way, closed-loop proportional control |
| Working Medium | Filtered, dry compressed air (5 μm filtration recommended) |
| Port Connection | G1/4 thread |
| Output Pressure Range | 0 ~ 6 bar |
| Minimum Supply Pressure | 3 bar above maximum output pressure |
| Maximum Supply Pressure | 10 bar |
| Control Input Signal | 0 ~ 10 V DC |
| Feedback Output Signal | 0 ~ 10 V DC |
| Electrical Connection | M12×1, 5-pin connector |
| Protection Class | IP65 |
| Linearity | < 1% full span |
| Hysteresis | < 1% full span |
| Response Time | < 80 ms (10%–90% pressure change, 0.1 L load) |
| Max Flow Rate | 1000 NL/min |
| Static Air Consumption | 5 NL/min |
| Operating Ambient Temperature | 0 ℃ ~ +50 ℃ |
| Storage Temperature Range | -20 ℃ ~ +60 ℃ |
| Mounting Method | Manifold mounting or surface direct mounting |
| Body Material | Aluminium alloy; Seals: NBR |
| Compliance Standards | CE, RoHS |
Core Technical Advantages
- Glandless spool design reduces friction, improving long-term control consistency and service life;
- Built-in closed-loop sensor ensures high precision pressure stability against supply fluctuation;
- Compact integrated structure saves installation space inside control cabinets and machine frames;
- Standard M12 connector simplifies wiring and supports quick plug-and-play replacement;
- Wide compatibility with PLC and motion control systems with analog output modules;
- Multiple mounting options facilitate flexible layout on automation equipment.
4. Product Dimensions and Weight
External Dimensions (Unit: Millimeter)
| Dimension Item | Exact Size |
|---|---|
| Overall Length | 116.5 |
| Overall Width | 55 |
| Overall Height | 119 |
Weight Parameters
| Weight Category | Specific Value |
|---|---|
| Single Unit Net Weight | 0.55 kg |
| Original Packaged Gross Weight | 0.68 kg |
5. 10 Norgren VP50 Series Similar Proportional Pressure Control Valves
All listed models belong to VP50 proportional valve platform with closed-loop pressure feedback, 3/2-way function and manifold mounting capability; differences lie in pressure range, control signal type and port configuration:
- VP5002BJ111H00 0–2 bar, 0–10V Analog Signal Proportional Valve
- VP5004BJ411H00 0–4 bar, 4–20mA Current Signal Proportional Valve
- VP5006BJ411H00 0–6 bar, 4–20mA Proportional Pressure Control Valve
- VP5008BJ111H00 0–8 bar, 0–10V Voltage Signal Proportional Valve
- VP5010BJ111H00 0–10 bar, 0–10V Analog Proportional Valve
- VP5006SBJ111H00 Manifold Mount Version, 0–6 bar 0–10V Valve
- VP5006BJ111H00 Standard 0–6 bar 0–10V Proportional Valve
- VP5006BJ111HX IO-Link Communication Type Proportional Valve
- VP5006SPK111H00 1/4″ NPT Thread Version, 0–6 bar
- VP5010BX111H00 Base Mounted High Pressure 0–10 bar Proportional Valve
列举一些Norgren品牌的其他产品
介绍一下Norgren品牌的发展历史
详细说明Norgren品牌的压力控制技术特点
