Sensor
New Original KEYENCE AP-C33K Ultra-compact Digital Pressure Sensor
| Model | AP-C33K | |||
| Type | Positive pressure, NPN | |||
| Rated pressure | 0 to 145.0 Psi | |||
| Fluid type | Air or non-corrosive gases | |||
| Type of pressure | Gauge pressure | |||
| Display | 3 1/2-digit, 2-color, 7-segment LED (Character height: 0.43″ (11 mm)) Display cycle: 10 times/s | |||
| Operation indicator | Red LED x 2 (corresponding to control output 1 and 2) | |||
| Display resolution | Normal mode: 0.2 Psi, Focus mode: 0.02 Psi | |||
| Power consumption | Normal | 12 V: 720 mW (60 mA) or less, 24 V: 960 mW (40 mA) or less | ||
New Original KEYENCE AP-V41AW Wire-saving AI Digital Pressure Sensor
| Model | AP-V41AW | |||
| Type | Amplifier Unit, NPN | |||
| Applicable sensor head | AP-41M, AP-41, AP-43, AP-44 | |||
| Set and display range | -15 to +110 % of F.S. | |||
| Display | 4 1/2-digit, 2-color, 7-segment LED (Character height: 4.5 mm 0.18″), AI indicator (green), Display cycle: 10 times/s | |||
| Operation indicator | Red LED x 2 (corresponding to control output 1 and 2) | |||
| Repeatability | ±0.2 % of F.S. | |||
| Display resolution | AP-41M/41/44: Standard mode 0.1 inchHg, High-resolution/Focus mode 0.01 inchHg AP-43: Standard mode 0.01 kgf/cm2, High-resolution/Focus mode 0.02 Psi |
|||
New Original KEYENCE BL-1301 Laser Barcode Reader
| Model | BL-1301 | |||
| Type | Standard type | |||
| Type | Reading direction | Front | ||
| Scanning method | Raster | |||
| Laser | Light source | Visible semiconductor laser (wavelength: 660 nm) | ||
| Control output | 85 µW | |||
| Pulse duration | 112 µs | |||
| Laser class | Class 2 Laser Product (IEC60825-1, FDA (CDRH) Part1040.10) | |||
| Reading | Supported codes | CODE39, ITF, Industrial2of5, Standard2of5, COOP2of5, CODABAR, CODE128, GS1-128, CODE93, UPC/EAN, GS1 DataBar | ||
| Number of readable digits | 74 digits (148 digits for CODE128 with start character C) | |||
| Readable bar width | 0.125 mm0.005″ | |||
| Reading distance | 65 to 500 mm 2.56″ to 19.69″ (narrow bar width 1.0 mm 0.04″) | |||
| Focal point | 120 mm 4.72″ | |||
| Largest readable label width | 339 mm 13.35″ (distance: 350 mm 13.78″, narrow bar width: 1.0 mm 0.04″) | |||
| PCS | 0.4 or more | |||
| Scanning rate | 500 to 1,300 scans/sec. (in units of 100 scans) | |||
New Original KEYENCE CA-LH16 Lenses for Machine Vision
| Model | CA-LH16 | |||
| Focal point | 16 mm 0.63″ | |||
| F-stop range (aperture) | F1.4 to F16 | |||
| Minimum WD | 0.2 m 0.7′ | |||
| Mount | C-mount | |||
| Filter size | 25.5 mm 1.00″ P0.5 | |||
| Compatible image sensor size | 2/3″ | |||
| TV distortion | -0.05 % (-0.1 %) | |||
| Resolving power | 100 cycles/mm at center, 80 cycles/mm on periphery | |||
| Ambient temperature/humidity range | 0 to +50°C 32 to 122°F, 80% RH or less (No condensation) | |||
| Weight | Approx. 81 g | |||
New Original KEYENCE CL-3000 Confocal Displacement Sensor
| Model | CL-3000 | |||
| Type | Controller | |||
| Number of optical unit connections | Controller only: 2 units; using expansion units / relay units: 6 units | |||
| Interface | EtherNet/IP™ | Supports cyclic communication and message communication; RPI: 1 to 10,000 ms (0.5 ms units) Maximum number of connections: 8, complies with Version CT14 conformance test Cannot be used when using PROFINET, PLC link or EtherCAT |
||
| PROFINET | Compatible with conformance class A. Cannot be used when using EtherNet/IP™, PLC link or EtherCAT | |||
| PLC-Link | The following PLCs are supported: Mitsubishi Electric: MELSEC iQ-R Series, iQ-F Series, Q Series, L Series, FX Series Cannot be used when using EtherNet/IP™, PROFINET or EtherCAT |
|||
| Ethernet | Allows for measurement data output and control I/O via no-protocol command communication with PCs and PLCs 100Base-TX, capable of communication with CL-NavigatorN |
|||
| USB | Conforms to USB 2.0 HighSpeed, capable of communication with CL-NavigatorN | |||
