Schneider A9K27210 Miniature Circuit Breaker
Product Overview
The Schneider A9K27210 is a high-performance miniature circuit breaker (MCB) belonging to Schneider Electric’s Acti9 iC65 series. It is a 2-pole (2P) DC circuit breaker with a B-type tripping characteristic and a rated current of 10A. Designed for DC power distribution systems, it provides reliable overcurrent and short-circuit protection for electrical circuits and equipment, ensuring safe operation in industrial, commercial, and residential DC applications. This MCB complies with international standards such as IEC/EN 60898-1 and GB 10963.1, guaranteeing its safety and performance.
Main Functions
- Overcurrent Protection: Automatically trips when the circuit current exceeds the rated value for a certain period, preventing damage to cables and electrical devices caused by overload.
- Short-Circuit Protection: Rapidly disconnects the circuit within milliseconds when a short-circuit fault occurs, effectively isolating the fault and protecting the entire power system.
- Isolation Function: Serves as an effective isolation device, providing a visible disconnection point for circuit maintenance and ensuring the safety of maintenance personnel.
- Fault Indication: Equipped with a visual fault indicator (red window) to clearly show the tripping status, facilitating quick fault location and troubleshooting.
- DC Circuit Adaptation: Optimized for DC systems, with stable performance and reliable tripping characteristics suitable for various DC power supply scenarios.
Technical Features
表格
| Parameter | Specification |
|---|---|
| Model | A9K27210 |
| Series | Acti9 iC65 DC |
| Number of Poles | 2P (2-pole) |
| Rated Current (In) | 10A |
| Tripping Characteristic | B-type (trips at 3–5 × In) |
| Rated Voltage (Ue) | 500 V DC |
| Short-Circuit Breaking Capacity | 10 kA |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Compliance Standards | IEC/EN 60898-1, GB 10963.1 |
| Certifications | CCC, CE |
| Electrical Life | ≥ 10,000 operations |
| Mechanical Life | ≥ 20,000 operations |
| Wiring Method | Front wiring |
| Mounting | Standard 35mm DIN rail mounting |
- High Breaking Capacity: With a 10 kA short-circuit breaking capacity, it can safely handle severe short-circuit faults in DC circuits.
- Stable Tripping Performance: B-type tripping characteristic ensures accurate and timely protection for sensitive DC equipment, avoiding unnecessary tripping caused by transient currents.
- Compact Design: Slim profile for space-saving installation in distribution boxes, suitable for dense wiring environments.
- Durable Construction: High-quality insulating materials and robust mechanical structure ensure long service life and reliable operation in harsh environments.
- Easy Installation: Compatible with standard 35mm DIN rails, enabling quick and convenient installation and replacement.
Product Dimensions
- Width: 36 mm (2 × 18 mm per pole)
- Height: 90 mm
- Depth: 45 mm
- Mounting Pitch: 35 mm (standard DIN rail)
Weight
- Net Weight: Approximately 0.18 kg
