Schneider ZB4BZ101 Single Contact Block with Body Fixing Collar
Product Overview
The Schneider ZB4BZ101 is a modular, single‑pole contact block assembly with an integrated body fixing collar, belonging to the Schneider Electric Harmony XB4 series of 22mm industrial control components. It is a complete mounting base and contact unit designed to form the core electrical switching element of XB4 series push buttons, selector switches, and indicator lights. This assembly combines a robust zinc‑alloy fixing collar, a durable plastic body, and a single normally open (1NO) contact element, providing a reliable, pre‑assembled solution for panel‑mounted control circuits. It is engineered for industrial automation, machinery control, and electrical panel applications, ensuring stable electrical performance and secure mechanical installation.
Main Functions
- Single‑Pole Normally Open (1NO) Switching
The ZB4BZ101 features a single normally open (1NO) contact configuration, which opens the circuit in its resting state and closes it when actuated by an XB4 series operator head. This is ideal for control functions such as start signals, momentary actuation, and status indication in industrial circuits.
- Integrated Body Fixing Collar
It includes a built‑in zinc‑alloy fixing collar that securely locks the contact block assembly to the control panel, eliminating the need for separate mounting hardware and ensuring stable, vibration‑resistant installation.
- Modular Compatibility with XB4 Series
The unit is fully compatible with all XB4 series operator heads (e.g., push buttons, selector switches, mushroom heads) and can be stacked with additional contact blocks (up to 6 poles) to create multi‑circuit control assemblies.
- Secure Electrical Connection
Equipped with screw‑clamp terminals for reliable, tool‑assisted wiring, ensuring secure electrical connections that resist loosening due to vibration or thermal cycling.
- Standard 22mm Panel Mounting
Designed for a standard 22mm panel cutout, enabling quick and consistent installation across industrial control panels, operator consoles, and machinery interfaces.
Technical Features
表格
| Feature | Specification |
|---|---|
| Series | Harmony XB4 |
| Part Number | ZB4BZ101 |
| Contact Configuration | 1 Normally Open (1NO) |
| Mounting Type | Integrated body fixing collar (zinc‑alloy) |
| Panel Cutout | 22 mm (standard) |
| Contact Material | Silver‑nickel alloy (high conductivity, long life) |
| Rated Insulation Voltage (Ui) | 600 V |
| Rated Operational Current (Ie) | 10 A (AC‑15, DC‑13) |
| Terminal Type | Screw‑clamp terminals |
| Protection Rating (IP) | IP20 (rear of panel) |
| Mechanical Life | Up to 10 million operations |
| Electrical Life | Up to 1 million operations (at rated load) |
| Operating Temperature | -25°C to +70°C |
| Standards Compliance | IEC 60947‑5‑1, RoHS compliant |
| Key Advantages | – Pre‑assembled collar‑body‑contact unit for simplified installation
– High‑grade silver‑nickel contacts for low resistance and long life – Vibration‑resistant zinc‑alloy fixing collar – Stackable design for multi‑pole configurations – Screw terminals for secure, maintenance‑free wiring |
Product Dimensions
- Panel Cutout Diameter: 22 mm
- Overall Diameter (Fixing Collar): 30 mm
- Overall Length (from panel rear): Approximately 45 mm
- Stacking Pitch: 12 mm (for multi‑block assembly)
Weight
- Net Weight: Approx. 23 grams (complete assembly including fixing collar, body, and contact block)
