New Original Mitsubishi G5XP86 MR‑J2S‑100B‑QE 1kW SSCNET AC Servo Drive Amplifier
"*" señala los campos obligatorios
New Original Mitsubishi G5XP86 MR‑J2S‑100B‑QE 1kW SSCNET AC Servo Drive Amplifier
Product Overview
The Mitsubishi MR‑J2S‑100B‑QE, serial number G5XP86, is a brand‑new original 1 kW SSCNET‑bus‑type AC servo amplifier from the MELSERVO‑J2‑Super series. This servo drive adopts high‑speed SSCNET serial motion bus for digital command transmission, and it is designed to drive matching Mitsubishi HC‑KFS / HC‑MFS‑series AC servo motors. It supports multi‑axis synchronous motion control for automation equipment such as pick‑and‑place machines, X‑Y positioning tables, packaging machinery, semiconductor processing equipment and automated assembly stations. Marked as “New Original”, it stands for genuine factory‑produced unit with complete internal power modules, control circuit boards and full‑range factory performance testing, free of refurbished or second‑hand components. It converts AC mains power into precisely controlled three‑phase AC output for high‑accuracy speed, torque and position servo control. The‑QE suffix represents special variant hardware for customized industrial machine requirements.
Main Functions
- SSCNET high‑speed digital bus control: Receives position, speed and torque commands via SSCNET optical‑fiber serial bus, realizes multi‑axis synchronized motion with short communication cycle.
- Multi‑mode servo control: Supports position control, speed control and torque control modes, switchable by internal parameter setting.
- Built‑in dynamic brake function: Triggers quick motor braking when servo‑off or fault alarm occurs to lock the motor shaft.
- Auto‑tuning function: Executes gain auto‑tuning to match mechanical load characteristics and optimizes servo response performance.
- Comprehensive fault diagnosis and alarm output: Detects abnormal operating status and outputs alarm codes via LED panel and external IO signals for on‑site troubleshooting.
- Absolute encoder support: Works with absolute‑value encoders; one‑time home position setting without repeated homing after power‑off reboot.
- PC configuration and monitoring: Connects with personal computer via dedicated communication interface for parameter editing, status monitoring and waveform tracing.
- Multiple safety protection mechanisms: Provides hardware‑level protection against over‑current, over‑voltage, overload, overspeed and encoder signal failures.
Technical Characteristics
- Sine‑wave PWM current control algorithm, delivering low‑torque‑ripple smooth motor operation even at low rotating speed.
- SSCNET optical fiber communication effectively suppresses electromagnetic interference in industrial workshop environments.
- Open‑frame self‑cooling structure (IP00 protection grade), intended for cabinet installation.
- Built‑in regenerative processing circuit; external regenerative resistor can be connected for high‑inertia frequent deceleration applications.
- Rich digital input‑output signal terminals for interlock logic, servo enable, alarm reset and status feedback.
- Compatible with incremental and absolute servo encoders of matched Mitsubishi servo motors.
- Complies with CE and UL industrial safety standards for global industrial machine deployment.
- Supports electronic thermal overload protection to prevent motor damage caused by continuous over‑load operation.
Core Technical Parameters
| Item | Parameter Value |
|---|---|
| Part Number | MR‑J2S‑100B‑QE, Serial No. G5XP86 |
| Product Type | SSCNET‑bus AC servo amplifier |
| Rated Output Power | 1.0 kW |
| Power Supply | 3‑phase / 1‑phase AC 200‑230 V, 50 Hz / 60 Hz |
| Rated Output Current | 6.0 A |
| Control Method | Sine‑wave PWM current control |
| Communication Interface | SSCNET optical fiber bus |
| Control Modes | Position / Speed / Torque control |
| Dynamic Brake | Built‑in |
| Ambient Operating Temperature | 0 °C ~ +55 °C (non‑freezing) |
| Storage Temperature | ‑20 °C ~ +65 °C (non‑condensing) |
| Ambient Humidity | 5%‑90% RH, no condensation |
| Installation Altitude | ≤1000 m above sea level |
| Protection Class | IP00 (cabinet‑mount type) |
| Weight | 1.7 kg |
Product Dimensions
All dimension data are given in millimetres.
- Overall height: 225 mm
- Overall width: 85 mm
- Overall depth: 190 mm
- Mounting hole horizontal pitch: 70 mm
- Mounting hole vertical pitch: 211 mm
- Mounting screw hole diameter: 5 mm
Note: Enough ventilation clearance must be reserved around the amplifier inside electrical cabinet. Do not install in locations with direct sunlight, corrosive gas or heavy oil mist.
10 Mitsubishi Similar‑function SSCNET‑bus Servo Amplifiers (MELSERVO‑J2‑Super Series)
Below are ten original Mitsubishi MR‑J2S‑B‑series SSCNET‑type servo amplifiers covering different power ratings and special variants for multi‑axis digital‑bus motion‑control systems:
- MR‑J2S‑10B‑QE: 0.1 kW SSCNET servo amplifier, low‑power variant for miniature positioning axes.
- MR‑J2S‑20B‑QE: 0.2 kW SSCNET bus servo drive for small‑load automation stations.
- MR‑J2S‑40B‑QE: 0.4 kW SSCNET‑interface servo amplifier for medium‑light‑duty motion axes.
- MR‑J2S‑70B‑QE: 0.75 kW SSCNET servo amplifier, widely‑used mid‑range power model.
- MR‑J2S‑200B‑QE: 2.0 kW SSCNET‑bus servo amplifier for medium‑high‑load driving tasks.
- MR‑J2S‑350B‑QE: 3.5 kW SSCNET servo drive for heavy‑duty mechanical‑axis control.
- MR‑J2S‑500B‑QE: 5.0 kW high‑power SSCNET‑type servo amplifier.
- MR‑J2S‑100B‑EE085: 1 kW SSCNET special‑custom variant for dedicated machine equipment.
- MR‑J2S‑70B‑S141U632: 0.75 kW SSCNET customized‑hardware servo amplifier.
- MR‑J2S‑200B‑QR141U633: 2 kW SSCNET special‑version servo amplifier for special‑machine application.
