New Original Siemens 6ES7 132-4HB01-0AB0 6ES7132-4HB01-0AB0 Digital electronic module
"*" indicates required fields
New Original Siemens 6ES7132-4HB01-0AB0 Digital Electronic Output Module
1. Product Overview
The Siemens 6ES7132-4HB01-0AB0 is a brand-new original digital output electronic module belonging to the SIMATIC ET 200S distributed I/O system. It is a 4-channel intrinsically safe digital output module designed for use in explosion-hazardous industrial zones classified as Zone 2, Zone 22 and dust hazardous areas. This module complies with NAMUR intrinsic safety standards and is specially developed to drive low-power intrinsically safe field actuators such as explosion-proof solenoid valves, small explosion-proof signal lamps and intrinsically safe relay coils. With a slim 15 mm modular width, it matches IM151 series PROFIBUS DP interface modules and dedicated ET 200S terminal bases to construct decentralized explosion-proof control systems for chemical plants, pharmaceutical production lines, oil & gas auxiliary equipment and grain processing workshops. It supports hot-swap maintenance without system power cut, transmits control signals between field hazardous area equipment and upper S7 PLC via PROFIBUS DP, and realizes isochronous communication for synchronous process control. The split structure separates the electronic unit and wiring terminal base, so field cables do not need to be reconnected during module replacement, significantly shortening maintenance downtime in hazardous production environments.
2. Main Functions
- 4-Channel Intrinsically Safe 24 V DC Digital Output
Output low-energy control signals certified for explosive atmospheres; each channel provides limited voltage and current to eliminate ignition risks for flammable gas and dust environments.
- NAMUR Intrinsic Safety Compliance
Strictly follows NAMUR standard circuit design to restrict maximum output energy, meeting international explosion-proof safety requirements for Zone 2 / 22 hazardous locations.
- Independent Channel LED Status Indicator
Each output channel is fitted with a dedicated green LED; the indicator lights up when the channel outputs logic 1 to facilitate on-site troubleshooting in explosion-proof cabinets.
- Multi-Layer Channel Protection
Integrates single-channel short-circuit protection, overload protection and reverse polarity protection. Only the faulty channel is disconnected during faults, while other channels remain operational.
- Hot-Swap Replacement Capability
When paired with matched ET 200S terminal modules, the electronic core can be detached and replaced without powering down the entire ET 200S station.
- PROFIBUS DP Isochronous Communication Support
Works under isochronous bus mode to achieve high-precision synchronized output for continuous chemical process control.
- Galvanic Isolation Between Bus and Hazardous Field Side
500 V DC isolation withstand voltage separates the backplane bus circuit and field intrinsically safe circuit, blocking interference from high-power cabinet devices.
- Low Energy Limited Output Circuit
Built-in energy limiting resistors and Zener barriers to avoid electric spark generation even under short-circuit conditions in flammable environments.
- Long-Distance Field Wiring Adaptation
Supports extended shielded cable wiring between the module and explosion-proof field actuators for widely distributed hazardous area equipment.
- Modular System Expansion
Can be stacked with other ET 200S intrinsically safe DI/DO modules and standard I/O modules to flexibly expand the number of explosion-proof control points according to site demands.
