New Original CAREL RITCUSRG02 Digital Cabinet Temperature Controller
"*" indicates required fields
New Original CAREL RITCUSRG02 Digital Cabinet Temperature Controller
1. Product Overview
The CAREL RITCUSRG02 is a compact digital cabinet temperature controller co-developed for electrical enclosure thermal management. It adopts microprocessor-based control logic, supporting NTC temperature sensor input and relay switching output to manage cabinet cooling fans or heating units. Equipped with LED digital display and front operation buttons, this unit maintains stable internal temperature for electrical cabinets, switchgear and automation control enclosures, preventing condensation and overheating risks. The delivered unit is brand-new original genuine CAREL product.
2. Main Technical Specifications
| Item | Parameter |
|---|---|
| Model | RITCUSRG02 |
| Product Type | Digital Cabinet Temperature Controller |
| Supported Sensor | CAREL NTC temperature probe |
| Control Mode | ON/OFF temperature control |
| Power Supply | 24 V AC / DC |
| Control Output | Electromechanical relay output |
| Display | LED digital temperature readout |
| Operation Interface | Front membrane push buttons |
| Mounting Method | Panel flush mounting |
| Front Panel Protection | IP54 |
| Overall Dimensions (W × H × Depth) | 75 mm × 33 mm × 62 mm |
| Panel Cutout Size | 71 mm × 29 mm |
| Operating Ambient Temperature | -10 °C ~ +50 °C |
| Storage Temperature | -20 °C ~ +70 °C |
| Relative Humidity | 5% ~ 90% RH, non-condensing |
| Net Weight | Approx. 120 g |
| Compliance Standards | CE, RoHS, EN 60730 |
3. Main Functions
- Collect real-time temperature inside electrical cabinets via NTC probe and activate fan or heater loads by ON/OFF logic.
- LED display continuously shows measured temperature for intuitive on-site monitoring.
- Front keypad allows quick setting of target temperature, switching differential and alarm thresholds.
- Built-in power-off memory retains all configured parameters after power interruption.
- Support anti-short-cycle delay function to extend service life of cooling and heating components.
- Configurable temperature alarm function to notify abnormal overheating or ultra-low temperature conditions.
- Widely applied for temperature regulation of Rittal electrical cabinets, automation switchgear and outdoor control enclosures.
4. Technical Features
- Slim compact housing saves limited panel installation space inside electrical cabinets.
- Optimized control algorithm reduces frequent relay switching and improves system stability.
- Standard panel cutout dimension compatible with mainstream electrical cabinet mounting frames.
- IP54 front panel prevents dust and light splash water inside control room environments.
- Simple button operation lowers commissioning difficulty for field maintenance personnel.
- Self-extinguishing plastic housing enhances safety under long-term continuous operation.
- Screw terminal wiring structure facilitates circuit inspection and equipment replacement.
- Basic anti-electromagnetic interference design adapts to environments with inverters and contactors.
- Wide allowable working humidity range resists condensation risks inside sealed cabinets.
- Matches standard CAREL NTC probes for unified spare part inventory management.
5. 10 CAREL Similar Digital Temperature Controllers
- RITCUSRG01, Digital cabinet temperature controller, basic version without extended alarm function
- PZRIX0H003, PZR series compact digital thermostat for refrigeration and small HVAC equipment
- IR33W7HR20, IR33 multifunctional digital temperature controller for refrigerated cabinets
- PJEZS0H000, EASY PJEZ series compact thermostat for display freezer temperature control
- RITCUSR0N1, Cabinet temperature controller supporting dual probe input for temperature monitoring
- PZRI0H0L03, Low voltage 24 V AC/DC PZR series digital temperature controller
- IR32V00000, Miniature IR32 digital thermostat for compact electrical enclosures
- PZRIX0H013, PZR controller with auxiliary relay output for fan and alarm control
- UC2SE, Universal digital controller for chiller and heat pump auxiliary temperature management
- EVD0000T40, Electronic expansion valve driver with integrated temperature monitoring function
