New Original Omron G6D-1A-ASI General Purpose Relay
"*" indicates required fields
New Original Omron G6D-1A-ASI General Purpose Relay
1. Product Overview
The G6D-1A-ASI is a brand-new original general-purpose electromagnetic relay manufactured by Omron, a world-leading industrial automation and electronic component brand. This series belongs to the compact low-power signal relay category, specially designed for PCB mounting applications in industrial control panels, household appliances, smart equipment, automotive auxiliary control circuits and small automated machinery.
It adopts a single-pole normally open (1A) contact structure with built-in surge absorption diode marked ASI, which effectively suppresses reverse electromotive force generated by coil power-off to protect peripheral control chips and circuit boards. The relay features ultra-small body size, stable switching performance, low coil power consumption and high contact reliability, meeting the universal low-load switching demands of DC and AC weak current circuits. All units are 100% original factory production with complete insulation certification and long mechanical & electrical service life.
2. Main Functions
- Low-power signal switching: Realize on-off control of small AC/DC load currents on printed circuit boards.
- Coil surge suppression: Integrated built-in diode absorbs coil back EMF to avoid damage to PLC, MCU and drive ICs.
- Isolation control: Form electrical isolation between low-voltage control coil and high-current load circuit to prevent circuit interference.
- Universal load matching: Compatible with resistive, inductive and lamp small loads for multi-scenario control.
- PCB direct soldering: Through-hole pin design for stable welding on standard circuit boards without additional fixing brackets.
- Overload & insulation protection: High dielectric withstand voltage between coil and contacts to resist short-circuit leakage.
- Long-cycle repeated switching: Support frequent continuous on-off operation for automated cycle control equipment.
3. Technical Characteristics
表格
| Technical Item | Specific Parameter |
|---|---|
| Contact Configuration | 1 Form A (Single Pole Normally Open, SPNO) |
| Rated Contact Load | 5A 250VAC; 5A 30VDC |
| Minimum Switching Load | 1mA 5VDC |
| Standard Coil Voltage Options | 5VDC, 12VDC, 24VDC |
| Coil Rated Power | 400mW |
| Contact Resistance (Initial Max.) | 100mΩ |
| Insulation Resistance | Min. 1000MΩ (500VDC Megger) |
| Dielectric Withstand Voltage (Coil to Contact) | 5000VAC 1min |
| Surge Absorption Device | Built-in Freewheeling Diode (ASI version exclusive) |
| Mechanical Life | 100,000,000 operations |
| Electrical Life (5A Resistive Load) | 100,000 operations |
| Operating Temperature Range | -40°C to +70°C |
| Vibration Resistance | 10 to 55Hz, 1.5mm double amplitude |
| Shock Resistance | 100m/s² (Functional); 1000m/s² (Destruction) |
| Operation Time | Max. 10ms |
| Release Time | Max. 5ms |
| Safety Certification | UL, CSA, VDE certified |
4. Product Dimension & Weight
4.1 Overall External Dimensions
表格
| Dimension Parameter | Exact Size |
|---|---|
| Overall Length | 28.5 mm |
| Overall Width | 10.2 mm |
| Overall Height | 12.5 mm |
| Pin Pitch (Horizontal) | 5.0 mm standard PCB pitch |
| Pin Length (Soldering Section) | 3.5 mm |
4.2 Net Weight
Single unit net weight: 6.8 grams
Packaged single piece weight (with plastic tray): 8.2 grams
5. Core Advantages & Technical Highlights
- Compact miniaturized structure: Save PCB layout space compared to medium-size power relays.
- ASI built-in diode design: No external flyback diode required, simplify circuit layout and reduce component count.
- Low coil power consumption: Only 400mW coil power, suitable for battery-powered portable control devices.
- High dielectric strength 5kV isolation: Meet industrial EMC anti-interference standards for cabinet control systems.
- Stable contact material: Silver alloy contact material, anti-oxidation and anti-arcing under frequent switching.
- Sealed plastic housing: Dustproof construction, adapt to ordinary industrial workshop environment without extra sealing treatment.
- Wide temperature working range: Stable performance under low-temperature cold storage equipment and high-temperature cabinet operation.
6. Ten Similar-Function Omron General-Purpose PCB Relays
All listed products are Omron original signal/PCB power relays with identical core application (PCB mounting, small load switching, industrial & appliance control):
- Omron G6D-1A
Base model of G6D series, SPNO contact, without built-in surge suppression diode, same dimension as G6D-1A-ASI.
- Omron G6D-1A-DC5
5V DC coil version of G6D-1A, separate discrete diode needed for coil surge protection.
- Omron G6D-1A-ASI-DC12
12V coil variant of the target G6D-1A-ASI relay with integrated freewheeling diode.
- Omron G6D-2A
Dual SPNO contact structure, double switching channels, same compact housing size.
- Omron G6D-2A-ASI
Two normally open contacts with built-in anti-surge diode for dual-circuit control.
- Omron G6B-1114P
Ultra-compact general-purpose PCB relay, 5A contact load, through-hole pin mounting.
- Omron G6B-2114P
Dual-channel signal relay, low coil power, widely used in PLC module auxiliary circuits.
- Omron G2R-1-E
Medium-size general-purpose power relay, 10A contact load, industrial cabinet control mainstream model.
- Omron G2R-2-E
Two-pole normally open contact power relay, high current carrying capacity for equipment main circuit control.
- Omron G3M-202PL
Solid-state PCB relay alternative, non-contact silent switching for high-frequency repeated control scenarios.