3. Technical Characteristics
表格
| Technical Parameter | Specification of 6ES7132-4HB01-0AB0 |
|---|---|
| Full Model Code | 6ES7132-4HB01-0AB0 |
| Product Series | SIMATIC ET 200S Intrinsically Safe Digital Output Module |
| Channel Layout | 4 × Intrinsically Safe Digital Output (DO) |
| Rated Supply Voltage | 24 V DC field supply |
| Maximum Permissible Output Current per Channel | 20 mA (energy limited for intrinsic safety) |
| Explosion-Proof Classification | ATEX II 3G Ex nA IIC T4 Gc; ATEX II 3D Ex tc IIIC T135 °C Dc |
| Applicable Hazardous Zones | Gas Zone 2, Dust Zone 22 |
| Supported Standard | NAMUR intrinsic safety standard, IEC 61241, IEC 60079 |
| Max Switching Frequency (Resistive Intrinsic Safe Load) | 100 Hz |
| Internal Protection | Single-channel short-circuit, overload, reverse polarity protection |
| Backplane 3.3 V DC Bus Current Consumption | Max 14 mA |
| Typical Module Power Dissipation | 1.4 W |
| PLC Address Occupation | 1 byte output address space |
| Communication Bus | PROFIBUS DP (cooperates with IM151 interface modules) |
| Isochronous Mode | Supported |
| Isolation Withstand Voltage | 500 V DC between bus side and field intrinsically safe circuit |
| Channel Diagnostic | No wire break diagnostic function |
| Visual Indication | 4 independent green channel LED indicators |
| Protection Class | IP20 (installation inside explosion-proof electrical cabinets only) |
| Operating Ambient Temperature | 0 °C ~ +60 °C |
| Storage & Transport Temperature | -40 °C ~ +70 °C |
| Global Certifications | CE, UL, ATEX explosion-proof certification |
| Matching Accessories | Special ET 200S intrinsic safety terminal modules |
4. Product Dimensions & Weight
4.1 Overall Module Dimensions
表格
| Dimension Item | Exact Measurement |
|---|---|
| Module Width | 15 mm |
| Module Height | 81 mm |
| Module Depth | 52 mm |
4.2 Weight Specifications
- Net weight of single electronic module (excluding terminal base): 0.045 kg
- Gross weight with original individual packaging carton: 0.069 kg
5. Core Structural & Design Advantages
- Ultra-slim 15 mm narrow housing: Consumes minimal DIN rail space inside explosion-proof cabinets, suitable for compact hazardous area control panels.
- Split electronic-terminal modular design: Eliminates the need to disconnect all field intrinsically safe cables during module replacement, lowering maintenance risks in explosive environments.
- Strict energy-limiting intrinsic safety circuit: Prevents spark formation under all normal and fault operating conditions, fully compliant with chemical and petrochemical industry safety standards.
- Independent single-channel fault isolation: Local short-circuit or overload will not trigger full module shutdown, ensuring continuous operation of other process control loops.
- Unified ET 200S system compatibility: Seamlessly combined with all ET 200S intrinsically safe input modules and standard I/O modules without extra conversion adapters.
- Reinforced anti-vibration casing: Resists mechanical vibration in chemical processing workshops and outdoor explosion-proof cabinet installations.
- Low heat generation electronic layout: Reduces heat accumulation inside sealed explosion-proof cabinets without auxiliary cooling fans.
6. List of 10 Similar Functional Siemens ET 200S Intrinsic Safety Digital I/O Modules
All listed products belong to ET 200S intrinsically safe explosion-proof I/O modules with split electronic-terminal structure and PROFIBUS DP communication, designed for Zone 2 / 22 hazardous locations; differences lie in signal type, channel count and safety specifications:
- Siemens 6ES7131-4HB01-0AA0: 4-channel NAMUR intrinsically safe digital input module for explosion-proof sensor signal collection
- Siemens 6ES7132-4HB00-0AB0: 4-channel intrinsically safe DO base model without extended temperature tolerance
- Siemens 6ES7131-4JB00-0AB0: 8-channel intrinsically safe digital input module for high-density hazardous area signal acquisition
- Siemens 6ES7132-4LB00-0AB0: 4-channel fail-safe intrinsically safe output module for PL e safety interlock circuits
- Siemens 6ES7134-4FB01-0AB0: 4-channel intrinsically safe analog input module for explosion-proof temperature and pressure transmitters
- Siemens 6ES7135-4FB01-0AB0: 2-channel intrinsically safe analog output module for explosion-proof regulating valves
- Siemens 6ES7131-4HB01-0CB0: Low-temperature wide-range intrinsically safe DI module for cold storage hazardous workshops
- Siemens 6ES7132-4HB02-0AB0: 4-channel high-frequency intrinsically safe DO module for fast switching explosion-proof valves
- Siemens 6ES7131-4MB00-0AB0: 4-channel intrinsically safe DI supporting both NAMUR and dry contact sensors
- Siemens 6ES7132-4HB01-0DB0: Dust explosion optimized intrinsically safe output module for grain and powder processing plants
