Festo NTSD-WD-11 Power Supply Socket (Order Code: 533119)

Product Overview

The Festo NTSD-WD-11 is a compact, industrial-grade power supply socket designed specifically for reliable electrical connection of Festo solenoid coils and small pneumatic control components in automation systems. As a key accessory in Festo’s electrical connection portfolio, this socket features a secure plug-in design that simplifies wiring, reduces installation time, and ensures stable power transmission even in high-vibration industrial environments. It is ideal for use in assembly lines, packaging machinery, and material handling systems, where consistent power supply to solenoid valves is critical for uninterrupted operation. The socket’s robust construction and compliance with international standards make it compatible with a wide range of Festo solenoid coils and industrial control equipment.

Product Dimensions

Parameter	Specification
Overall Width	22 mm
Overall Height	35 mm
Overall Depth	40 mm
Electrical Connector Type	2-pin plug-in (mating with DIN 43650 A connectors)
Mounting Hole Pitch	18 mm (center-to-center)
Mounting Compatibility	Panel mounting; compatible with Festo solenoid valve manifolds and control cabinets
Cable Entry Size	M12 thread (for cable gland installation)

Main Functions

Secure Power Transmission
- Serves as a dedicated interface to supply electrical power to Festo solenoid coils (e.g., MSFW series), converting a stable input voltage into the precise power required for valve actuation. The socket’s spring-loaded contact pins ensure low-resistance, vibration-resistant electrical connection, preventing signal or power loss during high-cycle automation operations.
- Supports a rated voltage range of 24 V DC to 230 V AC, making it versatile for use with different solenoid coil configurations and global power supply standards.
Simplified Wiring & Maintenance
- Features a tool-free plug-in connection for solenoid coils, eliminating the need for soldering or complex wiring and reducing human error during installation. The socket’s clear polarity marking ensures correct electrical connection, preventing damage to coils from reverse polarity.
- Enables quick disconnection of solenoid coils for maintenance or replacement without disrupting the entire system’s power supply, minimizing downtime in production environments.
Protection & Status Monitoring
- Incorporates a built-in LED status indicator that provides visual confirmation of power supply to the connected solenoid coil. This allows maintenance personnel to quickly diagnose power supply faults, coil malfunctions, or wiring issues on-site without additional testing equipment.
- The socket’s enclosed contact design provides basic protection against dust and accidental contact, enhancing operational safety in industrial settings.

Technical Features

Robust Industrial Construction
- Housing Material: Flame-retardant glass-reinforced polymer (UL94 V-0 rating) that offers excellent resistance to mechanical shock, vibration, and chemical corrosion from oil mist and dust in manufacturing environments.
- Protection Class: IP20 (when mounted in a control cabinet), preventing ingress of solid particles and ensuring safe operation in enclosed electrical enclosures. For field installation, it can be paired with IP65-rated cable glands to enhance environmental protection.
- Temperature Resistance: Operates reliably in a temperature range of -25 °C to +55 °C, suitable for use in extreme industrial conditions including cold storage facilities and high-heat assembly lines.
High Performance & Reliability
- Rated Electrical Parameters: Supports a maximum current of 2 A and a rated power of up to 460 VA, sufficient for powering most Festo solenoid coils and small control components.
- Contact Durability: The silver-plated contact pins ensure low electrical resistance and wear resistance, with a service life of up to 10,000 mating cycles—ideal for applications requiring frequent maintenance or component replacement.
- Voltage Compatibility: Works with both DC and AC power supplies, with a wide input range that accommodates global industrial voltage standards (24 V DC, 110 V AC, 230 V AC).
Compliance & Safety
- Fully compliant with international standards including IEC 60947-5-1 (industrial low-voltage switchgear) and CE certification, ensuring adherence to global safety and quality requirements.
- RoHS-compliant design eliminates hazardous substances, making it suitable for use in environmentally sensitive applications and markets.

Weight

The net weight of the Festo NTSD-WD-11 power supply socket (order code 533119) is approximately 0.03 kg (30 grams), making it extremely lightweight and easy to handle during installation, inventory management, and system configuration.
