New Original BANNER QS18VP6LV QS18 Series Non-Polarized Retroreflective Photoelectric Sensor
"*" indicates required fields
New Original BANNER QS18VP6LV QS18 Series Non-Polarized Retroreflective Photoelectric Sensor
1. Product Overview
The Banner QS18VP6LV belongs to the WORLD-BEAM QS18 series non-polarized retroreflective photoelectric sensor. Equipped with visible red LED light source, it achieves a maximum sensing distance of 6.5 meters when matched with standard reflector. This unit features complementary PNP solid-state output and 2-meter fixed cable connection. Different from polarized retroreflective types, it supports general reflector installation without polarization restriction. It is widely deployed on automated assembly lines, conveyor systems, packaging machinery and material handling equipment for object detection, workpiece counting and travel limit monitoring. The delivered unit is brand-new original genuine Banner product.
2. Main Technical Specifications
| Item | Parameter |
|---|---|
| Model | QS18VP6LV |
| Series | WORLD-BEAM QS18 Photoelectric Sensor |
| Sensing Mode | Non-Polarized Retroreflective |
| Light Source | Visible Red LED |
| Maximum Sensing Distance | 6500 mm (6.5 m) |
| Supply Voltage | 10 V DC ~ 30 V DC |
| Output Type | Complementary PNP, Light-ON / Dark-ON selectable |
| Max Load Current | 100 mA |
| Response Time | 0.6 ms |
| Electrical Connection | 2 m fixed cable |
| Built-in Protection | Reverse polarity protection, overload and short-circuit protection |
| Enclosure Rating | IP67, NEMA 6 |
| Housing Material | Reinforced ABS thermoplastic |
| Status Indicator | Dual LED indicators: green for power, amber for output signal |
| Operating Temperature | -20 °C ~ +70 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Mounting Standard | M18 threaded mounting base |
| Overall Dimensions (L × W × H) | 35 mm × 15 mm × 31 mm |
| Net Weight | Approx. 52 g |
| Compliance Standards | CE, RoHS |
3. Main Functions
- Detect object presence via non-polarized retroreflective optical path with standard reflector.
- Convert received optical signals into digital PNP switching signals to trigger PLC input modules and relays.
- Support Light-ON and Dark-ON operation modes to satisfy different automatic control logic requirements.
- Visible red light beam helps engineers complete quick alignment and calibration during on-site commissioning.
- Dual LED indicators display power status and switching output status for convenient inspection and troubleshooting.
- Built-in single-turn potentiometer allows sensitivity adjustment to adapt to different target surface conditions.
- Realize workpiece counting, position feedback and safety limit detection for continuous automated production equipment.
4. Technical Features
- Compact rectangular housing with standard M18 thread, compatible with universal mounting brackets and lock nuts.
- Non-polarized optical design works with ordinary reflectors, reducing spare part procurement limits.
- Long 6.5 m sensing range meets medium-distance detection demands in logistics and packaging lines.
- IP67 sealed housing effectively resists dust, splash water and oil mist in industrial workshop environments.
- Wide DC supply voltage range matches most industrial control power supply systems.
- Fast response time supports high-speed object detection on high-cycle production lines.
- Built-in comprehensive circuit protection prevents sensor damage caused by miswiring and load faults.
- Low repeat error ensures stable detection performance for long-term uninterrupted operation.
- Strong anti-electromagnetic interference capability for sites with inverters and servo motors.
- Rugged plastic housing with good vibration resistance for installation on moving machinery.
5. 10 Banner Similar Industrial Photoelectric Sensors
- QS18VN6LV, QS18 non-polarized retroreflective sensor, 6.5 m range, complementary NPN output, 2 m cable
- QS18VP6LVQ8, QS18 non-polarized retro sensor with 4-pin M12 quick-disconnect connector
- QS18VP6LP, QS18 polarized retroreflective photoelectric sensor, 3.5 m detection range
- QS18VP6DL, QS18 long-range diffuse photoelectric sensor without reflector
- QS18VP6FF100, QS18 fixed-field background suppression sensor, 100 mm cutoff distance
- QS186EQ, QS18 through-beam emitter unit for long-distance opposed detection
- Q25VP6LV, Q25 series non-polarized retroreflective compact photoelectric sensor
- QS30LV, Long-range non-polarized retroreflective sensor for heavy-duty logistics equipment
- QS18VP6R, QS18 standard short-range diffuse mode photoelectric sensor
- QS18VP6CV45, QS18 convergent mode photoelectric sensor for small target detection
