New Original Schneider LC1D18BD TeSys Deca 3-Pole DC Contactor
1. Product Overview
LC1D18BD is an original genuine electromagnetic contactor belonging to Schneider Electric TeSys Deca LC1D series, specially designed for three-phase asynchronous motor start-stop control and AC load switching in industrial automation systems, machine tools, water pump equipment, HVAC units, conveyor lines and low-voltage control cabinets.
This is a 3-pole non-reversing contactor with 3 main normally open power contacts, equipped with a 24V DC control coil. Under AC-3 utilisation category (standard motor operating condition), its rated working current reaches 18A at 440V AC, capable of driving three-phase motors up to 7.5kW. It comes with built-in 1NO+1NC standard auxiliary contacts for signal feedback to PLC and control loops. Adopting compact modular structure, it supports 35mm DIN rail mounting and panel screw fixing, and can be flexibly combined with thermal overload relays, auxiliary contact blocks, mechanical interlocks and other TeSys series accessories to form complete motor starter assemblies. The DC coil features built-in surge suppression circuit, stable anti-interference performance, suitable for DC control signal scenarios widely used in automation equipment. It complies with global mainstream electrical safety standards and is a general-purpose core component for industrial low-voltage power control.
2. Main Functions
- Remote Automatic On/Off Control for Motors & AC Loads
When 24V DC voltage is applied to the coil, the electromagnetic system pulls in contacts to switch on the main circuit; cutting off coil power releases contacts to disconnect the circuit. It realizes automatic remote start and stop of three-phase motors, as well as switching of resistive loads such as heating tubes, lighting equipment.
- Signal Feedback via Built-in Auxiliary Contacts
Integrated 1 normally open and 1 normally closed auxiliary contacts synchronously act with main contacts, feeding back contactor pull-in or release status to programmable controllers, indicator lights and interlocking circuits for logic control and operation monitoring.
- Arc Extinguishing & Long-Term Stable Switching
Independent sealed arc extinguishing chambers are configured for each main pole to rapidly cool and extinguish electric arcs generated during circuit breaking, effectively protecting contact surfaces from ablation and extending service life under frequent switching cycles.
- Expandable Functional Compatibility
Optional accessories including delay modules, auxiliary contact blocks, mechanical interlock units and surge suppressors can be assembled on the side or top of the contactor to realize timing control, multi-point signal output and reverse rotation interlock functions.
- Finger-Safe Protection & Wide Environmental Adaptability
IP20 front protection grade prevents accidental touch of internal live conductive parts under indoor installation; optimized coil and conductive structure ensures reliable operation within a wide temperature range.
- DC Coil Anti-Surge Design
Built-in freewheeling diode suppresses DC coil induced voltage surge, avoiding damage to front-end control components such as relays and PLC output modules.
3. Technical Characteristics
| Technical Parameter | Detailed Specification |
|---|---|
| Full Model | LC1D18BD |
| Product Series | TeSys Deca LC1D Electromagnetic Contactor |
| Number of Main Poles | 3 Poles (3 NO main contacts) |
| Auxiliary Contact Configuration | 1 NO + 1 NC (fixed built-in) |
| Rated Operational Current (AC-3, ≤440V AC) | 18 A |
| Rated Operational Current (AC-1 Resistive Load) | 32 A |
| Matched Three-Phase Motor Power (400V AC) | 7.5 kW |
| Control Coil Voltage | 24 V DC |
| Rated Power Circuit Voltage | Up to 690 V AC; Max 300 V DC |
| Rated Insulation Voltage | 1000 V |
| Rated Impulse Withstand Voltage | 6 kV |
| Maximum Switching Frequency | 3600 cycles per hour |
| Mechanical Service Life | 10,000,000 operation cycles |
| Electrical Service Life (AC-3) | 1,000,000 operation cycles |
| Protection Class | IP20 |
| Operating Ambient Temperature | -20 ℃ ~ +60 ℃ |
| Storage Temperature Range | -40 ℃ ~ +70 ℃ |
| Mounting Methods | 35mm standard DIN rail mounting, panel screw fixation |
| Terminal Type | Screw clamp wiring terminals |
| Compliance Standards | IEC 60947-4-1, UL 508, CSA, CCC, RoHS |
| Housing Flame Retardant Grade | UL94 V0 high-temperature resistant engineering plastic |
Core Technical Advantages
- Low-power consumption DC coil with built-in surge suppression, strong anti-interference for automation DC control systems;
- Silver alloy contact tips with excellent wear resistance and anti-welding performance;
- Unified modular size of LC1D series, convenient for cabinet layout and combination installation;
- High mechanical and electrical durability, applicable to equipment requiring frequent start-stop actions;
- Complete accessory system to meet diversified industrial control demands.
4. Product Overall Dimensions & Weight
External Dimensions (Height × Width × Depth, Unit: mm)
| Dimension Item | Size |
|---|---|
| Overall Height | 77 |
| Overall Width | 45 |
| Overall Depth | 86 |
Weight Parameters
| Weight Category | Value |
|---|---|
| Single Unit Net Weight | 490 g |
| Original Individual Packaged Gross Weight | 523 g |
5. 10 Schneider LC1D Series Similar DC Coil Contactors
All products below are 3-pole DC coil electromagnetic contactors under TeSys Deca LC1D series, applied for motor control and load switching with identical structural design, DIN rail installation and expandable accessories; differences lie in rated current and DC coil voltage:
- LC1D09BD 3P 9A, 24V DC Coil Contactor
- LC1D12BD 3P 12A, 24V DC Coil Contactor
- LC1D25BD 3P 25A, 24V DC Coil Contactor
- LC1D32BD 3P 32A, 24V DC Coil Contactor
- LC1D18JD 3P 18A, 12V DC Coil Contactor
- LC1D18KD 3P 18A, 48V DC Coil Contactor
- LC1D40ABD 3P 40A, 24V DC Coil Contactor
- LC1D50ABD 3P 50A, 24V DC Coil Contactor
- LC1D18MD 3P 18A, 220V DC Coil Contactor
- LC1D38BD 3P 38A, 24V DC Coil Contactor
