Product Overview
The FESTO NPFV‑AF‑G14‑G14‑MF, part number 563398, is a brand‑new original stainless‑steel pneumatic thread adapter from the FESTO NPFV fitting series. This straight‑through adapter features male‑to‑female G1/4 thread conversion and integrates an internal filter screen. It is specially designed for pneumatic pipeline conversion and impurity filtration in automation systems. Widely applied on solenoid valves, pneumatic cylinders, pressure regulators and other pneumatic components. The built‑in filter mesh intercepts solid particles inside compressed air to prevent valve spool jamming and component damage. Marked as “New Original”, it means genuine factory‑produced fittings, complete sealing components and full‑factory inspection, without refurbishment or secondary processing. It supports ATEX explosive‑atmosphere application scenarios for industrial compressed‑air circuitsFesto.
Main Functions
- Thread conversion: Realizes transition from G1/4 male thread to G1/4 female thread for pneumatic component connection.
- Compressed‑air filtration: Built‑in fine‑mesh filter screen captures dust, metal chips and granular contaminants inside compressed‑air pipelines.
- Pneumatic pipeline connection: Forms stable straight‑through flow channels between valves, actuators and auxiliary pneumatic accessories.
- Detachable filter maintenance: Internal filter screen can be disassembled and cleaned to maintain airflow performance.
- Leak‑proof sealing: Matched NBR sealing element ensures air‑tight performance under normal operating pressure.
- Explosion‑proof compatible installation: Suitable for equipment working in ATEX‑classified hazardous explosive zones.
- Space‑saving inline installation: Compact straight‑body structure for limited installation space inside fixture and machine cabinets.
Technical Characteristics
- Main body made of high‑alloy stainless steel, offering good mechanical strength and low‑level corrosion resistance (CRC 1).
- Integrated reusable filter screen, avoids extra inline filter components and reduces pipeline layout complexity.
- NBR rubber sealing material for reliable compressed‑air sealing performance.
- RoHS‑compliant material composition; conforms to VDMA 24364‑LABS‑PWIS standard for painting‑process equipmentFesto.
- Straight‑through flow channel with 6 mm nominal bore to guarantee stable air flow rate.
- Suitable for standard industrial compressed‑air medium according to ISO 8573‑1.
- Supports installation in ATEX Zone 1, Zone 2, Zone 21 and Zone 22 explosive‑risk environmentssp-sparepa….
- Simple tool‑mounting design; can be assembled and disassembled with standard hexagon spanner.
Core Technical Parameters
| Item | Parameter Value |
|---|---|
| Part Number | 563398 NPFV‑AF‑G14‑G14‑MF |
| Product Type | Pneumatic thread adapter with built‑in filter |
| Thread Port 1 | G1/4 male thread |
| Thread Port 2 | G1/4 female thread |
| Nominal Bore | 6 mm |
| Operating Pressure Range | 0.2 MPa ~ 0.8 MPa (2 bar ~ 8 bar) |
| Filter Mesh Size | 0.1 mm |
| Adapter Body Material | High‑alloy stainless steel |
| Seal Material | NBR |
| Corrosion Resistance Class | CRC 1 (low corrosion stress) |
| Ambient Temperature Range | ‑10 °C ~ +60 °C |
| Weight | 36 g |
| Explosion‑proof Rating | ATEX Zone 1/2/21/22 available |
Product Dimensions
All dimension data are expressed in millimetres.
- Overall total length: 34 mm
- Hexagon nut outer width: 19 mm
- Male‑thread segment length: 11 mm
- Female‑thread inner depth: 12 mm
- Main‑body outer diameter: 19 mm
- Internal flow channel nominal diameter: 6 mm
Note: Appropriate thread sealing compound or PTFE tape is recommended during installation. Do not apply excessive tightening torque to avoid thread deformation and body cracking.
10 FESTO Similar‑function Pneumatic Thread Adapters (NPFV Series)
Below are ten original FESTO NPFV‑series thread adapters with built‑in filter screens, covering different thread standards and thread‑combination forms for diverse pneumatic‑connection requirements:
- NPFV‑AF‑G14‑N14‑MF (563397): G1/4 male to 1/4 NPT female thread adapter, stainless‑steel filter‑type fittingFesto.
- NPFV‑AF‑N14‑N14‑MF (4727333): 1/4 NPT male to 1/4 NPT female thread adapter for North‑American‑standard pneumatic equipment.
- NPFV‑AF‑G18‑G18‑MF (563394): G1/8 male to G1/8 female filter‑equipped adapter for small‑bore valve ports.
- NPFV‑AF‑G18‑N18‑MF (563393): G1/8 male to 1/8 NPT female conversion adapter with internal filter.
- NPFV‑AF‑N18‑N18‑MF (4727332): 1/8 NPT male‑to‑female thread adapter for NPT‑standard miniature pneumatic components.
- NPFV‑AF‑G38‑G38‑MF (563401): G3/8 male‑to‑female filter adapter for large‑flow pneumatic interface conversion.
- NPFV‑AF‑G38‑N38‑MF (563400): G3/8 male to 3/8 NPT female thread transition adapter with filter screen.
- NPFV‑AF‑N38‑N38‑MF (4727334): 3/8 NPT male‑to‑female stainless‑steel filter‑type thread adapter.
- NPFV‑AF‑G12‑G12‑MF (563404): G1/2 male‑to‑female large‑size filter‑adapter for high‑flow pneumatic circuits.
- NPFV‑AF‑G12‑N12‑MF (563403): G1/2 male to 1/2 NPT female conversion adapter with built‑in impurity‑filtering mesh.
