New Original Siemens 3NE1435-0 SITOR FUSE LINK Full Technical Introduction
1. Product Overview
The 3NE1435-0 is an original Siemens SITOR series high-performance semiconductor protection fuse link, categorized as NH3 size LV HRC (High Rupturing Capacity) fuse with gR utilization class. It is specially engineered for full-range protection of power semiconductor components including IGBT modules, rectifiers, inverters, servo drives, DC link circuits, UPS power supplies, soft starters and frequency converters in industrial automation systems.
This fuse adopts a high-temperature ceramic housing with slotted blade contact structure, equipped with a built-in front visual blown indicator for rapid fault identification. It complies with IEC 60269-4 and VDE 0636-4 industrial standards, supports 690V AC and 440V DC rated voltage, and provides precise current limiting performance under short-circuit and overload conditions. Widely applied in packaging machinery, metal processing equipment, wind power converters, solar inverters, logistics automation lines and 3C manufacturing equipment. The new original unit maintains consistent electrical characteristics without parameter drift, meeting RoHS and EU CE certification requirements for global export projects.
2. Main Core Functions
- Full-range gR semiconductor protection: intercepts both overload current and severe short-circuit current to avoid permanent burnout of expensive power semiconductors
- Ultra-fast current limiting cut-off capability, effectively suppress short-circuit energy and reduce secondary damage to peripheral circuit parts
- Integrated front mechanical indicator window; the indicator pops up visibly once the fuse element melts for quick on-site troubleshooting
- High stable load factor, adapts to frequent variable load cycles under continuous 24-hour industrial operation
- Standard NH3 slotted blade contact design, compatible with Siemens matching fuse bases, fuse switch disconnectors and direct busbar bolt mounting
- Low power loss internal melt structure, minimizes heat generation during long-term rated current operation to lower cabinet heat dissipation pressure
- Wide ambient temperature adaptability, stable performance under workshop normal and mild high-temperature working environments
- Single-use disposable protection unit with standardized replacement structure for easy on-site maintenance
- High breaking capacity to withstand extreme short-circuit current in heavy industrial power distribution loops
- Unified Siemens SITOR series dimensional standard, convenient for batch spare parts inventory management
3. Core Technical Specifications
Table 1 Main Electrical Technical Parameters
表格
| Parameter Item | Technical Data of 3NE1435-0 |
|---|---|
| Model Number | 3NE1435-0 |
| Series | SITOR Semiconductor Fuse Link |
| Utilization Class | gR (Full-range semiconductor protection) |
| Standard Size | NH3 |
| Rated AC Voltage | 690 V |
| Rated DC Voltage | 440 V |
| Rated Nominal Current | 560 A |
| Rated Breaking Capacity (AC) | 100 kA |
| Internal Power Loss (Rated Current) | 68 W |
| Ambient Operating Temperature Range | -20 ℃ ~ +60 ℃ |
| Compliance Standards | IEC 60269-4, VDE 0636-4, CE, RoHS, UL Recognized |
| Contact Type | Slotted blade contact for screw fixing |
| Indicator Configuration | Front visual blown indicator |
| Cooling Method | Natural air convection cooling |
4. Product Dimension & Weight Information
Table 2 Dimension and Weight Data
表格
| Item | Specific Parameter |
|---|---|
| Overall Height | 151 mm |
| Overall Width | 102 mm |
| Overall Thickness | 54 mm |
| Blade Contact Spacing | 110 mm standard NH3 mounting dimension |
| Single Unit Net Weight | 0.86 kg |
| Single Original Packaging Gross Weight | 1.12 kg |
| Installation Orientation | Horizontal / vertical universal mounting |
| Mounting Method | Fit NH3 fuse base or direct busbar screw installation |
5. Key Technical Features
- High-purity ceramic housing with high thermal insulation and arc extinguishing performance, effectively isolate internal electric arc during fuse breaking
- Optimized silver alloy melt strip design, delivers precise time-current characteristic curve for accurate semiconductor protection matching
- Low thermal resistance blade contact structure, excellent heat transfer performance to avoid overheating at connection points under long-term full load
- Compact NH3 standardized body, saves internal installation space of electrical control cabinets
- Original Siemens industrial-grade manufacturing process, stable electrical consistency among batches, no performance deviation for parallel connection scenarios
- Built-in mechanical indicator without auxiliary power supply, instantly visible fault signal after fuse blowing
- Anti-corrosion plated blade contacts, resistant to workshop humid and slightly dusty environment, long service life
- Strict raw material control, fully compliant with global environmental protection standards for export customs clearance
- High overload tolerance, can withstand short-time peak surge current without accidental fusing during equipment startup
- Interchangeable with all standard NH3 SITOR fuse bases of Siemens and compatible brands, strong system compatibility
6. Ten Similar Functional Siemens SITOR Fuse Link Models (3NE Series)
All below products belong to Siemens original SITOR semiconductor protection fuse links, adopt NH standard blade contact structure, support gR/aR semiconductor protection, match inverters, servo drives and power semiconductor equipment, with different size and current ratings for alternative selection:
- 3NE1224-0 (NH1, 160A, 690V AC gR)
- 3NE1227-0 (NH1, 250A, 690V AC gR)
- 3NE1331-0 (NH2, 350A, 690V AC gR)
- 3NE1332-0 (NH2, 400A, 690V AC gR)
- 3NE1334-2 (NH2, 500A, 690V AC gR)
- 3NE1437-3 (NH3, 710A, 690V AC gR)
- 3NE4124-1 (NH0, 160A, 1000V AC aR)
- 3NE3230-0B (NH2, 315A, 690V AC gS)
- 3NE1802-0 (NH000, 40A, 690V AC gR)
- 3NE3335-8 (NH3, 560A, 1000V AC aR)
