Schneider EZC100F3050 Circuit Breaker
1. Product Overview
The Schneider Electric EZC100F3050 is a 3-pole, 50A molded case circuit breaker (MCCB) belonging to the EZC100 series, designed for reliable overload and short-circuit protection in low-voltage distribution systems. It serves as a critical safety component for industrial machinery, commercial buildings, and secondary power distribution networks, ensuring uninterrupted power supply while protecting equipment from damage caused by electrical faults.
Engineered to comply with international standards (IEC 60947-1, IEC 60947-2), the breaker features a compact, DIN-rail mountable design that optimizes space in distribution boards and control cabinets. Its robust construction delivers consistent performance in variable environments, with a visible open/closed position indicator for enhanced safety during maintenance. The EZC100F3050 supports easy replacement and integration with other Schneider Easy series components, making it a cost-effective solution for diverse application scenarios.
2. Main Functions
表格
| Function | Detailed Description |
|---|---|
| Overload Protection | Thermally-magnetic trip mechanism automatically interrupts current when sustained overloads exceed 设定 values, preventing overheating and equipment damage. |
| Short-Circuit Protection | Rapid magnetic tripping reacts instantly to high short-circuit currents, isolating faults within milliseconds to minimize arc flash and fire hazards. |
| Manual On/Off Control | Ergonomic handle provides positive operation for normal circuit switching, with a mechanical lock to prevent accidental activation/deactivation. |
| Visual Position Indication | Clear status indicator (red for ON, green for OFF) verifies circuit state, ensuring safe maintenance by confirming complete disconnection. |
| Arc Flash Mitigation | Internal arc chute design safely extinguishes electrical arcs during tripping, reducing operator risk and extending component lifespan. |
| Easy Replacement | Tool-accessible design allows quick replacement without full system disassembly, minimizing downtime during maintenance. |
| Compatibility | Seamlessly integrates with Schneider Easy series accessories (auxiliary contacts, signaling devices) for customized system configuration. |
| Wide Temperature Operation | Reliable performance across a broad temperature range, suitable for harsh industrial and environmental conditions. |
3. Technical Features
-
Core Ratings & Configuration
3-pole design with a rated operational voltage of 400 V AC (50/60 Hz) and a rated current of 50 A. The “F” rating denotes a short-circuit breaking capacity of 36 kA, suitable for secondary distribution applications.
-
Trip Unit & Protection
Equipped with a non-interchangeable thermal-magnetic trip mechanism, providing adjustable overload protection (1.05 In for delayed tripping) and instantaneous short-circuit protection (10–20 In). The trip unit is factory-set for immediate use, eliminating complex calibration.
-
Compact Modular Design
Slim profile with a width of 52.5 mm (3 poles × 17.5 mm per pole), ideal for dense distribution boards. Supports vertical, horizontal, or side-mounted installation on standard 35 mm DIN rails, with flexible line/load wiring options.
-
Safety & Compliance
Manufactured to IEC 60947-1/IEC 60947-2 standards, with IP20 protection against direct contact. Features a mechanical interlock to prevent incorrect wiring and ensure safe operation under fault conditions.
-
Environmental Robustness
Operates reliably in ambient temperatures from -25°C to +70°C (with derating above 50°C). Storage temperature ranges from -35°C to +85°C, ensuring durability in diverse industrial environments.
-
Low Maintenance Design
Sealed internal components resist dust and moisture, reducing the need for frequent servicing. The breaker can be reclosed after tripping without manual reset, simplifying post-fault recovery.
4. Product Dimensions (Unit: mm)
表格
| Dimension Parameter | Value |
|---|---|
| Width (3 Poles) | 52.5 |
| Height | 92 |
| Depth | 78 |
| Mounting Interface | Standard 35 mm DIN Rail |
| Terminal Screw Size | M5 |
| Mounting Hole Spacing | 82 × 52.5 |
| Electrical Port Diameter | 6.3 |
5. Weight and Material Specifications
表格
| Component | Material | Weight (g) |
|---|---|---|
| Main Housing | High-Strength Flame-Retardant Thermoplastic (UL94 V0) | 150 |
| Current-Carrying Parts | Copper Alloy with Tin Plating | 60 |
| Trip Mechanism | Metal Alloy (Steel/Brass) | 45 |
| Operating Handle | Durable Thermoplastic with Metal Core | 20 |
| Arc Chute | Ceramic + Steel Alloy | 35 |
| Terminal Screws | Zinc-Plated Steel | 15 |
| Total Weight (Complete Unit) | – | 325 |
