Keyence LR – W500C Self – Contained Full – Spectrum Sensor (LRW500C)

Product Overview

The Keyence LR – W500C is a self – contained full – spectrum photoelectric sensor with an M12 4 – pin connector, tailored for high – precision object detection, color differentiation, and surface feature inspection in industrial automation fields including electronics manufacturing, packaging, automotive component assembly, and food processing. It is equipped with a white LED light source, a 30–500 mm detecting distance, and an adjustable beam spot (ø3.5 mm at 100 mm, ø9 mm at 250 mm, ø18 mm at 500 mm), enabling flexible adaptation to various object sizes and detection distances基恩士. With selectable NPN/PNP open – collector outputs, multiple response time settings, and IP65/IP67 protection, it can stably operate in harsh industrial environments (- 20 to + 50 °C, dust, water exposure). Its 110 g lightweight zinc die – cast housing and M12 4 – pin connector facilitate flexible mounting and quick connection, and it supports mutual interference reduction (up to 2 units with alternate frequencies) and timer functions, making it a reliable choice for diverse inline automation tasks to enhance production accuracy and efficiency基恩士.

Main Functions

Full – Spectrum Color and Surface Inspection

It can detect subtle color differences, surface finish variations, and texture changes that are difficult to identify with the naked eye, suitable for applications such as color sorting of electronic components, quality inspection of printed packaging, and detection of surface defects on automotive parts, ensuring consistent product quality.
Adjustable Beam Spot for Diverse Detection Needs

The adjustable beam spot (ø3.5 mm at 100 mm to ø18 mm at 500 mm) enables precise detection of small parts and reliable identification of large – area objects, meeting the requirements of different production scenarios from small – scale assembly to large – batch packaging.
Flexible Output and Timer Configuration

It offers selectable NPN/PNP open – collector outputs (NO/NC switchable) and multiple response time settings (200 µs–500 ms), along with timer functions (OFF/ON delay/OFF delay/one – shot). This allows synchronization with production line speeds and precise control of output signals, optimizing the automation processKEYENCE FRANCE SAS.
Anti – Interference and Stable Performance

The mutual interference reduction function supports up to 2 units to operate simultaneously with alternate frequencies, avoiding signal crosstalk. The IP65/IP67 protection rating and a wide operating temperature range (- 20 to + 50 °C) ensure stable operation in dusty, wet, or temperature – varying industrial settings.
Easy Integration and Operation

The M12 4 – pin connector simplifies connection to industrial control systems, and the intuitive setting buttons enable quick parameter configuration. It can be easily integrated with PLCs and other automation equipment, reducing setup time and improving work efficiency.

Technical Features

Feature	Details
Sensor Type	Self – contained full – spectrum photoelectric sensor, M12 4 – pin connector type
Light Source	White LED
Detecting Distance	30–500 mm
Minimum Spot Diameter	Adjustable beam spot: ø3.5 mm at 100 mm, ø9 mm at 250 mm, ø18 mm at 500 mm
Output Configuration	NPN/PNP open – collector selectable; NO/NC switchable; Max 30 VDC, 50 mA, residual voltage ≤ 2 V
Response Time	200 µs, 1 ms, 10 ms, 100 ms, 500 ms (selectable)
Timer Functions	OFF/ON delay/OFF delay/one – shot
Power Supply	10–30 VDC; Current consumption: ≤ 120 mA (12 VDC, no load), ≤ 60 mA (24 VDC, no load)
Environmental Resistance	Operating temp: – 20–+50 °C; Storage temp: – 30–+60 °C Relative humidity: 35–85 % RH (no condensation) Vibration resistance: 10–55 Hz, 1.5 mm double amplitude, X/Y/Z axes for 2 hours each Shock resistance: 1000 m/s², 6 times in 6 directions Protection rating: IP65/IP67 Ambient light resistance: Incandescent lamp 10,000 lux max; Sunlight 20,000 lux max
Material	Case: Zinc die cast (nickel – chrome plating); Indicator cover: PPSU; Buttons: PES; Lens cover/display: PMMA (scratch – resistant coating); Connector ring: PMP; Connector socket: PEI

Product Dimensions and Weight

Item	Details
Overall Dimensions	30 mm (W) × 30 mm (H) × 52 mm (D) (approx.)
Connector	M12 4 – pin type (cable sold separately)
Weight	Approximately 110 g (sensor head only)
Mounting	M3 screw mounting for flexible installation in production lines
Indicator Lights	Red LED (output ON), Green LED (stable operation), Orange LED (setting mode)