| RS-232C | Allows for measurement data output and control I/O via no-protocol command communication with PCs and PLCs Baud rate: 9600 to 115,200 bps, data length: 8 bit, stop bit: 1 bit, parity: none / even numbers / odd numbers |
|||
| Terminal (IN) | 13 (supports function switching via software) | |||
| Terminal (OUT) | 11 (supports function switching via software) | |||
New Original KEYENCE CZ-H52 RGB Digital Fiberoptic Sensor
| Model | CZ-H52 | |||
| Type | Fluorescence detection UV | |||
| Detecting area | 25 to 55 mm 0.98″ to 2.17″ (Reco mmended: 35 mm 1.38″) |
|||
| Smallest spot diameter | Approx. 10 mm 0.39 dia. at reference distance of 25 mm 0.98″“ | |||
| Light source | UV (ultraviolet) LED (375 nm) | |||
| Minimum bend radius of fi ber | ― | |||
| Receivable wavelength (Receiver) | 425 to 550 nm | |||
New Original KEYENCE CZ-V21AP RGB Digital Fiberoptic Sensor Amplifier Unit
| Model | CZ-V21AP | |||
| Output | PNP output | |||
| Main unit/expansion unit | Main unit | |||
| Response time | 200 µs (HIGH SPEED) /1 ms (FINE) /4 ms (TURBO) /8 ms (SUPER) | |||
| Control output | PNP open-collector x 4 channels, 30 VDC max., Up to 100 mA for one output, Up to 200 mA in total of 4 outputs, Residual voltage: 1.0 V max. | |||
| Protection circuit | Reverse-polarity protection, overcurrent protection, surge absorber | |||
New Original KEYENCE ED-118M Built-in Amplifier Proximity Sensor for Non-ferrous Metals
| Model | ED-118M | |||
| Type | Shielded | |||
| Shape | M18Threaded type | |||
| Detecting distance | 5 mm 0.20″ ±15% | |||
| Detectable object | All metals | |||
| Standard target (aluminum, t=1 mm 0.04″) | 18 x 18 mm 0.71″ x 0.71″ | |||
| Hysteresis | 15% max. of detecting distance | |||
| Response frequency | 100 Hz | |||
| Operation mode | N.O. | |||
| Indicator lamp | Operation indicator: Red LED, Stable operation indicator: Green LED | |||
| Temperature characteristics | ±20% max. of detecting distance at 23°C 73.4°F, within 0 to 50°C 32 to 122°F | |||
New Original KEYENCE EG-530 High-accuracy Positioning Sensor
| Model | EG-530 | |||
| Type | DC | |||
| Sensitivity adjustment | 15-turn trimmer | |||
| Function | Operation mode | N.O./N.C. (switch-selectable) | ||
| Operation mode | External synchronization | ― | ||
| Output | Control output 1 (NPN) | 100 mA max. (40 V max.) Residual voltage： 1 V max. | ||
| Control output 2 | ― | |||
| Disconnection alarm output (NPN) |
100 mA max. (40 V max.) Residual voltage： 1 V max. |
|||
| Response time (Relay contact) |
1 ms | |||
| ― | ||||
| OFF-delay time | ||||
New Original KEYENCE EH-108 Separate Amplifier Proximity Sensor
| Model | EH-108 | |||
| Type | Oil-resistant, Shielded, Threaded | |||
| Detectable object | Ferrous metals (see Characteristics for nonferrous metals) | |||
| Standard target (iron, t=1 mm 0.04″) | 10 x 10 mm 0.39″ x 0.39″ | |||
| Stable detecting range | 0 to 1.5 mm0.06″ | |||
| Maximum detecting distance | 2.5 mm0.10″ | |||
| Hysteresis | 0.07 mm0.003″ | |||
| Repeatability | 0.005 mm0.0002″ | |||
| Temperature characteristics | ±10% max. of detecting distance at 23°C 73.4°F, within -10 to +60°C 14 to 140°F | |||
New Original KEYENCE EM-005 Proximity sensors with in-cable amplifiers
| Model | EM-005 | |||
| Type | Shielded | |||
| Shape | M5 Threaded | |||
| Detecting distance | 1.0 mm 0.04″ ±15% | |||
| Detectable object | Ferrous metals (see Characteristics for non-ferrous metals) | |||
| Standard target (iron, t=1 mm 0.04″) |
5 x 5 mm 0.20″ | |||
| Hysteresis | 10% max. of detecting distance | |||
| Response frequency | 1.2 kHz | |||
New Original KEYENCE ES-M1 Separate Amplifier Proximity Sensor
| Model | ES-M1 | |||
| Type | One-line expansion system | |||
| Shape | Main unit | |||
| Operation mode | N.O./N.C. switch-selectable | |||
| Timer function | 10-ms delay / timer OFF switchable | |||
| Output | NPN | |||
| Output | Control output | NPN open collector 100 mA max. 40 V, residual voltage 1 V max. | ||
| Disconnection alarm output | NPN open collector 100 mA max.40 V, residual voltage 1 V or less |
|||
| Response time | 1 ms max. | |||
