New Original FESTO 8002612 SIEN‑M5B‑NS‑S‑L‑P5 Inductive Proximity Sensor Switch
"*" señala los campos obligatorios
New Original FESTO 8002612 SIEN‑M5B‑NS‑S‑L‑P5 Inductive Proximity Sensor Switch
Product Overview
The FESTO SIEN‑M5B‑NS‑S‑L‑P5 with part number 8002612 is a miniature threaded inductive proximity sensor designed for compact automation environments. As a brand‑new original unit, it adopts non‑contact inductive sensing principle to detect the presence of ferrous metal targets. This small‑form‑factor sensor is widely integrated into pneumatic actuators, pick‑and‑place modules, assembly jigs, packaging machinery and miniature handling equipment. It delivers reliable digital switching signals for workpiece presence checking, limit position detection and cycle sequence control in space‑restricted industrial automation applications.
Main Functions
- Non‑contact detection of approaching ferrous metal objects and outputs switching signal for target‑presence judgment.
- Provides NPN normally‑open signal output for direct connection with PLC and industrial control modules.
- Realizes position feedback for limit stop, part counting and workpiece verification on compact automated stations.
- Built‑in LED status indicator offers on‑site visual feedback for power‑on and switching state during commissioning and troubleshooting.
- M5 threaded barrel allows flexible installation with lock nuts for adjustable sensing distance setting.
- Protects downstream control circuits with integrated reverse‑polarity and short‑circuit protection.
Technical Features
- Miniature M5 threaded metal housing, ideal for installation inside narrow mechanical structures
- Flush‑mountable design reduces risk of mechanical collision damage to sensing face
- Short‑circuit protection and reverse‑polarity protection improve electrical reliability
- Visible status LED for quick visual diagnosis without measurement instruments
- P5 flying‑lead cable connection style for convenient wiring inside machine housings
- Compact mechanical structure tolerates moderate vibration from pneumatic and mechanical equipment
- Optimized sensing performance for ferrous metals with defined reduction factors for non‑ferrous metals
- Strict factory testing ensures stable repeatability for high‑cycle automated operation
Specifications
| Item | Parameter |
|---|---|
| Brand | FESTO |
| Model | SIEN‑M5B‑NS‑S‑L‑P5 |
| Part Number | 8002612 |
| Sensor Type | Inductive Proximity Sensor |
| Mounting Type | Flush‑mount |
| Housing Thread | M5 × 0.5 |
| Nominal Sensing Distance | 1.5 mm |
| Output Type | NPN Normally‑Open |
| Operating Voltage | 10‑30 VDC |
| Max Switching Current | 100 mA |
| Switching Frequency | 2000 Hz |
| Connection | P5 fixed cable, length 0.5 m |
| Protection Class | IP67 |
| Operating Temperature | ‑25 °C ~ +70 °C |
| Overall Dimensions | M5 thread, total length 31 mm |
| Weight | Approx. 18 g |
10 Similar FESTO Products with Comparable Functions
- FESTO SIEN‑M5B‑PS‑S‑L‑P5 Inductive Proximity Sensor
- FESTO SIEN‑M8B‑NS‑S‑L‑P5 Inductive Proximity Sensor
- FESTO SIEN‑M8B‑PS‑S‑L‑P5 Inductive Proximity Sensor
- FESTO SIEN‑M12B‑NS‑S‑L‑P5 Inductive Proximity Sensor
- FESTO SIEN‑M5‑NS‑K‑L‑M5 Inductive Proximity Sensor M5 connector type
- FESTO SIEN‑M5B‑NO‑S‑L‑P5 Normally‑Closed Inductive Sensor
- FESTO SIEF‑M12‑NS‑K‑L‑M12 Inductive Proximity Sensor
- FESTO SIEN‑M18B‑PS‑S‑L‑P5 Inductive Proximity Sensor
- FESTO SIEN‑M30‑NS‑S‑L‑P5 Inductive Proximity Sensor
- FESTO SIEN‑M8‑NS‑S‑L‑P5 Extended‑range Inductive Sensor
