New Original Harting 09140122632 Heavy‑duty Connector Module
1. Product Overview
Harting part‑number 09140122632 is a Germany‑originated male‑pin heavy‑duty connector insert belonging to the Han‑Modular DD series. It is a 12‑position module with Han‑Quick‑Lock spring‑clamp wiring structure rather than traditional crimp‑type connection. This modular insert fits into Han‑Modular frames and then assembles with Harting Han‑series connector hoods and housings. It is widely applied for control‑signal transmission on automation production equipment, machine tools, robotic wiring systems and packaging machinery. The insulator body adopts UL94‑V0 flame‑retardant polycarbonate with RAL7032 pebble‑grey colour. Contact pins are made of copper alloy with silver‑plated surface. This component meets RoHS, REACH‑SVHC, UL‑61984 and DNV‑GL standards for worldwide industrial‑control‑system deployment. Minimum order quantity is two pieces per factory packaging unit.
2. Main Functions
- Stable power‑and‑signal transmission: The 12‑pin male contacts carry control‑circuit signals with rated 10 A and 250 V AC, which connects sensors, solenoid valves and auxiliary control components reliably.
- Time‑saving spring‑clamp wiring design: Han‑Quick‑Lock push‑in terminals accept 0.25‑1.5 mm² stranded wires without special crimping tools, greatly shortening wiring‑installation time.
- Anti‑vibration wire‑locking function: Internal stainless‑steel spring pieces firmly clamp conductors; wires will not get loose under continuous vibration during long‑term equipment running.
- Flexible modular combination: This DD‑size module can be combined with high‑current power modules, data modules and shielded signal modules inside one connector housing to integrate power‑supply and signal‑wiring together.
- Convenient maintenance: Individual module can be replaced separately without taking down the whole heavy‑duty connector housing when certain channels break down, which reduces maintenance costs.
- High‑insulation performance: Polycarbonate housing maintains high dielectric‑strength, preventing short‑circuit and cross‑interference between adjacent contact pins.
3. Technical Characteristics
- Electrical parameters: Rated current 10 A; rated voltage 250 V AC (600 V under UL certification); impulse withstand voltage 4 kV; insulation resistance ＞10¹⁰ Ω; contact resistance ≤3 mΩ; pollution grade‑3.
- Contact structure: 12‑pin male contacts; copper‑alloy material with silver‑plated surface; service life up to 500 mating cycles.
- Wiring specification: Han‑Quick‑Lock spring‑clamp connection, suitable for wire cross‑section 0.25‑1.5 mm² (AWG 16‑23).
- Material performance: Insulator: UL94‑V0 flame‑retardant polycarbonate; spring parts: stainless‑steel anti‑rust material.
- Environmental parameters: Operating temperature range −40 ℃ ~ +125 ℃; anti‑vibration performance complies with EN‑60068‑2‑27 industrial standard.
- Compliance certifications: Approved by UL, DNV‑GL, RoHS‑compliant and REACH‑qualified without prohibited hazardous substances.
- Matching parts: Installed into standard Han‑Modular DD frames and then matched with Han‑series connector hoods.
4. Dimensions and Weight
| Description | Specific Parameter |
|---|---|
| Overall length | 36.5 mm |
| Overall width | 25.4 mm |
| Overall height | 14.8 mm |
| Number of pins | 12‑pin male contacts |
| Termination method | Han‑Quick‑Lock spring‑clamp wiring |
| Single‑piece net weight | 5 g |
| Insulator colour | RAL7032 pebble‑grey |
| Acceptable wire size | 0.25 mm² to 1.5 mm² |
| Matching frame | Han‑Modular DD frame |
5. Ten Harting similar‑function Han‑Modular Connector Modules with official part‑numbers
All listed items are genuine Harting original modules for Han‑Modular heavy‑duty‑connectors for alternative selection:
- 09140122732: Female counterpart of 09140122632, 12‑pin spring‑clamp female‑type module with same 10‑A rated‑current and DD‑size outline.
- 09140123001: 12‑pin male module with crimp‑type termination instead of spring‑clamp design for projects that adopt crimp‑wiring way.
- 09140173001: Han‑DDD‑size 17‑pin male crimp‑module with 10‑A rated‑current for occasions requiring more signal channels浩亭技术集….
- 09140122632‑EMC: Shielded‑version 12‑pin spring‑clamp male module with metal shielding shell for high‑electromagnetic‑interference workshops.
- 09140006258: 4‑pin high‑power module with 16‑A rated‑current for heavy‑load control‑circuits.
- 09140423001: Han‑DD Quad double‑module with 42‑pins for high‑density wiring installationHARTING.
- 09140122633: High‑temperature variant with modified‑PC insulator, working temperature range −40℃ to +150℃ for oven‑related automation equipment.
- 09140132632: 8‑pin spring‑clamp male‑module with 10‑A rated‑current for fewer‑channel control‑system layout.
- 09140122632‑PCB: PCB‑mounted variant of 09140122632 for direct soldering on circuit‑boards without wire‑crimping.
- 09140013011: 8‑pin crimp‑type male module for small‑signal transmission with compact single‑module dimension.
6. Application Notes
- Do not exceed rated‑10‑A current and 250‑V voltage; otherwise over‑heating and contact burnout will occur.
- Strip appropriate‑length wire insulation before inserting conductors into spring‑clamp terminals to avoid short‑circuit caused by exposed copper wires.
- Only install this module with original Harting Han‑Modular frames and connector housings; non‑genuine accessories will result in poor‑mating and loose‑connection faults.
- Prevent cutting fluid, metal dust and oil mist from entering contact‑pin area so as to keep low contact‑resistance and stable signal‑transmission performance.
- Do not plug‑in and pull‑out over 500 times; replace modules if pins are bent after long‑term repeated mating.
