Schneider ZB4BZ105 Single Contact Block with body fixing collar
"*" indicates required fields
Schneider ZB4BZ105 Single Contact Block with Body Fixing Collar
Product Overview
The Schneider ZB4BZ105 is a pre‑assembled, dual‑circuit contact block with an integrated body fixing collar, belonging to the Schneider Electric Harmony XB4 series of 22 mm industrial control components. It serves as the core electrical switching and mounting base for XB4 series push buttons, selector switches, and pilot lights, designed for panel‑mount applications in industrial automation, machinery control, and electrical enclosures. This unit features a 1 Normally Open (1NO) + 1 Normally Closed (1NC) contact configuration, a zinc‑alloy (Zamak) fixing collar for vibration‑resistant installation, and screw‑clamp terminals for secure wiring. It complies with international standards, ensuring reliable performance in harsh industrial environments.
Main Functions
- Dual‑Circuit Switching (1NO + 1NC)
Provides one normally open and one normally closed circuit simultaneously: the NO circuit opens in the resting state and closes when actuated, while the NC circuit closes in the resting state and opens when actuated. This dual configuration is ideal for combined start/stop functions, interlock control, status indication, and safety‑related circuits.
- Integrated Body Fixing Collar
The built‑in zinc‑alloy collar locks the assembly to the control panel without separate hardware, ensuring a stable, anti‑vibration fit for continuous operation.
- Modular Compatibility
Fully compatible with all XB4 series operator heads and stackable with additional contact blocks to create multi‑circuit control solutions.
- Secure Screw‑Clamp Terminals
Tool‑assisted screw terminals provide high clamping force, resisting loosening from vibration or thermal cycling for maintenance‑free electrical connections.
- Standard 22 mm Panel Mount
Designed for a universal 22 mm panel cutout, enabling consistent, fast installation across control panels and machinery interfaces.
Technical Features
表格
| Feature | Specification |
|---|---|
| Series | Harmony XB4 |
| Part Number | ZB4BZ105 |
| Contact Configuration | 1 Normally Open (1NO) + 1 Normally Closed (1NC) |
| Mounting Type | Integrated body fixing collar (zinc‑alloy/Zamak) |
| Panel Cutout | 22 mm (standard) |
| Contact Material | Silver‑nickel alloy |
| Rated Insulation Voltage (Ui) | 600 V |
| Rated Operational Current (Ie) | 10 A (AC‑15, DC‑13) |
| Terminal Type | Screw‑clamp (torque: 0.8–1.2 N·m) |
| IP Rating | IP20 (rear of panel) |
| Mechanical Life | Up to 10 million operations |
| Electrical Life | Up to 1 million operations (at rated load) |
| Operating Temperature | -40 °C to +70 °C |
| Vibration Resistance | Up to 5 g (IEC 60068‑2‑6) |
| Shock Resistance | Up to 30 g (18 ms, IEC 60068‑2‑27) |
| Standards Compliance | IEC 60947‑5‑1, UL 508, CSA C22.2 No. 14, RoHS |
Product Dimensions
- Panel Cutout Diameter: 22 mm
- Fixing Collar Outer Diameter: 30 mm
- Overall Length (Rear of Panel): 47 mm
- Stacking Pitch (for Multi‑Pole Assemblies): 12 mm
- Body Width: 30 mm
Weight
- Net Weight: 28 grams (complete assembly: collar, body, 1NO + 1NC contact block)
