New‑Original Festo 564212 VUVG‑L10‑M52‑RZH‑M5‑1L2L Air Solenoid Valve
1. Product Overview
VUVG‑L10‑M52‑RZH‑M5‑1L2L (Part‑No:564212) belongs to Festo high‑performance VUVG‑L10 series inline‑type pilot‑operated air solenoid valve, a brand‑new original directional control component for automated pneumatic‑control systems. It adopts 5/2‑way monostable single‑solenoid structure with external pilot air supply and pneumatic‑spring return design. This component switches airflow direction to drive small‑size pneumatic cylinders, clamps and actuators widely applied in assembly equipment, packaging machinery, electronic‑product processing and automated‑production lines. It works with filtered compressed‑air following ISO‑8573‑1‑2010 [7:4:4] and supports long‑term continuous‑duty‑cycle operation. The whole‑valve assembly matches Festo VTUG‑series valve‑terminal manifolds for centralized installation and circuit‑management.
2. Main Functions
- Air‑flow switching: Realize air‑supply and exhaust switching of port‑2 and port‑4 under 24 V‑DC solenoid‑signal control. When energized, port‑1 connects to port‑4 and port‑2 links to port‑3; after power‑off, pneumatic‑spring resets internal spool so port‑1 connects to port‑2 and port‑4 connects to port‑5.
- External pilot‑air control (RZH = external pilot): Independent external pilot‑air inlet allows this valve to work under low working‑pressure conditions and even vacuum‑negative‑pressure environment, which internal‑pilot‑type valves cannot achieve.
- Manual override function: Non‑detent manual‑override button for manual‑commissioning during equipment debugging without electric‑signal input.
- Signal indication: Built‑in LED indicator shows solenoid energized‑status for quick‑failure‑diagnosis.
- Compatibility: Can be installed individually or assembled on VTUG‑series manifold base for multi‑valve modular combination.
3. Technical Characteristics
- Internal structure: Piston‑spool‑type valve with soft HNBR and NBR composite‑sealing design to reduce internal‑leakage and extend service lifeFesto.
- Electrical configuration: Rated coil voltage 24 VDC, power‑consumption 1.0 W; permitted voltage fluctuation ±10 %, 3‑pin M8‑A‑coded plug conforming to EN‑61076‑2‑104 for electrical‑connectionFesto.
- Working‑pressure range: Working‑pressure −0.09 MPa‑0.8 MPa; pilot‑air pressure range 0.25‑0.8 MPa.
- Switching‑performance: Switch‑on time 8 ms; switch‑off time 17 ms; maximum switching‑frequency 3 Hz, 100‑% continuous‑duty‑cycle available without coil over‑heating费斯托.
- Environmental adaptability: Ambient‑temperature range −5 ℃‑60 ℃; medium‑temperature −5 ℃‑60 ℃; protection‑grade IP40 when fitted with standard plug‑socket.
- Physical‑resistance: Pass shock‑and‑vibration‑test of severity‑level‑2 according to FN‑942017‑5 and EN‑60068‑2‑27; corrosion‑resistance class CRC‑2 for moderately‑corrosive‑factory‑environment; fully RoHS‑compliant without harmful substancesFesto.
- Housing‑material: Anodized wrought‑aluminum‑alloy; seal‑material HNBR / NBR rubber with good oil‑resistance and anti‑aging‑performance.
4. Dimensions and Weight
| Item | Parameter Value |
|---|---|
| Overall length | 48 mm |
| Overall width | 10.5 mm (grid‑size L10 series) |
| Overall height | 32 mm |
| Pneumatic‑thread size | Port‑1‑2‑3‑4‑5 all adopt M5 female‑thread |
| Pilot‑port size | Separate M5 female‑thread for external pilot‑air supply |
| Net‑weight of single‑valve unit | 45 g |
| Mounting‑method | Install on manifold‑rail or fixed via through‑holes |
| Standard nominal‑flow rate | 220 L/min in accordance with DIN‑1343 standardFesto |
5. Ten Festo alternative products with similar‑function (5/2‑way monostable, L10‑size solenoid‑valve)
All listed models are original Festo VUVG‑series products with identical L10 grid‑size, 24VDC coil and 5/2‑way monostable function for substitution selection:
- VUVG‑L10‑M52‑RT‑M5‑1P3 (Part‑No:566457): Internal‑pilot type, mechanical‑spring reset, M5 thread‑port, 220 L/min flow rate, IP40 protection gradeFesto.
- VUVG‑L10‑M52‑MT‑M5‑1R8L (Part‑No:8031468): Internal‑pilot design, non‑detent manual‑override, coil‑power‑1.0 W, standard‑DIN‑1343 flow‑rate 220 L/minFesto.
- VUVG‑LK10‑M52‑AT‑M5‑1R8L‑S (Part‑No:589281): Pneumatic‑spring‑reset structure, internal‑pilot‑supply, optional adjustable‑exhaust‑throttle‑valve, flow‑rate 195 L/minFesto.
- VUVG‑L10‑M52‑RZT‑M5‑1T1L (Part‑No:573392): External‑pilot type same as original item; detent‑type manual‑override, max switching‑frequency‑3 Hz, −0.09‑0.8 MPa working‑pressure range费斯托.
- VUVG‑L10‑M52‑MH‑Q6‑1R8L (Part‑No:564214): In‑line‑valve structure, push‑in‑connector‑6‑mm instead of M5‑thread, internal‑pilot‑air‑supply, mechanical‑spring‑reset.
- VUVG‑L10‑M52‑RT‑M7‑1P3 (Part‑No:566474): Port‑thread upgraded to M7‑size, nominal‑flow‑rate‑330 L/min, internal‑pilot‑type, IP65‑optional with special‑plug‑socketFesto.
- VUVG‑L10‑M52‑MT‑M5‑1H2L‑W1 (Part‑No:578162): Wide‑temperature‑version, support clean‑room‑class‑ISO14644‑1‑Class‑5 environment; passed LABS‑PWIS‑VDMA‑24364‑B1‑B2‑L certificationFesto.
- VUVG‑LK10‑M52‑AT‑M7‑1R8L‑S (Part‑No:8042543): M7‑thread‑ports, exhaust‑air‑adjustable‑throttle‑function, coil‑power‑0.8 W for energy‑saving applicationFesto.
- VUVG‑L10‑B52‑T‑M5‑1H2L‑W1 (Part‑No:577317): Double‑solenoid‑5/2‑way version with same L‑10 outline‑dimension; can be used when latching‑function is requiredFesto.
- VUVG‑L10‑M52‑RZH‑M5‑1R8L‑W1 (Part‑No:564213): External‑pilot‑type same‑structure as original‑564212‑model, detent‑manual‑override‑button for frequent‑manual‑operation scenarios.
6. Application Notes
- Use only dry and filtered compressed‑air; lubricated‑air is allowed, but continuous‑lubrication must be maintained after initial‑lubrication.
- Do not exceed 0.8 MPa maximum‑working‑pressure to avoid damage of internal‑spool‑components.
- When adopting external‑pilot‑air‑supply for VUVG‑L10‑M52‑RZH‑M5‑1L2L, the pilot‑air source must be independent and stable.
- The valve can be mounted in any orientation without performance‑reduction.
