New Original Harting 09150006203 Han D F Crimp Contact Ag AWG 20
"*" señala los campos obligatorios
New Original Harting 09150006203 Han D F Crimp Contact Ag AWG 20
Product Overview
09150006203 is an authentic original female crimp contact belonging to Harting classic Han D heavy-duty connector series, professionally manufactured in Germany. This silver-plated female contact is exclusively designed for Han D modular inserts of industrial heavy-duty rectangular connectors. It adopts crimp termination technology, perfectly matching AWG 20 (0.5 mm²) fine stranded cables, responsible for stable transmission of control signals and low-power electric current inside heavy-duty connectors. The contact is precision-machined from high-conductivity copper alloy with full silver plating on the mating surface, featuring low contact resistance, anti-oxidation and excellent wear resistance. Widely applied in machine tool control cabinets, automated production lines, packaging equipment, robotic systems, wind power auxiliary control units, transportation electrical modules and all kinds of factory automation wiring connection scenarios. It serves as the core conductive internal component to realize detachable pluggable electrical interconnection between device cables and cabinet wiring terminals.
Main Technical Specifications
| Parameter Item | Detailed Specification |
|---|---|
| Full Part Number | 09150006203 |
| Product Name | Han D Female Crimp Contact, Silver Plated, AWG 20 |
| Contact Gender | Female (Socket Contact) |
| Termination Method | Crimp connection |
| Applicable Wire Gauge | AWG 20 / 0.5 mm² conductor cross-section |
| Rated Current | 10 A |
| Rated Voltage | 250 V AC |
| Max Contact Resistance | ≤ 3 mΩ |
| Surface Plating Material | Silver plating |
| Base Material | High-grade copper alloy |
| Required Cable Stripping Length | 8 mm |
| Minimum Service Mating Cycles | ≥ 500 times |
| Operating Temperature Range | -40 °C ~ +125 °C |
| Compliance Certifications | RoHS, REACH compliant |
| Application Series | Han D heavy-duty connector inserts |
Overall Dimensions and Single Unit Weight
- Total overall length: 21.5 mm
- Maximum outer diameter: 3.5 mm
- Crimp barrel inner size: Matched for 0.5 mm² wire crimping
- Net weight per single contact: approximately 0.1 g
Main Functions
- Reliable Electrical Conduction: Build stable conductive path for control signals and low-power current between two pluggable connector parts with ultra-low energy loss.
- Firm Crimp Cable Fixation: Crimp structure tightly clamps cable conductors and insulation jackets, preventing wire pull-off caused by cable pulling, vibration or bending.
- Detachable Plug & Play Connection: Cooperates with male contacts to achieve quick connection and disassembly of equipment wiring for convenient equipment maintenance and replacement.
- Anti-oxidation Contact Protection: Silver plated layer isolates air and moisture, avoiding oxidation corrosion and contact failure in humid industrial environments.
- Vibration-resistant Continuous Transmission: Precision internal structure keeps consistent contact pressure under long-term mechanical vibration, no signal interruption or poor contact.
- Standardized Insert Assembly: Can be freely arranged and inserted into Han D plastic inserts to customize multi-pin wiring layouts according to circuit demands.
- Easy On-site Assembly: Compatible with dedicated Harting crimping hand tools, allowing fast wire termination on production site without soldering operation.
- Long-term Stable Storage Performance: Metal substrate with uniform plating will not degrade performance during long-term spare parts storage.
Key Technical Features
- Lathe precision turned copper alloy body delivers superior structural rigidity and electrical conductivity compared with stamped contacts.
- Uniform silver plating layer effectively reduces contact resistance and friction coefficient, extending service life under repeated plugging cycles.
- Dual-section crimp barrel design separately compresses conductor core and cable insulation layer, balancing electrical performance and mechanical pull-out resistance.
- Optimized female spring cage structure maintains stable clamping force on mating male pin, eliminating loose contact caused by wear after frequent plugging.
- Compact slim body occupies minimal space inside Han D inserts, supporting high-density multi-channel signal wiring layout.
- Wide temperature tolerance ensures stable performance in both low-temperature cold workshops and high-heat enclosed electrical cabinets.
- Soldering-free crimp connection avoids thermal damage to cable insulation, greatly improving wiring safety and construction efficiency.
- Strict unified dimensional tolerance ensures full interchangeability with all standard Han D series contacts for maintenance replacement.
List of 10 Harting Similar Functional Crimp Contacts (Han D Series)
- 09150006103 Han D Male Silver Crimp Contact AWG 20
- 09150006204 Female silver contact for AWG 18 (1.0 mm²)
- 09150006104 Male silver crimp contact AWG 18
- 09150006206 Female gold-plated contact AWG 20 for weak signal
- 09150006106 Male gold-plated crimp contact AWG 20
- 09150006202 Female silver contact AWG 22 (0.34 mm²)
- 09150006102 Male silver contact AWG 22
- 09150006208 Female 16A high-current silver contact AWG 16
- 09150006108 Male high-current crimp contact AWG 16
- 09150006205 Female tinned economical crimp contact AWG 20
