New Original Siemens 6ES7134-4GB11-0AB0 Analog Input Module
1. Product Overview
The Siemens 6ES7134-4GB11-0AB0 is a brand-new original analog electronic input module belonging to the SIMATIC ET 200S distributed I/O system. This 4-channel analog input module is specially designed to collect continuous analog signals from field industrial transmitters, including 4–20 mA current transmitters, temperature sensors and pressure transducers. It works collaboratively with IM 151 series PROFIBUS DP interface modules and matched ET 200S terminal base units to build decentralized measurement and control systems for chemical process equipment, water treatment plants, packaging production lines, HVAC systems and machine tool hydraulic monitoring units. The module converts weak analog field signals into standardized digital values and transmits data to upper S7-300/S7-400 PLCs via PROFIBUS DP fieldbus. It supports hot-swap maintenance without shutting down the whole ET 200S station, integrated channel diagnostic functions and independent signal filtering circuits. The split separation design of electronic module and wiring terminal base avoids reconnection of field signal cables during module replacement, greatly shortening equipment maintenance downtime. All parameter configuration, signal calibration and fault diagnosis operations are completed uniformly through TIA Portal engineering software.
2. Main Functions
- 4-Channel Standard Analog Signal Acquisition
Supports 2-wire and 4-wire 4–20 mA analog current signals, the most widely used signal type for industrial pressure, flow and liquid level transmitters.
- High-Precision Analog-to-Digital Conversion
Adopts high-resolution ADC chips to realize stable conversion between analog field signals and digital PLC process data with low measurement deviation.
- Independent Software-Configurable Signal Filtering
Adjustable digital filter time for each channel via TIA Portal to suppress transient electromagnetic interference from inverters and servo drives in industrial cabinets.
- Comprehensive Per-Channel Diagnostic Detection
Automatically monitors wire break, short-circuit and overload faults on every input channel; uploads fault alarm information to PLC in real time.
- Independent Channel Status LED Indicators
Each analog channel is equipped with a dedicated LED light to display normal operating status or fault alarm status for quick on-site troubleshooting.
- Hot-Swap Replacement Capability
When matched with dedicated ET 200S terminal modules, the electronic core can be disassembled and replaced while the ET 200S station keeps running normally.
- Galvanic Isolation Between Bus and Field Circuits
Built-in isolation structure separates internal backplane bus circuit and field analog signal circuit to eliminate cross-interference between multiple measurement channels.
- PROFIBUS DP Isochronous Communication Support
Compatible with PROFIBUS DP isochronous mode to meet high-synchronization continuous process measurement requirements.
- Reverse Polarity Protection for Field Inputs
Internal protection circuit prevents module damage caused by reversed positive and negative wiring of field transmitters.
- Modular Free System Expansion
Stackable layout with other ET 200S digital I/O, analog output and safety modules to flexibly expand analog measurement points according to process monitoring demands.
3. Technical Characteristics
表格
| Technical Parameter | Specification of 6ES7134-4GB11-0AB0 |
|---|---|
| Complete Model Code | 6ES7134-4GB11-0AB0 |
| Product Series | SIMATIC ET 200S Analog Input Module |
| Channel Quantity | 4 analog input channels |
| Supported Signal Type | 4–20 mA, 2-wire / 4-wire current transmitters |
| Measuring Resolution | 13 bits + sign bit |
| Measuring Range | 0–20 mA, 4–20 mA software selectable |
| Basic Error Limit | ±0.5% of full scale at 25 °C |
| Adjustable Filter Time Range | 0.5 ms to 64 ms via software parameterization |
| Diagnostic Functions | Wire break detection, channel short-circuit, overload monitoring |
| Communication Bus | PROFIBUS DP (cooperates with IM151 interface modules) |
| Isochronous Mode Support | Yes |
| Isolation Withstand Voltage | 500 V DC between bus side and field signal side |
| Backplane 3.3 V DC Bus Current Consumption | Max 16 mA |
| Typical Module Power Dissipation | 1.6 W |
| PLC Process Image Address Occupation | 4 words input address space |
| Visual Indicator | 4 independent channel LED status lights |
| Protection Class | IP20, only for installation inside electrical control cabinets |
| Operating Ambient Temperature | 0 °C ~ +60 °C vertical installation |
| Storage & Transport Temperature | -40 °C ~ +70 °C |
| Industrial Certifications | CE, UL standard global industrial safety certifications |
| Matching Accessories | ET200S Type A or Type B dedicated terminal modules |
4. Product Dimensions & Weight
4.1 Overall Module Outer Dimensions
表格
| Dimension Item | Exact Measurement |
|---|---|
| Module Width | 15 mm |
| Module Height | 81 mm |
| Module Depth | 52 mm |
4.2 Weight Specifications
- Net weight of single analog electronic module (excluding terminal base): 0.048 kg
- Gross weight with original separate individual carton packaging: 0.072 kg
5. Core Structural & Design Advantages
- Ultra-slim 15 mm narrow housing: Saves massive DIN rail installation space inside control cabinets, suitable for compact small machine monitoring panels.
- Split electronic-terminal modular structure: Field transmitter signal cables are fixed on the terminal base; no need to disconnect all wiring during module replacement to cut maintenance workload.
- Independent single-channel fault isolation: Fault on one measurement channel will not affect the normal signal collection of other channels, avoiding full monitoring system failure.
- High anti-interference hardware design: Built-in multi-stage filtering and isolation circuits ensure stable measurement data in workshops with high-power frequency conversion equipment.
- Low heat generation industrial circuit layout: Minimal heat accumulation during 24-hour continuous measurement operation, no extra cooling fans required.
- Unified ET 200S platform compatibility: Can be freely combined with all ET 200S series I/O modules without special conversion adapters.
- Standard industrial shock-resistant casing: Adaptable to vibration-intensive production environments such as metal processing and packaging equipment workshops.
6. List of 10 Similar Functional Siemens ET 200S Analog Input Modules
All listed products belong to ET 200S analog input modules for field continuous signal measurement, with split electronic-terminal design and PROFIBUS DP communication; differences lie in channel quantity, supported signal types, intrinsic safety specifications and resolution grades:
- Siemens 6ES7134-4JB01-0AB0: 4-channel intrinsically safe analog input module for Zone 2 hazardous chemical workshops
- Siemens 6ES7134-4FB01-0AB0: 4-channel RTD temperature analog input module for PT100/PT1000 temperature sensors
- Siemens 6ES7134-4GB01-0AB0: Basic 4-channel 4–20 mA analog input module without full channel diagnostic function
- Siemens 6ES7134-4LB02-0AB0: 8-channel high-density 4–20 mA analog input module for multi-point centralized measurement
- Siemens 6ES7134-4NB01-0AB0: 4-channel thermocouple analog input module for high-temperature furnace temperature detection
- Siemens 6ES7134-4EB00-0AB0: 4-channel voltage signal analog input module supporting 0–10 V DC field signals
- Siemens 6ES7134-4GB11-0CB0: SIPLUS wide-temperature anti-corrosion analog input module for humid corrosive workshops
- Siemens 6ES7134-4SB00-0AB0: 4-channel fail-safe analog input module for safety-related process control loops
- Siemens 6ES7134-4MB00-0AB0: 2-channel high-precision analog input module with 16-bit ultra-high resolution
- Siemens 6ES7134-4PB00-0AB0: 4-channel universal analog input module supporting simultaneous voltage and current signal collection
