Festo 1366958 DSBC-50-400-PPVA-N3 ISO Cylinder
"*" indicates required fields
New Original Festo 1366958 DSBC-50-400-PPVA-N3 ISO Cylinder: Detailed Introduction
Product Overview
The Festo 1366958 (DSBC-50-400-PPVA-N3) is a ISO 15552 standard double-acting pneumatic cylinder from the DSBC series, designed for precise linear motion in industrial automation systems. Featuring a profiled barrel, single piston rod, and pneumatic end-position cushioning, it delivers reliable performance in a compact, corrosion-resistant design. Suitable for harsh industrial environments and cleanroom operations (Class 6 per ISO 14644-1), it is ideal for clamping, lifting, pushing, and positioning tasks in assembly lines, material handling, and general automation.
Key Functions
- Linear Motion Actuation: Converts compressed air energy into precise, controlled linear movement for double-acting loads.
- Dual-End Pneumatic Cushioning: Absorbs impact at both ends of the stroke to protect the cylinder and workpiece, with adjustable cushioning.
- Position Sensing: Compatible with proximity sensors for reliable position detection, enabling closed-loop control.
- Versatile Mounting: Supports multiple installation options (via female thread or accessories) for flexible system integration.
- High Force Output: Generates substantial pushing/pulling forces at standard operating pressures for heavy-duty tasks.
- Lubrication Flexibility: Operates with or without lubrication (lubricated operation requires continuous lubrication thereafter).
Technical Characteristics
Core Performance Specifications
表格
| Parameter | Detail |
|---|---|
| Order Number | 1366958 |
| Model | DSBC-50-400-PPVA-N3 |
| Operation Mode | Double-actingFesto |
| Piston Diameter | 50 mmFesto |
| Stroke | 400 mmFesto |
| Piston Rod Thread | M16x1.5 (male)Festo |
| Operating Pressure Range | 0.4 – 12 bar (0.04 – 1.2 MPa) |
| Theoretical Force (6 bar/87 psi) | Advancing: 1178 N; Retracting: 990 NFesto |
| Pneumatic Connection | G1/4 |
| Cushioning | Pneumatic, adjustable at both ends; cushion length 22 mmFesto |
| End Position Impact Energy | 1 JFesto |
| Mounting Position | Any |
| Corrosion Resistance Class (CRC) | 2 (moderate corrosion stress)Festo |
| Standards Compliance | ISO 15552, VDMA 24364-B1/B2-L, RoHSFesto |
| Cleanroom Suitability | Class 6 per ISO 14644-1Festo |
Material & Construction
表格
| Component | Material / Specification |
|---|---|
| Cylinder Barrel | Wrought aluminum alloy, smooth-anodized |
| Cover | Die-cast aluminum, coated |
| Piston | Wrought aluminum alloy |
| Piston Rod | High-alloy steel |
| Seals (Piston/Rod/Buffer) | TPE-U(PU) (polyurethane) for wear and oil resistance |
| Cushion Piston | POM (polyoxymethylene) |
| Rod Wiper | TPE-U(PU) |
| Bearings | POM |
| Tie Rods & Nuts | High-alloy steel/galvanized steel |
| Operating Medium | Compressed air to ISO 8573-1:2010 [7:4:4]Festo |
Environmental & Operational Limits
表格
| Attribute | Specification |
|---|---|
| Ambient Temperature | -20 °C to +80 °CFesto |
| Media Temperature | -20 °C to +80 °CFesto |
| Vibration Resistance | Complies with relevant industrial standards |
| Shock Resistance | Complies with relevant industrial standards |
| Max. Switching Frequency | Application-dependent (optimized for continuous duty) |
Physical Dimensions & Weight
表格
| Dimension | Value |
|---|---|
| Overall Length | 577.8 mm |
| Bore Diameter | 50 mmFesto |
| Piston Rod Diameter | 16 mm (M16x1.5 thread)Festo |
| Width/Height | 64 mm (standard ISO profile) |
| Basic Weight (0 mm stroke) | 1190 g |
| Additional Weight per 10 mm Stroke | 56 g |
| Total Weight (400 mm stroke) | Approx. 3390 g (1190 g + 40×56 g) |
| Cushion Length (each end) | 22 mmFesto |
Operational Advantages
- ISO Standard Compatibility: Interchangeable with other ISO 15552 cylinders for easy system replacement and expansion.
- Smooth, Shock-Free Operation: Adjustable pneumatic cushioning minimizes wear and noise, protecting loads and equipment.
- Durable Construction: Anodized aluminum barrel and high-alloy steel components ensure long service life in demanding environments.
- Flexible Integration: G1/4 ports, multiple mounting options, and sensor compatibility simplify installation in new or existing systems.
- Energy Efficiency: Optimized sealing and low-friction design reduce air consumption and operational costs.
- Cleanroom Ready: Suitable for precision manufacturing environments with low particle emission.
