Festo DSBC-40-60-PPVA-N3 ISO Cylinder (Order Code: 2123224)

Product Overview

The Festo DSBC-40-60-PPVA-N3 is a robust, ISO 15552-compliant pneumatic cylinder designed for heavy-duty linear motion control in industrial automation systems. As part of Festo’s DSBC series, this double-acting cylinder delivers high thrust, smooth operation, and exceptional durability, making it ideal for applications such as material handling, clamping, pressing, and assembly line actuation. Its standardized design ensures seamless integration with global automation equipment, while built-in features like adjustable cushioning and position sensing readiness optimize performance and reduce maintenance effort.

Product Dimensions

Parameter	Specification
Bore Diameter	40 mm
Stroke Length	60 mm
Overall Length (Retracted)	184 mm
Overall Length (Extended)	244 mm
Piston Rod Diameter	16 mm
Width (Mounting Flange)	80 mm
Height (Mounting Flange)	80 mm
Pneumatic Port Size	G1/8
Mounting Hole Diameter	12 mm
Mounting Hole Pitch	60 mm (lengthwise) × 60 mm (widthwise)

Mounting Compatibility: Supports front flange, rear flange, foot, and trunnion mounting configurations, fully compliant with ISO 15552 mounting standards for flexible system integration.

Main Functions

High-Thrust Linear Actuation
- Double-Acting Operation: Delivers bidirectional linear motion by alternately supplying compressed air to the cap and rod sides of the piston. At a supply pressure of 6 bar, it generates a maximum thrust force of 754 N (cap side) and a retraction force of 565 N (rod side), suitable for heavy-load automation tasks.
- Smooth Motion Control: Equipped with adjustable pneumatic cushioning (PPVA) at both end positions, allowing users to fine-tune deceleration to minimize impact, noise, and mechanical wear during cyclic operation—critical for high-speed production lines.
Position Sensing & System Integration
- Features integrated T-slots on the cylinder barrel, enabling easy installation of Festo proximity sensors (e.g., SMT-8M-A) for non-contact position detection. This provides real-time feedback to PLCs, supporting closed-loop control for precise positioning tasks.
- Standardized G1/8 pneumatic ports and threaded piston rod ends ensure compatibility with a wide range of pneumatic accessories, including valves, fittings, and end-effectors like grippers and push plates.
Durability & Maintenance Optimization
- Modular design allows quick replacement of wear parts (e.g., piston seals, rod bearings) without disassembling the entire cylinder, minimizing downtime during maintenance.
- The cylinder’s corrosion-resistant surface treatment ensures reliable operation in harsh industrial environments with dust, moisture, or mild chemical exposure.

Technical Features

Robust Industrial Construction
- Material Specifications: Hard-anodized aluminum barrel for lightweight strength; high-strength steel piston rod with hard chrome plating to resist wear and corrosion; nitrile rubber (NBR) seals for reliable airtightness and long service life.
- Protection Class: IP65 (rod end), protecting the piston rod and seals from dust, water spray, and oil contamination in demanding manufacturing environments.
- Service Life: Up to 30 million cycles under standard operating conditions, reducing replacement costs and ensuring long-term system reliability.
Performance & Environmental Adaptability
- Operating Pressure Range: 1–10 bar, enabling flexible adaptation to low and high-pressure pneumatic systems. Maximum operating speed: 1 m/s, with stable motion maintained at speeds as low as 0.005 m/s.
- Temperature Resistance: -20 °C to +80 °C (with standard seals), suitable for use in extreme temperature environments such as cold storage facilities and high-heat welding stations.
- Low-Friction Operation: Precision-machined piston and barrel interface minimize internal friction, reducing energy consumption and ensuring consistent performance over the cylinder’s service life.
Compliance & Certification
- Fully compliant with ISO 15552 standards for pneumatic cylinders, ensuring interchangeability with other ISO-compliant components from different manufacturers.
- Meets international safety and environmental standards including CE, RoHS, and UL, ensuring global market acceptance and compliance with regional regulatory requirements.

Weight

The net weight of the Festo DSBC-40-60-PPVA-N3 ISO cylinder is approximately 1.8 kg, balancing structural rigidity with ease of handling during installation and maintenance.
