New Original Harting 09150006124 Heavy‑Duty Han D Male Crimp Pin Contact
1. Product Overview
Harting part‑number 09150006124 is German‑manufactured male crimp‑style contact pin belonging to Han‑D series heavy‑duty‑connector system. It serves as internal conductive pin fitted into Han‑D series connector inserts for control‑signal transmission in automated assembly machines, machine tools, packaging equipment and robot wiring systems. The pin body is made of high‑strength copper‑alloy with gold‑plated contact surface to achieve low contact resistance and anti‑oxidation performance. It adopts crimp‑type termination and is applicable for wire cross‑section from 0.14 mm² to 0.37 mm² (AWG22‑26). This component complies with RoHS, REACH‑SVHC and IEC‑60664‑1 standards for global industrial‑control‑system application. It can only work together with matched Han‑D inserts, connector housings and dedicated Harting crimp tools.
2. Main Functions
- Reliable signal‑conducting function: Transmit control‑circuit signals continuously with rated 10 A current and 250 V AC voltage between internal wiring and Han‑D connector inserts.
- Firm crimp connection: After crimping by special Harting crimp pliers, copper conductors are tightly clamped inside the tail part of contact pin to avoid wire loosening caused by long‑time equipment vibration.
- Stable mating performance: Precision‑machined male‑pin geometry ensures consistent contact pressure against female counterparts; maximum 500 insertion‑withdrawal cycles without obvious performance degradation.
- Low‑resistance transmission: Gold‑plated surface reduces contact resistance below 3 mΩ and prevents oxidation even under humid and slightly dusty workshop environments.
- Convenient maintenance: The pin can be detached from Han‑D insert with Harting extraction tools when individual pins get damaged without replacing whole connector insert.
- Standardized matching design: Designed exclusively for Han‑D series inserts, which can form complete multi‑pin heavy‑duty‑connector assembly after installation.
3. Technical Characteristics
- Electrical parameters: Rated continuous current 10 A; rated voltage 250 V AC; impulse withstand voltage 4 kV; maximum contact resistance ≤3 mΩ; insulation pollution grade‑3.
- Material and surface treatment: Base material is high‑strength copper alloy; contact area is gold‑plated.
- Wiring requirement: Crimp‑termination type; applicable wire size 0.14–0.37 mm² (AWG22‑26); recommended wire stripping length is 8 mm.
- Environmental specifications: Operating temperature range −40 ℃ ~ +125 ℃; anti‑vibration property complies with EN‑60068‑2‑27 standard.
- Mechanical performance: Allowable mating cycles up to 500 times; pull‑out force after crimping exceeds 80 N.
- Compliance certificates: RoHS‑compliant, REACH‑qualified without restricted hazardous substances.
- Matching accessories: Requires Harting dedicated crimp tool and pin‑removal tool; compatible with Han‑D series inserts onlyHARTING Te….
4. Dimensions and Weight
| Item | Specific Parameter |
|---|---|
| Overall length of single pin | 25 mm |
| Maximum outer diameter of contact head | 3.2 mm |
| Crimp‑range for conductors | 0.14‑0.37 mm² |
| Single‑piece net weight | 1.8 g |
| Plating material of contact part | Gold plating |
| Termination method | Crimp connection |
| Suitable insert | Han‑D series heavy‑duty‑connector inserts |
5. Ten Harting similar‑function crimp‑contact pins with official part‑numbers
All items are original Harting crimp contacts for Han‑series heavy‑duty‑connectors for alternative selection:
- 09150006123: Han‑D female crimp contact matched with 09150006124, same wire range of 0.14‑0.37 mm² and 10‑A rated‑current.
- 09150006125: Male crimp pin for 0.5‑1.0 mm² wires under Han‑D series with rated‑current 10 A for thicker control cables.
- 09150006126: Silver‑plated male crimp pin instead of gold‑plated type for dry indoor workshop to reduce cost.
- 09150008104: Han‑D high‑current male crimp contact with 16‑A rating for higher‑load control‑circuits.
- 09150006122: High‑temperature‑resistant version of Han‑D male pin, working temperature from −40 ℃ to +150 ℃.
- 09330006106: Han‑E‑series male crimp pin, 10‑A rated‑current for Han‑E connector inserts.
- 09150006121: Shield‑type crimp‑pin variant with anti‑electromagnetic‑interference design for high‑noise industrial sites.
- 09140013011‑PIN: Han‑Modular male crimp‑pin for modular‑type inserts with 5‑A rated‑current for low‑current signal circuits.
- 09150006127: Extended‑length Han‑D male crimp pin for deep‑installation‑type Han‑D inserts.
- 09150006128: Nickel‑plated male‑pin version used in slightly corrosive workshop environment.
6. Application Notes
- Only use official Harting crimp‑tools; improper crimping will cause high contact resistance and over‑heating issues.
- Keep stripped wire length strictly at 8 mm; too‑long exposed copper will result in short‑circuit between adjacent pins.
- Install this pin only into original Harting Han‑D inserts; non‑genuine inserts lead to poor mating and loose‑contact faults.
- Prevent metal powder, cutting fluid and oil mist from polluting gold‑plated surface to maintain low‑contact‑resistance performance.
- Replace contacts once pins are bent after repeated plug‑in beyond 500‑cycle service‑life limit.
