New Original Autonics TC4H-24R PID Temperature Controller
1. Product Overview
The Autonics TC4H-24R belongs to the TC4 series economical single-display PID temperature controller, featuring 1/8 DIN 48×96 mm panel mounting form. It supports multi-type sensor inputs including thermocouples and RTD Pt100, equipped with relay control output, dual alarm outputs (AL1 & AL2), and universal 100–240 V AC power supply. Adopting PID algorithm together with ON/OFF, P, PI, PD control modes, it stabilizes temperature by regulating heaters or cooling equipment. Widely used in ovens, molding machines, packaging equipment, environmental test chambers and automated production lines for constant-temperature control. The supplied unit is brand new original genuine Autonics product.
2. Main Technical Specifications
| Item | Parameter |
|---|---|
| Model | TC4H-24R |
| Series | TC4 PID Temperature Controller |
| Panel Size | 48 mm (W) × 96 mm (H), 1/8 DIN standard |
| Display | 4-digit red 7-segment LED single display |
| Control Modes | ON/OFF, P, PI, PD, PID control |
| Sensor Input | Thermocouple K, J, L; RTD Pt100Ω, Cu50Ω |
| Sampling Cycle | 100 ms |
| Control Output | Relay output (250 V AC, 3 A) + SSR drive signal |
| Alarm Output | AL1, AL2 dual relay alarm outputs (250 V AC, 1 A) |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Power Consumption | Max. 5 VA |
| Operating Temperature | -10 °C ~ +50 °C |
| Storage Temperature | -20 °C ~ +60 °C |
| Accuracy | ±0.5% FS or ±1 °C (whichever greater) |
| Mounting | Panel flush mounting |
| Terminals | Screw clamping terminals |
| Overall Depth | 65 mm |
| Net Weight | Approx. 194 g |
| Compliance Standards | CE, RoHS |
3. Main Functions
- Collect temperature signals from thermocouple or Pt100 sensors and perform continuous closed-loop PID temperature regulation.
- Support multiple control algorithms to eliminate temperature overshoot and maintain stable target temperature.
- Dual independent alarm outputs realize high-temperature, low-temperature or deviation alarm for equipment protection.
- Relay and SSR dual-purpose control output can directly drive contactors or solid state relays for heating loads.
- Digital parameter setting via front panel keys for target temperature, PID parameters and alarm thresholds.
- Built-in loop break alarm function to detect sensor open-circuit failure.
- Visible LED digital readout shows real-time process value for convenient on-site monitoring.
- Multiple alarm operation modes including deviation alarm, upper/lower limit alarm for flexible application configuration.
4. Technical Features
- Compact 48×96 mm standard panel size, compatible with universal industrial instrument cutout dimensions.
- High-speed 100 ms sampling ensures fast response to temperature fluctuation.
- Optimized PID algorithm effectively suppress overshoot and oscillation for precise constant temperature control.
- Universal sensor input supports switching between thermocouple and RTD without hardware modification.
- Dual alarm channels provide multi-level temperature monitoring to prevent abnormal working conditions.
- Selectable control output modes match resistive heating loads with different driving schemes.
- Clear LED display with high visibility under factory workshop lighting conditions.
- Stable circuit design with strong anti-interference capability for complex industrial electromagnetic environments.
- Non-volatile memory saves all parameter settings after power failure.
- Simple key operation structure, easy commissioning and parameter modification on site.
5. 10 Autonics Similar PID Temperature Controllers
- TC4H-22R, TC4H series, 24–48 V AC/DC power supply, single-display PID temperature controller
- TC4S-14R, 48×48 mm 1/16 DIN single-display temperature controller with 1 alarm output
- TC4M-24R, 72×72 mm 1/4 DIN PID temperature controller, dual alarm output
- TC4W-24R, 96×48 mm horizontal type single-display temperature controller
- TCN4H-24R, Dual display PV/SV PID temperature controller, 48×96 mm panel size
- TC4L-24R, 96×96 mm large-size panel mount temperature controller
- TC4Y-14R, 48×24 mm slim miniature PID temperature controller
- TK4S-14RN, Economical compact temperature controller with RS485 communication option
- TC4SP-14R, Simplified single alarm version of TC4 series temperature controller
- TN4H-24R, High-precision 2-DOF PID programmable temperature controller
