Siemens 6ES7134-6JD00-0CA1 Analog Input Module
Product Overview
The Siemens 6ES7134-6JD00-0CA1 is a high-precision, 4-channel analog input module from the SIMATIC ET 200SP series, designed for distributed I/O systems in industrial automation. It is used to acquire, condition, and digitize standard analog current and voltage signals from field devices such as pressure transmitters, temperature sensors, flow meters, and level detectors. Featuring galvanic isolation, high resolution, and comprehensive diagnostics, this module ensures stable and accurate signal processing in harsh industrial environments. It is widely applied in process automation, machine building, material handling, and building control systems.
Main Functions
-
Multi-Channel Analog Signal Acquisition
- Provides 4 electrically isolated analog input channels for simultaneous measurement of current and voltage signals.
- Supports a wide range of standard industrial analog signals for high compatibility with field instruments.
-
High-Precision A/D Conversion
- Delivers high-resolution analog-to-digital conversion to ensure accurate measurement and stable data transmission.
- Offers configurable filtering to suppress electromagnetic interference and improve signal stability.
-
Galvanic Isolation & Protection
- Features full galvanic isolation between input channels, backplane bus, and system power to prevent ground loops and protect the controller.
- Provides overrange and underrange monitoring for each channel to avoid measurement errors.
-
Comprehensive Diagnostic Functions
- Supports wire-break monitoring for current signals to detect cable faults quickly.
- Includes channel status LEDs and system diagnostic feedback for real-time operation monitoring and troubleshooting.
-
Flexible Configuration & Compatibility
- Configurable via SIMATIC engineering software for signal type, measuring range, filtering, and diagnostic parameters.
- Fully compatible with all SIMATIC ET 200SP base units and supports hot-swapping for easy maintenance.
-
System Integration
- Communicates reliably over the ET 200SP backplane bus and works seamlessly with SIMATIC S7-1200, S7-1500, and other supported controllers.
Technical Features
表格
| Parameter | Specification |
|---|---|
| Product Model | 6ES7134-6JD00-0CA1 |
| Product Series | SIMATIC ET 200SP |
| Number of Input Channels | 4 analog input channels |
| Nominal Input Voltage | 24 V DC (via base unit) |
| Supported Signal Types | Standard current and voltage analog signals |
| Isolation | Galvanic isolation between channels and bus |
| Resolution | High-resolution analog-digital conversion |
| Input Filter | Software-configurable filtering |
| Diagnostics | Wire-break detection, overrange, underrange, channel status |
| Operating Temperature | -25 °C to +60 °C |
| Storage Temperature | -40 °C to +70 °C |
| Humidity | 10% – 95% non-condensing |
| EMC Compliance | EN 61131-2, EN 61000-6-2, EN 61000-6-4 |
| Mounting | 35 mm DIN rail (EN 50022) |
| Base Unit Required | Standard ET 200SP analog base unit |
Product Dimensions
- Width: 15 mm
- Height: 66 mm
- Depth: 54 mm
- Ultra-compact modular design for high-density installation in control cabinets
Weight
- Net weight: Approximately 0.04 kg
- Gross weight (with packaging): Approximately 0.06 kg
