New Original Omron H3DT-F H3DT Series DIN Rail Timer Relay
"*" indicates required fields
New Original Omron H3DT-F H3DT Series DIN Rail Timer Relay
1. Product Overview
The H3DT-F is an authentic brand-new DIN rail mounted timer relay belonging to Omron’s H3DT universal time delay relay lineup, developed for industrial automation timing logic control. This compact timing component adopts standard 35 mm DIN rail installation structure, designed for control cabinets, PLC peripheral matching, motor startup delay, lighting timing, equipment sequential operation and automated assembly line timing workflows.
H3DT-F integrates multi-mode timing functions, wide-range input voltage compatibility and stable mechanical contact output. It supports flexible delay time setting via front panel knobs and DIP switches, with strong anti-interference performance to adapt to harsh industrial environments including workshop electromagnetic interference, temperature fluctuation and vibration. As a core timing control unit, it separates power input and signal output circuits to achieve electrical isolation, and all original units comply with international safety and electrical performance standards for industrial low-voltage control.
2. Main Functions
- Multi-mode time delay control: Cover power-on delay, power-off delay, signal trigger delay and interval timing modes to satisfy diverse automation logic requirements.
- Standard DIN rail snap-on mounting: Quick installation and disassembly without extra fixed brackets inside electrical control cabinets.
- Adjustable wide timing range: Continuous time parameter tuning from milliseconds to hours via front rotary knob and DIP switch combination.
- Dual isolation output contacts: Independent relay contact terminals to drive small AC/DC loads such as contactor coils, indicator lamps and auxiliary valves.
- Universal wide voltage power supply: Compatible with multiple AC and DC supply voltages to reduce spare part inventory for equipment manufacturers.
- Visible working status indication: Built-in LED status light to display power supply, timing running and contact actuation states in real time.
- Anti-interference circuit design: Internal surge absorption circuit suppresses coil reverse electromotive force from peripheral contactors.
- Manual parameter reset function: One-click reset of timing cycle to restart timing procedures during equipment debugging.
- Wide ambient temperature adaptability: Maintain stable timing accuracy under low-temperature cold storage and high-temperature enclosed control cabinets.
- Modular compact structure: Small body size saves internal cabinet layout space compared to large independent timing controllers.
3. Technical Characteristics
| Technical Parameter | Detailed Specification |
|---|---|
| Product Model | H3DT-F (H3DT Series Timer Relay) |
| Installation Method | 35 mm standard DIN rail mounting |
| Timing Modes | Power-on delay, Signal delay, Flashing interval delay, Power-off delay |
| Standard Timing Ranges | 0.1 s ~ 1 s, 1 s ~ 10 s, 10 s ~ 1 min, 1 min ~ 10 min, 10 min ~ 1 h |
| Supply Voltage Options | AC24V, AC100~240V, DC12V, DC24V |
| Rated Power Consumption | Max. 2.5 VA (AC); Max. 1.2 W (DC) |
| Contact Configuration | 1 Form C (SPDT, normally open + normally closed) |
| Rated Contact Load | 5 A 250 VAC resistive load; 3 A 30 VDC resistive load |
| Timing Accuracy | ±1% of full scale setting (25°C reference temperature) |
| Insulation Resistance | Minimum 1000 MΩ (500 VDC measurement) |
| Dielectric Withstand Voltage | 2000 VAC between power circuit and contact circuit for 1 minute |
| Mechanical Service Life | 10,000,000 contact switching cycles |
| Electrical Service Life (5 A load) | 100,000 contact switching cycles |
| Operating Ambient Temperature | -20 °C ~ +55 °C |
| Storage Temperature Range | -40 °C ~ +70 °C |
| Vibration Resistance | 10 ~ 55 Hz, 0.75 mm amplitude, 2 hours each axis |
| Shock Resistance | 100 m/s², 6 directions, 10 times per direction |
| Safety Certifications | UL, CSA, VDE, CE industrial control compliance |
4. Product Dimensions and Weight
4.1 External Overall Dimensions Table
| Dimension Item | Exact Measurement |
|---|---|
| Total Width | 17.5 mm |
| Total Height | 90 mm |
| Total Depth (Cabinet Insertion) | 60 mm |
| DIN Rail Matching Width | Standard 35 mm top hat rail |
| Terminal Spacing | 5 mm uniform terminal pitch for wiring |
4.2 Weight Data
- Single bare unit net weight: 42 grams
- Single unit with original plastic packaging: 48 grams
5. Core Technical Advantages
- Ultra-narrow 17.5 mm width: Occupies minimal cabinet rail space, supports dense modular arrangement of multiple timing relays.
- All-in-one multi-timing modes: Single device replaces multiple single-function delay timers to cut component purchasing costs.
- Wide universal power voltage version: One model adapts to global equipment power standards for export machinery.
- Independent SPDT switching contact: Simultaneous control of two opposite logic circuits with one output terminal group.
- Front accessible adjustment components: Knob and DIP switches on front panel allow parameter modification without removing the relay from DIN rail.
- Dust-resistant sealed front housing: Prevents metal powder and workshop dust from entering internal timing circuits.
- Low power consumption design: Reduces long-term cabinet heat generation during continuous 24-hour operation.
- Clear LED indicator system: Rapid fault diagnosis for equipment maintenance technicians.
6. Ten Omron Similar-Function DIN Rail Timer Relay Products
All items below are original Omron DIN rail mount timing relays with identical core applications: industrial sequential delay control, cabinet installation, contact output timing logic regulation
- Omron H3DT-A
Basic power-on delay timer relay of H3DT series, single fixed timing mode, same 17.5 mm narrow DIN rail size.
- Omron H3DT-B
Signal trigger delay dedicated timer, optimized for sensor input trigger timing control, SPDT contact output.
- Omron H3DT-C
Flashing cycle interval timer, auto-repeating timing function for warning lamp and intermittent conveyor control.
- Omron H3DT-D
Power-off delay special timer, maintains timing function after main power supply cut-off for motor braking control.
- Omron H3DT-F2
Enhanced H3DT-F variant with extended maximum timing range up to 10 hours, wide AC/DC dual power input.
- Omron H3DK-M1
Classic multi-mode DIN rail timer relay, wider 22.5 mm rail width, larger adjustable timing range options.
- Omron H3DK-S1
Short millisecond-level precision delay timer, dedicated for high-speed automated machine signal timing.
- Omron H3DK-G
Star-delta motor startup delay timer, preset special timing curve for three-phase motor soft start control.
- Omron H3YN-2
Compact miniature DIN rail timer, ultra-slim 12.5 mm width for ultra-dense cabinet layout.
- Omron H5CX-A
Digital display DIN rail timer relay with numerical screen, precise digital time setting instead of mechanical knobs.
