Festo VACN-H1-A1-1 Solenoid Coil (Order Code: 8022877)

Product Overview

The Festo VACN-H1-A1-1 is a high-efficiency, compact DC solenoid coil engineered for precise actuation of Festo proportional and directional control valves in industrial automation systems. Tailored for applications requiring rapid response and stable electromagnetic force—such as precision fluid control, pneumatic valve positioning, and automated process regulation—this coil is fully compatible with Festo’s advanced valve series (e.g., proportional pressure regulators, high-speed directional valves). Its low-power consumption, robust construction, and standardized mounting interface ensure seamless integration and long-term reliability in harsh manufacturing environments, including automotive assembly lines, pharmaceutical production equipment, and electronic component handling systems.

Product Dimensions

Parameter	Specification
Overall Diameter	24 mm
Overall Length (Including Connector)	48 mm
Mounting Bore Diameter	16 mm
Coil Bobbin Outer Diameter	20 mm
Electrical Connector Type	3-pin plug-in (DIN 43650 A-code, with polarity marking)
Mounting Compatibility	Fits Festo valves with 16 mm diameter armatures; compatible with valve manifolds and panel-mounted installations

Main Functions

High-Precision Valve Actuation
- Converts a stable 24 V DC input into controlled electromagnetic force to drive the armature of Festo proportional or directional control valves. This force enables precise positioning of valve spools, supporting functions such as variable flow regulation, pressure modulation, and fast on/off switching for pneumatic actuators (cylinders, grippers).
- Delivers a consistent holding force of 18 N at rated voltage, ensuring reliable valve positioning even under fluctuating system pressure or vibration.
Status Monitoring & Fault Diagnosis
- Integrates a built-in LED status indicator that provides visual confirmation of coil energization. This allows maintenance personnel to quickly identify power supply issues, coil malfunctions, or control signal faults on-site, minimizing system downtime and simplifying troubleshooting.
- The plug-in connector design with clear polarity marking prevents reverse wiring, eliminating the risk of coil burnout and ensuring safe, error-free installation.
Energy-Efficient Operation
- Features a low-power consumption design (rated power: 3 W) that reduces energy usage in continuous operation scenarios, lowering overall system operating costs. The coil’s optimized electromagnetic circuit minimizes heat generation, preventing thermal overload and extending service life in high-cycle applications.

Technical Features

Advanced Electromagnetic Design
- Adopts a precision-wound copper wire coil with a low-resistance circuit, delivering a fast response time of ≤ 5 ms for valve actuation—critical for high-speed automation processes requiring synchronized motion control.
- The ferrite core construction enhances magnetic flux density, ensuring stable force output across the entire operating temperature range and eliminating performance degradation due to heat buildup.
Robust Industrial Construction & Durability
- Housing Material: Flame-retardant glass-reinforced polyamide (UL94 V-0 rating) that provides excellent resistance to mechanical shock, vibration, and chemical corrosion (oil mist, dust, and mild solvents) in industrial environments.
- Protection Class: IP65 (when mated with a compatible valve body), preventing ingress of dust and water spray and ensuring reliable operation in outdoor or harsh factory floor settings.
- Temperature Resistance: Operates reliably in a range of -25 °C to +60 °C, with thermal overload protection to prevent damage during prolonged continuous use.
- Service Life: Up to 20 million switching cycles under standard operating conditions, reducing replacement frequency and maintenance costs for critical automation systems.
Compliance & Safety Certification
- Fully compliant with international standards including IEC 61558-2-6 (safety of transformers and inductors), CE, and RoHS, ensuring global market compatibility and adherence to environmental and safety regulations.
- Designed with short-circuit protection capabilities, safeguarding the coil and connected control systems from electrical faults.

Weight

The net weight of the Festo VACN-H1-A1-1 solenoid coil (order code 8022877) is approximately 0.04 kg (40 grams), making it extremely lightweight and easy to handle during installation, replacement, and inventory management.
