Festo NEBA-M8G3-U-5-N-M8G3 Connecting Cable (Order Number: 8078287)
Product Overview
The Festo NEBA-M8G3-U-5-N-M8G3 (Order Number: 8078287) is a premium 5-meter industrial connecting cable engineered for reliable signal and power transmission between 3-pin sensors, actuators, and control systems in automation setups费斯托. It is optimized for energy chain and robotic applications, enduring repeated motion, bending, and torsion while performing stably in harsh industrial environments with oil, chemicals, UV rays, and ozone exposure费斯托. Compliant with IEC 61010-1, IEC 61010-2-202, EN 61076-2-104, and EN 61984, it integrates seamlessly with Festo electrically operated valves and diverse industrial field devices, and holds c UL us – Listed (OL) and RoHS certifications for safety and environmental complianceFesto.
Main Functions
| Function | Description |
|---|---|
| Industrial Device Interconnection | Links 3-pin sensors/actuators to controllers, enabling consistent data and power transfer in automated production lines费斯托. |
| Harsh Environment Endurance | Operates reliably amid oil, lubricants, hydrolysis, microbes, UV radiation, and ozone, guaranteeing long-term stability费斯托. |
| Motion Application Suitability | Ideal for energy chain and robotic setups, withstanding continuous bending, torsion, and movement without signal degradation费斯托. |
| Enhanced Safety Assurance | Features flame-retardant, self-extinguishing properties and a high protection class (IP65/IP68/IP69K when assembled) to mitigate industrial safety risksFesto. |
| Convenient Installation | Comes with rotatable M8 screw-locking connectors (9 mm hexagon + longitudinal knurling) for secure, flexible assembly and easy cable routing in tight spacesFesto. |
Technical Features
Core Electrical Characteristics
| Characteristic | Value |
|---|---|
| Conductor Structure | 3×0.25 mm²费斯托 |
| Nominal Conductor Cross-Section | 0.25 mm²费斯托 |
| Operating Voltage | DC 0-60 V; AC 0-48 V (30 V max for UL NEC/CEC CLASS 2 circuits) |
| Current Rating (40°C, derated) | 4 A (derating required at 40°C) |
| Surge Resistance | 1.5 kV费斯托 |
| Protection Class (Assembled) | IP65, IP68, IP69KFesto |
| Certifications | c UL us – Listed (OL), RoHS compliantFesto |
Mechanical Durability (Tested at 23°C)
| Durability Metric | Performance |
|---|---|
| Torsion Resistance | >300,000 cycles, ±270°/0.1 m费斯托 |
| Flexural Fatigue | >50,000 cycles, 5 mm bending radius费斯托 |
| Energy Chain Service Life | >5 million cycles, 28 mm bending radius费斯托 |
| Minimum Fixed Bending Radius | ≥12 mm费斯托 |
| Minimum Moving Bending Radius | ≥39 mm费斯托 |
Material & Environmental Resistance
| Item | Details |
|---|---|
| Cable Sheath | TPE-U (PUR): wear-resistant, low-adhesion, flame-retardant, self-extinguishing费斯托 |
| Connector Housing | TPE-U (PU) for durability and chemical resistance |
| Electrical Contacts | Gold-plated brass for optimal conductivity and corrosion resistance |
| Resistance Traits | Oil, lubricant, hydrolysis, microbe, UV, and ozone resistant费斯托 |
| Ambient Temperature | -20°C to +80°C (standard); suitable for moving applications within this range费斯托 |
Product Dimensions & Weight
| Parameter | Value |
|---|---|
| Cable Length | 5 m (as per product code)费斯托 |
| Cable Diameter | 3.8 mm费斯托 |
| Connector Type | 2 straight M8x1 A-coded sockets (female)Festo |
| Mounting Mechanism | Threaded lock (9 mm hexagon + longitudinal knurling, rotatable)Festo |
| Product Weight | Approximately 150 g (minor batch variations) |
Installation & Safety Guidelines
- Secure Assembly: Utilize the threaded connectors for a firm fit; the rotatable design simplifies routing in confined areasFesto.
- Current Derating: Apply a derating factor to the 4 A current load at 40°C ambient temperature to prevent overheating费斯托.
- UL Circuit Restrictions: For UL applications, limit to energy-limited circuits with max 4 A current and 30 VDC open-circuit voltage (NEC/CEC CLASS 2)费斯托.
- Test Context: All mechanical durability data (torsion, flexure, energy chain) is based on 23°C testing; results are standard – condition references费斯托
