New Original Schneider LC1D40ABD TeSys Deca Electromagnetic Contactor
1. Product Overview
LC1D40ABD is an original genuine three-pole electromagnetic contactor belonging to Schneider Electric TeSys Deca LC1D series. Equipped with a 24V DC control coil, this contactor is rated 40A under AC-3 utilization category. It is widely applied to control the start, stop and forward/reverse operation of three-phase asynchronous motors, as well as the switching of inductive and resistive AC loads in machine tools, water pump units, HVAC ventilation systems, automated production lines, packaging machinery and various industrial low-voltage control cabinets.
The contactor is designed with 3 main normally open power contacts and fixed built-in 1NO + 1NC auxiliary contacts. Under 400V AC power supply, it can drive three-phase motors up to 18.5 kW. A freewheeling diode is integrated inside the DC coil to absorb reverse electromotive force generated during coil de-energization, which effectively protects PLC output ports and other precision control components in the front control loop. It supports two installation ways: standard 35 mm DIN rail mounting and panel screw fastening. It can be combined flexibly with thermal overload relays, auxiliary contact blocks, mechanical interlock attachments, time delay modules and other TeSys series accessories to assemble complete motor starter systems for overload protection, interlock control and signal feedback scenarios. With high electrical durability, stable electromagnetic performance and full international safety certifications, it is a general-purpose core control component for industrial automatic power distribution.
2. Main Functions
- Remote Automatic Load Switching Control
When 24V DC voltage is applied to the electromagnetic coil, the electromagnet is energized to pull the movable contact assembly tightly, closing the main circuit to supply power to downstream motors or loads. Once the coil power is cut off, the spring resets the contacts to disconnect the main circuit. This structure realizes unattended remote start-stop control of three-phase motors and on-off switching of heating equipment, fans and lighting loads.
- Synchronous Status Signal Feedback via Auxiliary Contacts
The built-in 1 normally open and 1 normally closed auxiliary contacts act synchronously with main contacts. They transmit pull-in or release status signals to PLCs, indicator lights and interlock circuits to realize equipment running monitoring and electrical logic interlock.
- Arc Extinguishing Protection for Power Contacts
Each pole is equipped with an independent sealed arc extinguishing chamber. It quickly cools and eliminates electric arcs produced at the moment of circuit breaking, preventing arc ablation, contact welding and wear of silver alloy contacts, extending service life under frequent switching conditions.
- Multifunctional Expansion via Optional Accessories
Various accessories can be installed on the top and side of the contactor, including additional auxiliary contacts, mechanical interlock devices, surge suppressors and pneumatic delay modules, to meet demands of multi-channel signal output, motor positive and negative rotation interlock and delayed switching control.
- DC Coil Anti-surge and Anti-interference Performance
Built-in freewheeling diode restrains voltage surge during coil power-off, reducing electromagnetic interference to peripheral circuits and improving the stability of DC automatic control systems.
- Finger-Safe Protection Structure
IP20 protection grade avoids accidental contact with internal live conductive parts during indoor cabinet inspection and maintenance, complying with global industrial safety norms.
3. Technical Characteristics
| Technical Parameter | Detailed Specification |
|---|---|
| Full Model | LC1D40ABD |
| Product Series | TeSys Deca LC1D 3-Pole Contactor |
| Main Contact Layout | 3 Poles, 3 Normally Open Main Contacts |
| Fixed Auxiliary Contacts | 1 NO + 1 NC |
| Rated Operational Current (AC-3, 440V AC) | 40 A |
| Rated Resistive Load Current (AC-1) | 60 A |
| Matched Three-Phase Motor Power (400V AC) | 18.5 kW |
| Control Coil Voltage | 24 V DC |
| Maximum Main Circuit Voltage | 690 V AC |
| Rated Insulation Voltage | 1000 V |
| Rated Impulse Withstand Voltage | 6 kV |
| Maximum Allowed Switching Frequency | 3600 cycles per hour |
| Mechanical Service Life | 10,000,000 operating cycles |
| Electrical Service Life (AC-3 Working Condition) | 700,000 operating cycles |
| Protection Class | IP20 |
| Operating Ambient Temperature | -20 ℃ ~ +60 ℃ |
| Storage Temperature Range | -40 ℃ ~ +70 ℃ |
| Mounting Forms | 35 mm DIN rail mounting, panel screw installation |
| Terminal Type | Screw clamping wiring terminals |
| Compliance Standards | IEC 60947-4-1, UL508, CCC, CSA, RoHS & REACH |
| Housing Flame Retardant Level | UL94 V0 high temperature resistant engineering plastic |
Core Technical Advantages
- Low-consumption DC coil with integrated surge absorption circuit, strong anti-electromagnetic interference capability;
- High-performance silver alloy contacts with excellent anti-welding and abrasion resistance;
- Unified modular dimension for the whole LC1D series, convenient for compact layout inside electrical cabinets;
- Perfect compatibility with TeSys thermal relays to construct integrated motor protection units;
- Stable operation under slight vibration environments, suitable for workshop assembly lines and mobile machinery equipment.
4. Product Dimensions & Weight
External Overall Dimensions (Unit: mm)
| Dimension Item | Size |
|---|---|
| Overall Height | 90 |
| Overall Width | 65 |
| Overall Depth | 96 |
Weight Parameters
| Weight Category | Value |
|---|---|
| Single Unit Net Weight | 730 g |
| Original Packaged Gross Weight | 768 g |
5. 10 Schneider LC1D Series DC Coil Contactors with Similar Functions
All listed products are 3-pole DC coil electromagnetic contactors of TeSys Deca LC1D series, applied for motor control and load switching, with identical installation structure and expandable accessory system; differences exist mainly in rated current and DC coil voltage:
- LC1D09BD 3P 9A, 24V DC Coil Contactor
- LC1D18BD 3P 18A, 24V DC Coil Contactor
- LC1D25BD 3P 25A, 24V DC Coil Contactor
- LC1D32BD 3P 32A, 24V DC Coil Contactor
- LC1D38BD 3P 38A, 24V DC Coil Contactor
- LC1D40AJD 3P 40A, 12V DC Coil Contactor
- LC1D40AKD 3P 40A, 48V DC Coil Contactor
- LC1D50ABD 3P 50A, 24V DC Coil Contactor
- LC1D65ABD 3P 65A, 24V DC Coil Contactor
- LC1D40AMD 3P 40A, 220V DC Coil Contactor
