New Original Schneider V02C TeSys VARIO 3-Pole Switch Disconnector

1. Product Overview

V02C is an original genuine bare switch body of Schneider Electric TeSys VARIO series modular load isolation switch, designed as the core switching unit matched with external rotary operating handles for low-voltage power distribution cabinets and mechanical equipment main circuit isolation control.

This is a 3-pole isolator with conventional thermal current of 12 A, applicable for three-phase AC power circuits up to 690 V. It serves as the main power cut-off component for small fan units, water pumps, machine tools, HVAC equipment and small automation control boxes. After assembling VARIO series door-mounted rotary handles (such as KAD series), it realizes external cabinet door operation and Lockout-Tagout safety locking function. It adopts compact modular structure, supports back panel screw fixing inside enclosures, and can be combined with various extension shafts and padlockable handles to adapt to different cabinet depths. With visible contact isolation gaps and excellent breaking performance, it complies with international isolation switch safety specifications, widely used for circuit maintenance power cut-off and general load switching in indoor industrial environments.

2. Main Functions

Complete Electrical Isolation for Circuit Maintenance

When switched to OFF position, a distinct visible contact gap is formed inside the switch body, thoroughly disconnecting three-phase power supply for downstream loads. It eliminates residual voltage risks during equipment overhaul, fully meeting industrial maintenance isolation safety requirements.
Manual Load On/Off Switching Control

Matched with external rotary operating handles, it completes manual switching of resistive and inductive loads within rated current range under normal working conditions, acting as the main power switch for small industrial equipment.
Adaptable LOTO Safety Locking Matching

Compatible with KAD, KCD series padlockable rotary handles; the OFF position can be locked by multiple padlocks to prevent accidental switch closure and unintended energization during maintenance operations.
Short-Time Withstand Current & Fuse Coordination Protection

It can withstand short-time fault current and coordinate with external backup fuses to limit short-circuit damage to the switch body, ensuring stable performance under transient power grid faults.
Universal Accessory Expandability

Supports installation of auxiliary contact blocks for switch ON/OFF status signal feedback; optional extension drive shafts adapt to deep electrical cabinet installation demands.
Finger-Safe Internal Protection Structure

IP20 protection grade prevents accidental touch of internal live conductive parts inside cabinets, avoiding electric shock hazards during routine inspection.

3. Technical Characteristics

Technical Parameter	Detailed Specification
Full Model	V02C
Product Series	TeSys VARIO Switch Disconnector Bare Body
Number of Poles	3 Poles
Conventional Free Air Thermal Current (Ith)	12 A
Rated Operational Current (AC-23, 400V AC)	8.1 A
Rated Enclosed Thermal Current	10 A
Rated Operational Voltage (Ue)	Up to 690 V AC, 50/60 Hz
Rated Insulation Voltage (Ui)	800 V
Rated Impulse Withstand Voltage (Uimp)	8 kV
Short-Time Withstand Current (1s)	300 A
Conditional Short-Circuit Breaking Capacity	10 kA @ 400 V AC (with gG/aM backup fuse)
Making & Breaking Capacity	120 A @ 400 V AC (AC-21/22/23)
Mechanical Service Life	100,000 operation cycles
Electrical Service Life (AC-21)	100,000 cycles
Protection Degree (Switch Body Only)	IP20
Operating Ambient Temperature	-20 ℃ ~ +50 ℃
Storage Temperature Range	-40 ℃ ~ +70 ℃
Terminal Type	Screw clamping terminals
Tightening Torque for Terminals	2.1 N·m
Compliance Standards	IEC 60947-3, UL508, CCC, CSA, RoHS, REACH
Housing Flame Retardant Grade	UL94 V0 high-temperature resistant engineering plastic

Core Technical Advantages

Compact modular size, occupies minimal cabinet installation space;
Robust internal contact structure with excellent anti-ablation performance for long-term switching;
Universal drive shaft interface, fully compatible with all VARIO series operating handles and accessories;
Stable temperature rise performance under continuous rated current operation;
Multi-national safety certifications, applicable to global industrial low-voltage distribution projects.

4. Product Overall Dimensions & Weight

External Dimensions (Unit: Millimeter)

Dimension Item	Exact Size
Overall Width	55
Overall Height	74
Overall Depth	74

Weight Parameters

Weight Category	Specific Value
Single Unit Net Weight	200 g
Original Packaged Gross Weight	220 g

5. 10 Schneider TeSys VARIO Series Similar Switch Disconnector Bodies

All listed products are bare isolation switch bodies of VARIO series, featuring visible isolation gap, screw terminal wiring, compatible rotary handles and auxiliary contacts; differences lie in rated current and pole configuration:

V1C 3P 20A VARIO Switch Disconnector Body
V2C 3P 25A VARIO Switch Disconnector Body
V3C 3P 32A VARIO Switch Disconnector Body
V4C 3P 40A VARIO Switch Disconnector Body
V6C 3P 63A VARIO Switch Disconnector Body
V8C 3P 80A VARIO Switch Disconnector Body
VN12 3P Compact Mini VARIO 12A Isolator Switch Body
VN20 3P Compact Mini VARIO 20A Isolator Switch Body
V01C 1P 12A Single-Pole VARIO Isolation Switch Body
V04C 4P 12A Four-Pole VARIO Switch Disconnector Body
