Product Overview
The Siemens 3RV1021‑4BA10 (order reference 3ZX1012‑0RV01‑1AA1) is a brand‑new original SIRIUS‑series 3‑pole motor protection circuit breaker (MPCB) in S0 frame size. It integrates thermal overload release and magnetic short‑circuit release for three‑phase asynchronous motor protection. The adjustable thermal setting range is 14‑20 A, suitable for 7.5 kW three‑phase motors under 400 V AC supplyState Elec…. Widely applied in fan, pump, conveyor, machine‑tool and packaging‑machine motor feeder circuits. Marked as “New Original”, it means genuine factory‑manufactured unit with full‑factory function testing, intact bimetallic strips and magnetic trip assemblies, free of refurbished or second‑hand products. It can perform manual motor switching as well as overload and short‑circuit fault interruption in one compact device。
Main Functions
- Dual‑protection thermomagnetic trip: Thermal bimetallic overload protection and instantaneous magnetic short‑circuit protection for three‑phase motors.
- Adjustable overload current dial: Continuous setting from 14 A to 20 A to match motor rated full‑load current.
- Class 10 overload trip characteristic: Standard motor trip class for general‑purpose asynchronous motors.
- Rotary operating handle: ON/OFF manual switching, visible trip indication, padlock‑capable for lock‑out tag‑out maintenance.
- Built‑in test function: Manual test button to verify mechanical tripping performance on site.
- Modular expandable design: Supports external auxiliary contact blocks, fault‑signal contacts and shunt‑trip accessories.
- Two installation options: 35 mm DIN‑rail snap‑on mounting or direct screw panel mounting, any installation orientation allowed.
- High short‑circuit breaking capacity: Quickly cuts short‑circuit faults to protect downstream motor and wiring.
Technical Characteristics
- S0 compact frame size, screw‑type main circuit terminals, finger‑safe IP20 terminal protectionRS.
- Trip class Class 10; magnetic short‑circuit instantaneous trip at approx. 12×max setting current.
- High breaking capacity: 55 kA at 400 V AC, 100 kA at 240 V AC.
- Mechanical service life up to 100 000 switching cycles for frequent‑start motor applicationsState Elec….
- Surge voltage withstand 6 kV, pollution degree 3 for industrial control cabinet environment.
- Complies with IEC 60947‑2, IEC 60947‑4‑1 standards; CE, UL, CSA certified.
- RoHS‑compliant flame‑retardant plastic housing.
- No built‑in auxiliary contacts; auxiliary switches need separate accessory installation.
Core Technical Parameters
| Item | Parameter Value |
|---|---|
| Part Number | 3RV1021‑4BA10, Reference 3ZX1012‑0RV01‑1AA1 |
| Product Type | 3‑pole motor protection circuit breaker (MPCB), SIRIUS S0 frame |
| Thermal Overload Setting Range | 14 A … 20 A |
| Rated Operational Voltage | Up to 690 V AC, 50‑60 Hz |
| Rated Motor Power (400 V AC) | 7.5 kW |
| Trip Characteristic | Thermal Class 10, magnetic instantaneous short‑circuit trip |
| Short‑circuit Breaking Capacity(Icu) | 55 kA @400 V AC |
| Mounting | 35 mm DIN‑rail / screw direct mounting |
| Terminal Type | Screw terminal |
| Ambient Operating Temperature | ‑20 °C ~ +60 °C (non‑condensing)RS |
| Protection Class | IP20 (cabinet‑mount device)State Elec… |
| Weight | 0.36 kg |
Product Dimensions
All dimension values are given in millimetres:
- Overall height: 97 mm
- Overall width: 45 mm
- Overall depth: 96 mm
- Main‑circuit terminal screw size: M4
- DIN‑rail compatible width: 45 mm
Note: Install inside electrical cabinet. Adjust current dial strictly according to motor nameplate rated current. Padlock the rotary handle for maintenance lock‑out.
10 Siemens Similar‑function SIRIUS 3RV‑series Motor Protection Circuit Breakers
Below are ten original Siemens 3RV‑series motor‑protection circuit breakers covering different current ranges and frame sizes for motor‑feeder applications:
- 3RV1021‑1BA10: 1.4‑2 A adjustable, S0 frame, for small‑power three‑phase motor protection.
- 3RV1021‑1CA10: 2‑2.8 A thermal setting range, S0 size thermomagnetic MPCB.
- 3RV1021‑1EA10: 2.8‑4 A, S0 frame, manual motor starter‑protector.
- 3RV1021‑1GA10: 4‑6 A adjustable overload current for low‑power motors.
- 3RV1021‑1JA10: 6‑10 A, S0‑frame motor‑protection circuit breaker.
- 3RV1021‑4DA10: 18‑25 A, S0‑frame high‑current variant for higher‑power motors.
- 3RV1011‑1KA10: 9‑12 A, compact S00 frame size for narrow cabinet installation.
- 3RV2021‑4BA10: New‑generation 3RV2 series, 14‑20 A S0‑frame upgraded‑version MPCB.
- 3RV1031‑4EA10: 22‑32 A, S2 frame for medium‑power heavy‑duty motor feeders.
- 3RV1041‑4FA10: 28‑40 A, S3 large‑frame motor‑protection circuit‑breaker for high‑power motors.
