Festo JMN1H-5/2-D-2-C Solenoid Valve (Order Code: 159702)

Product Overview

Product Dimensions

Main Functions

1. 5/2-Way Pneumatic Flow Control
   • Serves as a directional control valve to switch compressed air supply between two output ports (A and B) while exhausting air through the exhaust port (R or S). This enables bidirectional actuation of double-acting pneumatic cylinders, controlling their extension and retraction.
   • Operates in monostable mode: the valve returns to its default position (e.g., port A pressurized, port B exhausted) when the solenoid is de-energized, ensuring fail-safe operation in case of power loss.
   • Supports a maximum flow rate of 600 L/min (at 6 bar pressure), meeting the demand for fast actuator response in high-cycle automation tasks.
2. Electrical Signal Integration
   • Accepts a 24 VDC electrical control signal, compatible with standard PLC digital output modules for direct system integration. The plug-in electrical connector ensures quick, tool-free wiring and reduces installation time.
   • Features a built-in LED status indicator that displays the solenoid’s energization state, enabling easy on-site troubleshooting of valve and control system faults.
3. Modular System Expansion
   • Can be mounted individually or integrated into Festo valve manifolds to create multi-valve control stations, eliminating the need for complex individual piping and streamlining pneumatic system design.
   • Compatible with Festo’s full range of pneumatic accessories, including flow regulators, check valves, and pressure sensors, for customized system functionality.

Technical Features

1. Fast Response & High Reliability
   • Achieves a valve switching time of ≤ 15 ms for both energization and de-energization, ensuring rapid actuation of pneumatic devices and optimizing production line cycle times.
   • Adopts Festo’s proprietary pilot valve technology, which reduces the minimum operating pressure to 1 bar, enabling stable operation even with low air supply pressure—ideal for low-power pneumatic systems.
   • Boasts a service life of up to 100 million switching cycles under standard operating conditions, minimizing replacement frequency and maintenance costs.
2. Robust Industrial Design
   • Protection Class: IP65 (front side), protecting the valve from dust, water spray, and oil contamination in harsh manufacturing environments. The housing is made of high-strength glass-reinforced polymer with flame-retardant properties (UL94 V-0).
   • Operating Temperature Range: -10 °C to +50 °C, suitable for use in temperature-variable environments such as food processing plants and automotive assembly lines. Special seals are available for extended temperature ranges (-20 °C to +60 °C).
   • Corrosion Resistance: The valve’s internal components are made of nickel-plated brass and stainless steel, providing excellent resistance to corrosion from compressed air impurities and ambient moisture.
3. Energy Efficiency & Compliance
   • Low power consumption: the solenoid coil consumes only 1.5 W of power, minimizing energy usage in continuous operation scenarios and reducing overall system operating costs.
   • Fully compliant with international standards including ISO 15407-2 (pneumatic valves), CE, and RoHS, ensuring global market compatibility and environmental friendliness.

Weight

• The net weight of the Festo JMN1H-5/2-D-2-C solenoid valve (order code 159702) is approximately 0.38 kg, making it lightweight and easy to handle during installation, maintenance, and system configuration.
