Festo VEAB-B-26-D14-F-V1-1R1 Proportional Pressure Regulator (Order Code: 8046271)

Product Overview

The Festo VEAB-B-26-D14-F-V1-1R1 is a high-precision proportional pressure regulator engineered for dynamic, closed-loop pressure control in industrial pneumatic systems. As a core component of Festo’s VEAB series, this regulator converts electrical input signals into precise, adjustable output pressure—enabling fine-tuned control of pneumatic actuators such as proportional cylinders, grippers, and servo valves. It is optimized for applications requiring variable pressure regulation, including precision assembly, material testing, packaging machinery, and automotive component manufacturing. Its modular design, integrated electronics, and robust construction ensure seamless integration into automated control systems and reliable operation in harsh industrial environments.

Product Dimensions

Parameter	Specification
Overall Width	60 mm
Overall Height	185 mm
Overall Depth	120 mm
Pneumatic Inlet Port Size	G1/4
Pneumatic Outlet Port Size	G1/4
Electrical Connector Type	D-sub 9-pin male
Mounting Hole Pitch	45 mm (widthwise) × 110 mm (depthwise)
Mounting Compatibility	Panel mounting; compatible with Festo air preparation units and valve manifolds

Main Functions

Closed-Loop Proportional Pressure Control
- Converts analog electrical input signals (0–10 V DC or 4–20 mA) into proportional output pressure, with an adjustable regulation range of 0.2–10 bar. The integrated pressure sensor provides real-time feedback for closed-loop control, ensuring output pressure accuracy even with fluctuating inlet pressure or downstream air consumption.
- Supports dynamic pressure adjustment with fast response times, enabling smooth pressure ramping and precise pressure holding for high-precision automation tasks (e.g., force control in press-fitting applications).
Integrated Electronics & Signal Processing
- Features built-in signal conditioning and amplification, eliminating the need for external control modules and simplifying system wiring. The regulator is compatible with standard PLC analog output signals for direct integration into automated control systems.
- Offers configurable pressure ramping rates and response times via software or manual adjustment, allowing customization for specific application requirements (e.g., slow ramping for delicate component handling, fast response for high-cycle operations).
Diagnostics & Safety Functions
- Incorporates comprehensive self-diagnostic capabilities, including overpressure detection, sensor fault monitoring, and electrical signal loss alarms. Fault status is indicated via LED indicators on the front panel for quick on-site troubleshooting.
- Equipped with a safe exhaust function that vents output pressure to atmospheric levels in case of power loss or system fault, preventing unintended actuator movement and enhancing operational safety.

Technical Features

High-Precision Performance
- Delivers exceptional pressure regulation accuracy with a linearity error ≤ ±1% of full scale and a repeatability error ≤ ±0.5% of full scale, ensuring consistent output pressure for critical automation processes.
- Achieves a fast response time of ≤ 50 ms (for 90% pressure step change), enabling dynamic pressure control for high-speed production lines.
- Supports a maximum flow rate of 800 L/min (at 6 bar outlet pressure), meeting the air demand of medium-sized pneumatic circuits with proportional actuators.
Robust Industrial Construction & Durability
- Housing Material: Die-cast aluminum alloy with a corrosion-resistant powder coating, providing excellent resistance to mechanical shock, vibration, and ambient moisture. Internal components are made of brass, stainless steel, and reinforced polymer to ensure long service life.
- Sealing System: Fluorocarbon rubber (FKM) seals for reliable airtightness and compatibility with a wide range of compressed air media, including dry and lubricated air.
- Protection Class: IP65 (front side), protecting the regulator from dust, water spray, and oil contamination in harsh manufacturing environments such as machining workshops and automotive assembly lines.
- Temperature Resistance: Operates reliably in a temperature range of -10 °C to +60 °C, ensuring stable performance across varying industrial temperature conditions.
Energy Efficiency & Compliance
- Optimized internal valve design minimizes pressure drop and air leakage, reducing compressed air consumption and lowering overall system energy costs.
- Fully compliant with international standards including ISO 15407-2 (pneumatic proportional valves), IEC 61131-2 (industrial control equipment), CE, and RoHS, ensuring global market compatibility and adherence to environmental regulations.
- Each unit undergoes rigorous factory testing for pressure accuracy, response time, and safety functionality to meet Festo’s strict quality standards.

Weight

The net weight of the Festo VEAB-B-26-D14-F-V1-1R1 proportional pressure regulator is approximately 1.9 kg, balancing robust construction with ease of handling during installation, maintenance, and system configuration.
