New Original Siemens 1FL6061-1AC61-2LA1 SINAMICS V90 Servo Drive
"*" indicates required fields
New Original Siemens 1FL6061-1AC61-2LA1 SINAMICS V90 Servo Motor Full Introduction
1. Product Overview
The 1FL6061-1AC61-2LA1 is a low-inertia single-turn absolute encoder servo motor belonging to the Siemens SINAMICS V90 servo system series, matched exclusively with SINAMICS V90 servo drives for positioning, speed and torque control applications. This original Siemens servo motor is designed for general automation machinery with low to medium dynamic performance demands, featuring compact mechanical structure, stable running precision and simple wiring debugging. It is widely applied in packaging equipment, textile machinery, small CNC machine tools, electronic assembly equipment, logistics conveying lines and 3C automated processing lines. The model integrates a 20-bit single-turn absolute encoder, which can retain position data without battery power supply, eliminating zero point re-calibration after power failure and greatly improving production continuity. It supports matching pulse version and PN PROFINET version SINAMICS V90 drives to realize multi-mode motion control.
2. Main Functions
- High-precision position closed-loop control, positioning accuracy up to 0.001°
- Three control modes switchable freely: position control, speed control, torque control
- Built-in single-turn absolute encoder, power-off position memory function without backup battery
- Low torque fluctuation design, stable operation at ultra-low speed without jitter
- Overload, overvoltage, undervoltage, overheat, encoder fault multi-layer self-protection function
- Electronic gear ratio function, flexible matching mechanical transmission reduction ratio
- Support pulse signal and PROFINET industrial bus communication two control interfaces
- Built-in holding brake option for vertical axis anti-drop positioning
- Smooth S-curve acceleration and deceleration to reduce mechanical impact and vibration
- Parameter quick copying function, convenient for batch equipment debugging and replacement
3. Technical Specifications
Table 1 Core Technical Parameters
表格
| Parameter Item | Technical Data of 1FL6061-1AC61-2LA1 |
|---|---|
| Rated Power | 0.4 kW |
| Rated Torque | 1.27 N·m |
| Rated Speed | 3000 r/min |
| Maximum Speed | 4000 r/min |
| Peak Torque | 3.82 N·m |
| Encoder Type | Single-turn absolute encoder, 20-bit |
| Brake Configuration | Without holding brake |
| Shaft Type | Smooth shaft without keyway |
| Rated Voltage | 230 V AC single/three phase |
| Rotor Inertia | 0.12 kg·cm² |
| Protection Grade | IP64 (motor body), IP54 for connector |
| Ambient Operating Temperature | 0 ℃ ~ +40 ℃ |
| Cooling Mode | Natural air cooling |
4. Product Dimension & Weight
Table 2 Dimension and Weight Information
表格
| Item | Specific Data |
|---|---|
| Motor Flange Size | 60 mm × 60 mm square flange |
| Motor Overall Length | 117 mm |
| Shaft Diameter | 14 mm |
| Mounting Hole Spacing | 45 mm × 45 mm |
| Net Weight (Single Motor) | 1.9 kg |
| Gross Weight (Original Individual Packaging) | 2.4 kg |
| Installation Form | Flange vertical / horizontal universal installation |
5. Core Technical Features
- Low inertia rotor design, fast dynamic response, short acceleration and deceleration time, suitable for high-frequency start-stop working conditions
- Single-turn absolute encoder cancels battery maintenance, reduces equipment failure rate and later maintenance cost
- Fully sealed motor casing, dust and splash water resistant, adaptable to workshop complex production environment
- Optimized magnetic circuit design, low energy consumption and high operating efficiency, saving long-term power cost
- Standard Siemens unified wiring connector, plug-and-play, effectively reduce wiring error rate
- Compatible with all standard SINAMICS V90 drive models, strong system compatibility, convenient spare parts stock management
- Compact miniaturized structure, save equipment internal installation space, facilitate miniaturization of automated equipment
- Standard original Siemens industrial grade motor, long service life, stable performance under continuous 24-hour operation
