New Original Schneider DF143C TeSys DF 3P Fuse Holder
1. Product Overview
DF143C is an original Schneider Electric industrial modular fuse holder belonging to the premium TeSys DF series, designed for three-phase low-voltage AC power distribution circuits. It is a 3-pole DIN rail-mounted fuse carrier dedicated to accommodating standard 14 mm × 51 mm cylindrical cartridge fuses (gG general-purpose fuses and aM motor protection fuses). Integrated with a safety isolation switch structure, this unit combines fuse installation, circuit isolation and overcurrent short-circuit protection into one compact assembly. Widely applied in industrial automation control cabinets, three-phase motor power supply loops, machinery equipment panels, commercial workshop power distribution systems and auxiliary electrical circuits for production lines. It features drawer-type fuse extraction design for safe fuse replacement, stable conductive performance and excellent mechanical durability, and can be matched with auxiliary contacts and blown-fuse indicator accessories to build complete circuit protection solutions.
2. Main Functions
- Three-phase synchronous circuit isolation: The unified operating handle can cut off all three live phases simultaneously, forming a visible physical disconnection gap inside the device, which complies with international IEC safety standards for power-off maintenance, overhaul and equipment troubleshooting.
- Pole-by-pole overcurrent & short-circuit protection: Each independent pole is equipped with an individual fuse cavity; the inserted fuse will melt rapidly under overload or short-circuit faults to isolate faulty circuits and protect downstream motors, wiring and electrical loads from burnout damage.
- Drawer-type safe fuse replacement: Pull-out drawer structure allows operators to replace fuses without direct contact with live conductive parts, effectively lowering electric shock risks during maintenance work.
- Padlockable operating handle: The main toggle handle can be locked with padlocks in both ON and OFF positions to prevent unauthorized switching operations and avoid accidental power cut-on or cut-off on site.
- Expandable accessory compatibility: Reserved mounting positions for auxiliary signal contacts and blown-fuse indicator modules, which can output fault signals to PLC control systems or visually remind staff of fuse failure status.
- Universal screw terminal wiring: Screw clamping terminals support both rigid solid copper wires and stranded flexible copper wires to adapt to diversified on-site wiring layouts.
- Modular combined installation: Standard body size enables multiple holders to be arranged side by side on 35 mm DIN rails for centralized three-phase power distribution management.
3. Technical Specifications
| Item | Detailed Parameter |
|---|---|
| Full Model Number | DF143C |
| Product Series | Schneider TeSys DF Fuse Holder Series |
| Number of Poles | 3 Poles (3P) |
| Rated Operational Current | 50 A |
| Rated Operational Voltage | 690 V AC / 690 V DC, 50/60 Hz |
| Rated Insulation Voltage | 690 V |
| Rated Impulse Withstand Voltage | 8 kV |
| Applicable Fuse Dimension | 14 mm × 51 mm cylindrical cartridge fuse |
| Compatible Fuse Types | gG general distribution fuse, aM motor dedicated protection fuse |
| Rated Short-circuit Breaking Capacity | 120 kA at 400 V AC |
| Ingress Protection Grade | IP20 for terminal internal area |
| Wiring Cross-section Range | Rigid wire: 1.5 ~ 16 mm²; Flexible wire: 1 ~ 10 mm² |
| Ambient Operating Temperature | -20 °C ~ +60 °C |
| Pollution Degree | Class 3 |
| Compliance Standards | IEC 60269, IEC 60947-3, RoHS 3 Compliant |
| Mounting Method | Clip-on dual-lock system for standard 35 mm DIN top-hat rail |
| Handle Function | Padlockable at ON & OFF positions |
4. Technical Features
- High-strength flame-retardant reinforced plastic housing: Anti-arc ablation, high-temperature resistant and impact-resistant shell material ensures long-term stable operation in harsh industrial workshop environments.
- Silver-plated internal conductive contacts: Ultra-low contact resistance eliminates abnormal heating under continuous rated load, and guarantees balanced three-phase current transmission performance.
- Dual-lock DIN rail mounting structure: Firm clamping design prevents sliding or falling off caused by equipment vibration during long-term operation.
- Safe visible isolation gap: Clear mechanical breaking point after switching off fully meets electrical safety maintenance requirements stipulated by global low-voltage codes.
- Humanized drawer-type fuse carrier: Ergonomic pull-out structure simplifies fuse replacement steps and improves on-site maintenance efficiency.
- Strong environmental adaptability: No performance attenuation under temperature fluctuation, slight condensation and dust accumulation conditions.
- Complete expandable accessory ecosystem: Perfectly matched with auxiliary contacts, blown-fuse indicators and interconnection kits of the same series for flexible system upgrading.
5. Product Dimensions and Net Weight
| Parameter | Value |
|---|---|
| Overall Width | 54 mm |
| Overall Height | 128 mm |
| Overall Depth | 85 mm |
| Single Unit Net Weight | 570 g |
| Recommended Terminal Screw Tightening Torque | 1.5 N·m |
| Applicable Mounting Rail | 35 mm standard DIN rail |
6. Ten Schneider Similar-Function TeSys DF Series Fuse Holders
All listed products are original Schneider DIN rail-mounted fuse holders for three-phase/single-phase circuit isolation and fuse protection with different poles, current ratings and configurations:
- DF141C: 1P 50A single-pole fuse holder for single-phase live wire independent protection circuits
- DF142C: 2P 50A two-pole variant for single-phase live and neutral dual-line power distribution loops
- DF143NC: 3P+N four-wire fuse holder with additional neutral pole for three-phase four-wire systems
- DF143VC: 3P 50A fuse holder pre-installed with blown-fuse indicator lamps for each phase
- DF103: 3P 32A compact fuse holder adapted for 10×38 mm small-size cylindrical fuses
- DF223C: 3P 125A large-current heavy-duty fuse holder for main three-phase incoming power loops
- DF143C-H: High-temperature resistant customized version suitable for high-heat production workshop environments
- DF141NC: 1P+N single-phase plus neutral fuse holder for commercial and building auxiliary power circuits
- DF143C+AM: 3P fuse holder assembled with auxiliary signal contacts for remote fault feedback
- DF221C: 1P 63A medium-current single-pole fuse holder for general small-power control cabinets
