SMC G36-10-01 Pressure Gauge (G361001)
1. Product Overview
The SMC G36-10-01 is a general-purpose analog pressure gauge belonging to the G36 series, designed for real-time pressure monitoring in pneumatic systems. It has a 36 mm outer diameter, a measurement range of 0 to 1.0 MPa (0 to 10 bar), and ±3% full – scale accuracy, making it suitable for routine pressure checks in industrial automation, packaging, automotive assembly, and general machinery applications. With a back – side R1/8 threaded connection, it allows for easy integration into air preparation units, valves, and cylinder lines. Its robust mechanical structure, clear 36 mm dial, and durable housing ensure reliable performance and easy reading in standard industrial settings, meeting the basic pressure monitoring needs of most pneumatic systems with long – term stability and low maintenance requirements.
2. Main Functions
| Function | Detailed Description |
|---|---|
| Real – time Pressure Display | Uses a Bourdon tube mechanism to convert air pressure into pointer rotation, providing clear analog readings for quick on – site pressure checks and system status assessment. |
| System Pressure Monitoring | Monitors the pressure of compressed air in pneumatic circuits, enabling timely detection of pressure fluctuations, leaks, or abnormal operations to maintain stable system performance. |
| Process Optimization & Safety | Facilitates precise pressure adjustment of regulators and filters, preventing equipment damage from over – pressure and ensuring compliance with operational safety standards. |
| Easy Installation & Integration | Features a back – side R1/8 thread for direct mounting on panels or pipelines, compatible with standard pneumatic fittings for quick setup and replacement. |
| Visual Status Indication | The large 36 mm dial with clear markings allows operators to quickly identify pressure levels, supporting efficient troubleshooting and maintenance workflows. |
3. Technical Features
- Bourdon Tube Sensing: A brass Bourdon tube serves as the core sensing element, ensuring stable and responsive pressure – to – mechanical motion conversion with minimal hysteresis.
- ±3% Full – Scale Accuracy: Guarantees reliable readings across the 0 – 1.0 MPa range, meeting the precision requirements of general industrial pressure monitoring tasks.
- Durable Construction: The housing is made of rolled steel, the transparent cover is polycarbonate, and the internal wetted parts are brass, ensuring resistance to corrosion and mechanical impact for long – term use.
- Back – Side Threaded Connection: The R1/8 back – side thread enables flexible panel or pipeline mounting, simplifying installation in confined spaces and reducing assembly time.
- Clear Dial Design: The 36 mm dial has bold scales and clear markings, making it easy to read even from a short distance, which speeds up on – site inspections and reduces reading errors.
- Wide Operating Conditions: Operates stably at temperatures ranging from -5°C to 60°C and relative humidity of 35% – 85% (non – condensing), adapting to typical industrial environments.
- Cost – Effective Reliability: The mechanical design without electronic components results in low failure rates and maintenance costs, providing long – term service life with proper use and installation.
4. Product Dimensions (Unit: mm)
| Dimension Parameter | Value |
|---|---|
| Outer Diameter (Dial) | 36 |
| Total Height (Including Thread) | 42 |
| Thread Type | R1/8 (Back – Side Male) |
| Thread Length | 8 |
| Dial Thickness | 12 |
| Mounting Clearance | 38 (Minimum Panel Hole Diameter) |
| Pointer Length | 14 |
| Scale Range | 0 – 1.0 MPa (0 – 10 bar) |
5. Weight and Material Specifications
| Component | Material | Weight (g) |
|---|---|---|
| Housing | Rolled Steel | 45 |
| Dial & Pointer | Polycarbonate & Aluminum | 10 |
| Bourdon Tube | Brass | 8 |
| Connection Fitting | Die – Cast Aluminum | 12 |
| Seals & Gaskets | Nitrile Rubber | 5 |
| Total Weight (Assembly) | – | 80 |
6. Key Performance Parameters
| Parameter | Value |
|---|---|
| Measurement Range | 0 – 1.0 MPa (0 – 10 bar) |
| Accuracy Class | ±3% Full – Scale |
| Working Fluid | Filtered Compressed Air (Max Particle Size ≤5 μm) |
| Proof Pressure | 1.5 MPa |
| Operating Temperature | -5°C to 60°C |
| Storage Temperature | -10°C to 70°C |
| Relative Humidity | 35% – 85% (Non – Condensing) |
| Connection Torque | 7 – 9 N·m (R1/8 Thread) |
| Service Life | ≥10,000 Cycles (Under Rated Conditions) |
| Wetted Parts Material | Brass (Bourdon Tube), Die – Cast Aluminum (Fitting) |
