Siemens 6ES7223‑1BL32‑0XB0 SM1223 SIMATIC S7‑1200 Digital Input Output Module
Product Overview
The Siemens 6ES7223‑1BL32‑0XB0 SM1223 is a digital mixed input‑output signal expansion module for the SIMATIC S7‑1200 PLC system. It provides 16‑channel 24 V DC digital inputs and 16‑channel transistor digital outputs, connecting to S7‑1200 CPU via internal backplane bus to expand discrete I/O capacity. The digital input supports both sink and source sensor wiring modes; the transistor outputs are sourcing type for fast‑switching DC loads. It is configured and diagnosed through TIA Portal engineering software, widely used for packaging machines, conveyor systems, assembly equipment and general discrete automation applications. It is designed for cabinet‑only installation with industrial‑grade anti‑interference performance西门子工业….
Main Functions
- Digital signal acquisition: Collect 24 V DC discrete signals from push‑buttons, limit switches, proximity sensors and other field devices.
- Digital output driving: Control DC‑type actuators such as solenoid valves, indicator lights and small contactors via transistor output channels.
- Parameterizable input filter: Adjust input delay time in groups to suppress field contact bounce and electrical interference.
- Backplane bus communication: Exchange I/O data with S7‑1200 CPU through internal expansion bus without extra communication wiring.
- Channel‑level diagnostics: Supply hardware diagnostic information for module status for quick fault identification in TIA Portal.
- Flexible wiring: Support sink/source connection for digital inputs to adapt different sensor types on‑site.
- System expansion: Multiple SM modules can be stacked to increase total system I/O points subject to S7‑1200 CPU expansion limits.
Technical Characteristics
| Item | Specification |
|---|---|
| Order Number | 6ES7223‑1BL32‑0XB0 |
| Product Model | SM 1223 |
| Compatible Series | SIMATIC S7‑1200 PLC |
| Digital Input | 16 channels, 24 V DC, sink / source compatible |
| Digital Output | 16 channels, 24 V DC sourcing transistor, 0.5 A per channel |
| Input Delay | Configurable: 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms, 12.8 ms (group‑wise setting) |
| Backplane Bus Current Consumption | 185 mA @ 5 V DC from backplane bus |
| Typical Power Dissipation | 4.5 W |
| Rated Load Supply Voltage | 20.4 V ~ 28.8 V DC |
| Max Cable Length (shielded) | 500 m |
| Max Cable Length (unshielded) | 300 m |
| Operating Temperature | ‑20 ℃ ~ +60 ℃ horizontal mounting; ‑20 ℃ ~ +50 ℃ vertical mounting |
| Storage & Transport Temperature | ‑40 ℃ ~ +85 ℃ |
| Relative Humidity | 5%‑95%, non‑condensing |
| Protection Class | IP20 (for installation inside electrical cabinet) |
| Programming Tool | TIA Portal STEP 7 |
Mechanical Specifications
| Mechanical Parameter | Value |
|---|---|
| Width | 70 mm |
| Height | 100 mm |
| Depth | 75 mm |
| Net Weight | Approx. 310 g |
| Mounting Method | DIN‑rail mounting or screw mounting inside control cabinet |
10 Similar‑function Siemens S7‑1200 Digital I/O Expansion Products
- 6ES7223‑1BH32‑0XB0：SM1223, 8 DI ×24 V DC / 8 DO ×24 V DC transistor mixed digital I/O module
- 6ES7223‑1PL32‑0XB0：SM1223, 16 DI ×24 V DC / 16 DO relay output mixed I/O module
- 6ES7223‑1PH32‑0XB0：SM1223, 8 DI ×24 V DC / 8 DO relay output mixed digital I/O module
- 6ES7223‑1QH32‑0XB0：SM1223, 8 DI 120‑230 V AC / 8 DO relay output mixed I/O module for AC field signals
- 6ES7221‑1BH32‑0XB0：SM1221, 16‑channel 24 V DC pure digital input expansion module
- 6ES7222‑1BH32‑0XB0：SM1222, 16‑channel 24 V DC transistor pure digital output expansion module
- 6ES7222‑1HH32‑0XB0：SM1222, 16‑channel relay pure digital output expansion module
- 6ES7221‑1BF32‑0XB0：SM1221, 8‑channel 24 V DC pure digital input module for small‑scale expansion
- 6AG1223‑1BL32‑7XB0：SIPLUS SM1223, conformal‑coated 16DI/16DO transistor module for harsh wide‑temperature industrial environment
- 6ES7223‑0BD30‑0XB0：SB1223 signal board, 4DI /4DO compact mixed digital I/O board mounted directly on S7‑1200 CPU front panel
